12-ton Crawler Crane
|
|
|
|
Dual Power
|
Diesel engine and electric motor
|
|
|
Max working radius
|
21m * 1ton
|
|
|
Max Ground Lifting Height
|
22m
|
|
|
Hook lifting speed
|
0-12m/min (high speed 12m/min, low speed 6.5m/min)
|
|
|
Telescopic Wire rope
|
Φ12mm* 100m
|
|
|
Telescopic Boom type
|
Hexagonal fully automatic 5-section
|
|
|
Telescopic Boom length
|
5.5m-21m
|
|
|
Telescopic Boom length/time
|
50sec (fully extended)
|
|
|
Undulating Boom angle/time
|
0~78°/ 60sec
|
|
|
Gyratory angle/time
|
0-360°（continuous）120sec
|
|
|
Outrigger Operating type
|
Manual unscrewing + hydraulic expansion
|
|
|
Outrigger Max extended dimensions
|
Left/Right 7400mm Front 7000mm Back 6000mm
|
|
|
Traveling type
|
Hydraulic motor driven
|
|
|
Traveling speed
|
low speed 0-0.8km/h high speed 0-2km/h
|
|
|
Gradeability
|
20°
|
|
|
Track size
|
2570mm*400mm
|
|
|
Engine Brand
|
YuChai 78KW/ Yanmar
|
|
|
Engine Starting method
|
Electric
|
|
|
Fuel
|
Diesel
|
|
|
Fuel tank capacity
|
50L
|
|
|
Electric Motor model
|
YE2-180-6 (Three-Phase AC Asynchronous Motor)
|
|
|
Motor Voltage
|
AC380V(50Hz) customizable
|
|
|
Motor Power/Speed
|
15KW/ 970 rpm/min
|
|
|
vehicle size
|
6050mm*1850mm*2300mm
|
|
|
vehicle weight
|
11500kg
|
|
|
Hydraulic Oil Tank Capacity
|
130L
|
|
|
Safety Devices optional
|
Remote Control System Safe Load Moment Indicator Anti-Tipping Device One-Click Leveling etc.
|
|
