Quick Details
-
Brand Name:
-
JXR 501012
-
Model Number:
-
501012 40mAh
-
Battery Size:
-
Li polymer battery
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
2.5g
-
The charging ratio:
-
1C/customized
-
The discharge rate:
-
1C
-
Cell type:
-
LI-PO
-
Product name:
-
3.7v Lipo Battery
-
Warranty:
-
1 Year
-
Capacity:
-
40mAh
-
Voltage:
-
3.7v~ 4.2v
-
Cycle life:
-
500-1000 Times
-
Size:
-
5*10*12mm
-
Usage:
-
Electronic Devices
-
Material:
-
LCO
-
Model:
-
3.7v Polymer Lithium Battery
Quick Details
-
Storage Type:
-
Standard Storage
-
Anode Material:
-
LCO
-
Application:
-
Toys, Home Appliances, Consumer Electronics
-
Brand Name:
-
JXR 501012
-
Model Number:
-
501012 40mAh
-
Battery Size:
-
Li polymer battery
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
2.5g
-
The charging ratio:
-
1C/customized
-
The discharge rate:
-
1C
-
Cell type:
-
LI-PO
-
Product name:
-
3.7v Lipo Battery
-
Warranty:
-
1 Year
-
Capacity:
-
40mAh
-
Voltage:
-
3.7v~ 4.2v
-
Cycle life:
-
500-1000 Times
-
Size:
-
5*10*12mm
-
Usage:
-
Electronic Devices
-
Material:
-
LCO
-
Model:
-
3.7v Polymer Lithium Battery
Details Images
LI POLYMER BATTERY SOLUTION
We offer over 3000 different battery models and have 12 years of battery experience
The engineer will accurately locate the size required by the customer's sample
|
1
|
Nominal Capacity
|
40mAh
|
|
2
|
Nominal Voltage
|
3.7V
|
|
3
|
Initial Impedance
|
(23±2°C)
|
|
4
|
Limited Charge Voltage
|
4.20V
|
|
5
|
Discharge Cut-off Voltage
|
3.0V
|
|
6
|
Charge Current
|
Standard Charge: 0.2C
|
|
|
|
Rapid Charge: 1C
|
|
7
|
Standard Charge
|
0.2C(constant current) charge to 4.2V, then CV(constant voltage) charge till charge current decline to 0.02C.
|
|
8
|
Standard Discharge
|
0.2 C discharge to the Discharge Cut-off Voltage.
|
|
9
|
End-of-Charge Current
|
0.02C
|
|
10
|
Max Continuous Charge Current
|
1C
|
|
11
|
Max Continuous Discharge Current
|
1C
|
|
12
|
Working Temperature Range
|
Charge : 0 ~ 45°C
|
|
|
|
Discharge : – 20 ~ 60°C
|
|
13
|
Storage Temperature Range
|
-20 ~ 60°C≤1month
-20 ~ 45°C≤3months -20 ~ 30°C≤12months |
|
14
|
Operating and Storage Humidity Range
|
45~75% RH
|
|
15
|
Weight (Approx)
|
3.1g
|
Our Advantages
Grade A Battery
Stable performance, the use of brand new A cell, sufficient capacity and low internal resistance, large output current
Product Testing
True capacity, no false label, low self-discharge, ready to charge and ready to use, safe liquid leakage,environmental protection
Quality Silicone Wire
A technician will test the wire for good performance and weld it to the battery's PCB
Resistance Stability
Test resistance, voltage and battery performance, each type of test before shipment
Connector
Insulation, corrosion resistance and long service life, and you can customize a variety of terminals you need
PCB
New upgraded PCB, with voltage balance and temperature control module, active voltage balance better effect
Production Flow
Production Visualization
Technicians weld the battery pack in the dust-free workshop to ensure the reliability of production
Battery To Be Tested
Check whether all indicators of the battery are good, including appearance, performance of the battery, All require sophisticated testing
About us
Manufacturing Technique
Certificate
Recommend Products
Packing & Shipping
Before Packaging
Before shipment, check whether the appearance, capacity, voltage and other conditions of the battery are good. After testing,place the blister plate and wait for packaging
Packaging
When packing, the battery will be insulated with appropriate blister plate and bubble bag according to the size of the battery to
ensure the safety of the batter
