Products
IPC-HDBW3849R1-ZAS-PV Outdoor IP67 Vandal-proof dome TIOC Smart Dual Light 8mp PoE 4k ip cctv security camera full color night
IPC-HDBW3849R1-ZAS-PV Outdoor IP67 Vandal-proof dome TIOC Smart Dual Light 8mp PoE 4k ip cctv security camera full color night
IPC-HDBW3849R1-ZAS-PV Outdoor IP67 Vandal-proof dome TIOC Smart Dual Light 8mp PoE 4k ip cctv security camera full color night
IPC-HDBW3849R1-ZAS-PV Outdoor IP67 Vandal-proof dome TIOC Smart Dual Light 8mp PoE 4k ip cctv security camera full color night
IPC-HDBW3849R1-ZAS-PV Outdoor IP67 Vandal-proof dome TIOC Smart Dual Light 8mp PoE 4k ip cctv security camera full color night
IPC-HDBW3849R1-ZAS-PV Outdoor IP67 Vandal-proof dome TIOC Smart Dual Light 8mp PoE 4k ip cctv security camera full color night
IPC-HDBW3849R1-ZAS-PV Outdoor IP67 Vandal-proof dome TIOC Smart Dual Light 8mp PoE 4k ip cctv security camera full color night
IPC-HDBW3849R1-ZAS-PV Outdoor IP67 Vandal-proof dome TIOC Smart Dual Light 8mp PoE 4k ip cctv security camera full color night

IPC-HDBW3849R1-ZAS-PV Outdoor IP67 Vandal-proof dome TIOC Smart Dual Light 8mp PoE 4k ip cctv security camera full color night

FOB Reference Price: Get Latest Price
≥2 Pieces
US $195
≥20 Pieces
US $189
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Place of Origin:
Zhejiang, China
Model Number:
IPC-HDBW3849R1-ZAS-PV
Product name:
Da hua Full Color IP Camera
Image Sensor:
1/2.7" CMOS
Resolution:
3840 x 2160
IR Distance:
50m
Focal Length:
2.7-13.5mm motorized zoom lens
Intelligence:
IVS, SMD 4.0, Quick Search
Video Compression:
H.265; H.264; H.264H; H.264B; MJPEG
Smart Codec:
Smart H.265+/h.264+
Audio:
Built-in Microphone/speaker
Power Supply:
12 VDC / PoE

Quick Details

Special Features:
Face detection, Vandal-proof, Sound Detection, Waterproof / Weatherproof, Built-in Mic, Full Color
Function:
Alarm I/O, Built-in Mic, Waterproof / Weatherproof, Wide Angle, Vandal-proof, Built-in Speaker
Customized support:
Online technical support, Customized logo, Software reengineering, OEM, ODM
Place of Origin:
Zhejiang, China
Model Number:
IPC-HDBW3849R1-ZAS-PV
Product name:
Da hua Full Color IP Camera
Image Sensor:
1/2.7" CMOS
Resolution:
3840 x 2160
IR Distance:
50m
Focal Length:
2.7-13.5mm motorized zoom lens
Intelligence:
IVS, SMD 4.0, Quick Search
Video Compression:
H.265; H.264; H.264H; H.264B; MJPEG
Smart Codec:
Smart H.265+/h.264+
Audio:
Built-in Microphone/speaker
Power Supply:
12 VDC / PoE
Product Description
Launched by Da hua Technology, WizSense is a series of wide range AI products and solutions that adopt independent AI chip and deep learning algorithm. It can recognize human and vehicle in an image with high accuracy, enabling users to focus on real targets. WizSense focuses on human and vehicle, benefiting everyone with intelligent functions, simple configuration and inclusive products.

SMD 4.0:
With upgraded AI capabilities, the SMD function filters out irrelevant objects in the scene. Equipped with new deep learning algorithm, SMD 4.0 is optimized to filter out small and large animals in the scene to avoid triggering false alarms. Also, SMD 4.0 can detect the color information of clothing and vehicle for data support of quick search after an event.

