- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
12V300W IP67
-
Output Frequency:
-
50/60Hz
-
Output Current:
-
25A
-
Model::
-
12V300W IP67
-
AC Voltage::
-
170-260V
-
Frequency:
-
50/60Hz
-
AC current:
-
1.35A
-
DC Voltage:
-
12V±0.5VDC
-
Rated power:
-
300W
-
Current range:
-
25A±1%
-
Overload:
-
100% overloading
-
Short circuit:
-
Auto recovery
-
Size:
-
230*80*40 mm
Quick Details
-
Input Voltage:
-
170V-260V
-
Output Voltage:
-
12V
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
12V300W IP67
-
Output Frequency:
-
50/60Hz
-
Output Current:
-
25A
-
Model::
-
12V300W IP67
-
AC Voltage::
-
170-260V
-
Frequency:
-
50/60Hz
-
AC current:
-
1.35A
-
DC Voltage:
-
12V±0.5VDC
-
Rated power:
-
300W
-
Current range:
-
25A±1%
-
Overload:
-
100% overloading
-
Short circuit:
-
Auto recovery
-
Size:
-
230*80*40 mm
Why Choose Us
Product Parameters
1.Built-in EMI filter
2.Low output ripple noise
3.Over load,over voltage,short circuit
4.CE&Rohs approval
Features:
Aluminum housing,100% waterproof,IP67
Efficiency:>80%
2 years warranty
OEM, ODM are acceptable
|
Model
|
12V300W IP67
|
|
|
|
Input
|
AC Voltage:
|
170-260V
|
|
|
|
Frequency
|
50/60Hz
|
|
|
|
AC current
|
1.35A
|
|
|
Output
|
DC Voltage
|
12V±0.5VDC
|
|
|
|
Rated power
|
300W
|
|
|
|
Current range
|
25A±1%
|
|
|
Protection
|
Overload
|
100% overloading
|
|
|
|
Short circuit
|
Auto recovery
|
|
|
|
Over voltage
|
≤255V
|
|
|
|
Over temperature
|
≤80°C
|
|
|
Others
|
Waterproof rate
|
IP67
|
|
|
|
Cooling
|
by convection
|
|
|
|
Efficiency
|
>80%
|
|
|
|
Housing materials
|
Aluminum
|
|
|
|
Dimension(mm)
|
230（L）*80（W）*40（H）
|
|
|
|
Weight
|
1.4kgs
|
|
1.LED switching power supply using pulse width modulation (PWM) switching technology designed to ensure power supply stability and high efficiency.
2. Product interference, through the EMC testing, ripple ≤ 50MV.
3. Efficiency above 80%, temperature ≤ 25 °C.
4.LED switching power supply with overvoltage protection, short circuit protection, overload protection.
5. Constant current output to ensure the stability of the power, so that LED lighting effects better and live longer.
6. Products have the anti-interference ensures long-life LED strips, reducing the LED lighting decline.
