Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
JUGETEK
-
Model Number:
-
57AIM30
-
Torque:
-
0.48Nm
Quick Details
-
Speed(RPM):
-
1500
-
Continuous Current(A):
-
0.67
-
Efficiency:
-
IE 1
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
JUGETEK
-
Model Number:
-
57AIM30
-
Torque:
-
0.48Nm
Product Features:
· 1. 15-bit absolute encoder, up to 32768 pulses per loop.
· 2. Multi-turn absolute value, the maximum record is 65,535.(batteries needed).Pulse mode: reenergize automatically return to power off position.
· Communication mode: power off to record location.
· 3. Multi-stage DD motor structure, large torque output.
· 4. Integrated servo, simplified wiring, ultra-small volume.
· 5. Low noise, low vibration, high speed positioning, high reliability.
· 6. FOC field oriented vector control, supporting position/velocity closed-loop.
· 7. It can work in the given pulse state with zero lag and follow zero lag.
· 8. 16-bit electronic gear function.
· 9. Modbus RTU communication (1920, 8,N,1).
· 10. Position mode, support pulse + direction signal
· 11. With blocked rotation, overcurrent protection, overpressure protection.
|
Model parameter |
57 AIM 15C |
57 AIM 15CH |
57 AIM 30C |
57 AIM 30CH |
|||
|
Power |
Voltage |
24 ~36VDC |
24 ~36VDC |
24 ~36VDC |
24 ~36VDC |
||
|
Current |
2. 2 A |
2. 2 A |
4.4 A |
4.4 A |
|||
|
Motor parameters |
Torque |
0. 48 NM |
0. 24 NM |
0. 96 NM |
0. 48 NM |
||
|
Rated speed |
1000RPM |
2000 RPM |
1000RPM |
2000 RPM |
|||
|
Max speed |
1 5 00RPM |
25 00RPM |
1 5 00RPM |
25 00RPM |
|||
|
Power |
50W |
50W |
100 W |
100 W |
|||
|
Feedbacks singal |
Multi-coil absolute value encoder (single coil 32768 pulse, single coil 15 bits) |
||||||
|
Cooling method |
Natural cooling |
||||||
|
Weight |
|
||||||
|
Position control mothed |
Maximum input pulse frequency |
500KHz |
|||||
|
|
Pulse command mode |
Pulse + Direction , A phase + B phase |
|||||
|
|
Electronic gear ratio |
Setting range 1~65535 to 1~65535 |
|||||
|
|
Location sampling frequency |
2KHz |
|||||
|
Protection Function |
Stall alarm |
||||||
|
Communication port |
Easycan( CANBus , Speed 1M ) Serial port TTL(19200,8,N,1)(Monitor motor status and modify parameters) |
||||||
|
Us able environment
|
Ambient temperature |
0~40° |
|||||
|
Max motor temperature |
85° |
||||||
|
H umidity |
5~95% |
||||||
About the shipping methods , for samples or small batch , air shipping is recommended .
For mass production or big batch, ocean shipping is recommended .