Quick Pick:
Quick Pick technology can quickly identify human/vehicle targets of interest, which optimizes the search for relevant
SMD events. With excellent integration of intelligent functions of both cameras and recorders, this feature can search
human/vehicle targets based on AI algorithm that can extract and compare clothing and vehicle colors.

AI SSA:
AI SSA (Scene Self-adaption) technology is based on deep learning algorithm that can intelligently identify multiple scenes and adjust to their optimal images.

AI Coding(IP Solution):
With the improvement of monitoring resolution, how to maintain image quality while saving storage cost has
become one of the most concerning problems of users. Based on CBR (Constant Bit Rate), WizSense AI Coding dynamically allocate bitrate, providing clear target images while saving more than 25% bit rate compared with H.265.


AI-Powered Image
With AI ISP technology, the camera is able to easily adapt to scenes, producing high quality images that reveal the fine details of targets.

Perimeter Protection
With deep learning algorithm, Da hua Perimeter Protection technology can recognize human and vehicle accurately. In restricted area (such as pedestrian area and vehicle area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion, fast moving, parking detection, loitering detection and gathering detection) are largely reduced.

Face Detection
Da hua Face Detection technology can detect the face in the image. With deep learning algorithm, the technology supports detecting, tracking, capturing and selecting the best face image, and then outputs face snapshot.


Technical Datasheet
Brief specifications for a quick acknowledge of this item, for further detailed parameters or technical consult, please feel free to contact us at HERE.
Model
IPC-HDBW3849R1-ZAS-PV
Image Sensor
1/2.8" CMOS
Max. Resolution
8 MP (3840 × 2160)@25/30 fps
Min. Illumination
0.003 lux@F1.0 (Color, 30 IRE)
0.0003 lux@F1.0 (B/W, 30 IRE)
0 lux (illuminator on)
Illumination Distance
Up to 50 m (164.04 ft) (IR)
Up to 40 m (131.23 ft) (warm light)
Illuminator Number
2 (IR LED); 2 (Warm light)
Lens Type
Motorized
Focal Length
2.7-13.5 mm motorized lens
Field of View
H: 108°–34°
V: 56°–19°
D: 130°–39°
Max. Aperture
F1.4
Intelligence
IVS (Perimeter Protection)
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
SMD
SMD 4.0
Quick Pick
With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events.
Smart Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
EPTZ
Enlarge and track the targets of intelligent alarms
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec
Smart H.265+;Smart H.264+
AI Coding
AI H.265;AI H.264
Video Frame Rate
Main stream: 4096 × 1860@(1–20 fps )
Sub stream: 1200 × 530@(1–20 fps)
Third stream: 1920 × 860@(1–20 fps)
Stream Capability
3 streams
Resolution
4096 × 1860; 3632 × 1632; 3040 × 1368; 1200 × 530; 1920 × 860; 960 × 432
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
Scene Self-adaptation (SSA)
Yes
Audio
Built-in MIC
Yes, built-in dual Mic
Built-in Speaker
Yes, built-in speaker
Audio Compression
G.711a; G.711Mu; PCM; G.726; G.723
General
Network Port
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering;
Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
Management Software
Smart PSS Lite; DSS; DMSS
Audio Input
1 channel (RCA port)
Audio Output
1 channel (RCA port)
Alarm Input
1 channel in: wet contact, 5 mA 3 V–5 VDC
Alarm Output
1 channel out: wet contact, 300 mA 12 VDC
Power Supply
12 VDC (±30%); PoE (802.3af)
Power Consumption
Basic: 3.4 W (12 VDC); 3.8 W (PoE) Max. (H.265+WDR+ warm light+siren and light active deterrence + intelligence on): 9 W (12 VDC);
10.3 W (PoE)
Operating Temperature
–40 °C to +60 °C (–40 °F to +140 °F)
Storage Temperature
–40 °C to +60 °C (–40 °F to +140 °F)
Protection
IP67, IK10
Casing
Metal
Product Dimensions
105 mm × Φ126.0 mm (4.13" × Φ4.96" )
