Quick Details
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT, laser engraving machine
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
China
-
Brand Name:
-
LS
-
Weight (KG):
-
1000 KG
-
Core Components:
-
Other
-
Product name:
-
laser cutting machine
-
spindle:
-
6.0KW air cooling spindle
-
machine controller:
-
DSP A18 4 axis controller
-
Motor:
-
Leadshine Servo motor
-
Z axis height:
-
1000mm
-
Table:
-
T-Slot
-
machine frame:
-
heavy duty frame
-
inverter:
-
Fuling
-
Rotary:
-
diameter 700mm
-
application:
-
F wood plastic MDF
Quick Details
-
Engraving Area:
-
1300*2500mm
-
Laser Type:
-
CO2
-
Engraving Speed:
-
0-350mm/s
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT, laser engraving machine
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
China
-
Brand Name:
-
LS
-
Weight (KG):
-
1000 KG
-
Core Components:
-
Other
-
Product name:
-
laser cutting machine
-
spindle:
-
6.0KW air cooling spindle
-
machine controller:
-
DSP A18 4 axis controller
-
Motor:
-
Leadshine Servo motor
-
Z axis height:
-
1000mm
-
Table:
-
T-Slot
-
machine frame:
-
heavy duty frame
-
inverter:
-
Fuling
-
Rotary:
-
diameter 700mm
-
application:
-
F wood plastic MDF
Product Description
Machine configurations:
#working area is :1300*2500mm
#300W SLW brand laser tube
#laser head for cutting metal
#follow-up control system on the laser head
#Ruida 6332M control system
#oxygen auxiliary equipment for cutting metal
#taiwan HINWIN rails
#water chiller CW6000
#Stepper motor and Leadshine driver
#Taiwan Dongfeng belt
#blade table #Red light point #1×USB Cable
#550w Air Exhaust Fan with Tube ducts
#Three Reflection mirror and one focus lens Original imported from Singapore
#1×Air Pump for Air Assist
#It supports multiple graphic formats, such as PLT / DXF / BMP / JPG / GIF / PGN / TIF and so on.
# Control System for CorelDraw/AutoCAD and other advance software.
# Compatible with WIN7, 8,10
#We have manual book and CD for Software's Installing and Operation
#300W SLW brand laser tube
#laser head for cutting metal
#follow-up control system on the laser head
#Ruida 6332M control system
#oxygen auxiliary equipment for cutting metal
#taiwan HINWIN rails
#water chiller CW6000
#Stepper motor and Leadshine driver
#Taiwan Dongfeng belt
#blade table #Red light point #1×USB Cable
#550w Air Exhaust Fan with Tube ducts
#Three Reflection mirror and one focus lens Original imported from Singapore
#1×Air Pump for Air Assist
#It supports multiple graphic formats, such as PLT / DXF / BMP / JPG / GIF / PGN / TIF and so on.
# Control System for CorelDraw/AutoCAD and other advance software.
# Compatible with WIN7, 8,10
#We have manual book and CD for Software's Installing and Operation
Specification
|
item
|
value
|
|
Application
|
Laser Engraving
|
|
Applicable Material
|
Stainless steel, carbon steel Acrylic, Crytal, Glass, Leather, MDF, Paper, Plastic, Plexiglax, Plywood, Rubber, Stone, Wood
|
|
Engraving Area
|
1300*2500mm
|
|
Engraving speed
|
0-350mm/s
|
|
Graphic Format Supported
|
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT, laser engraving machine
|
|
Cooling Mode
|
WATER Chiller CW6000
|
|
Laser Source Brand
|
SLW
|
|
Guiderail Brand
|
HIWIN
|
|
Control System Brand
|
RuiDa
|
|
Gross weight
|
1000KG
|
|
Table
|
Blade
|
|
Accessories
|
Exhaust fan, air pump, water chiller
|
APPLICATIONS
Applicable Materials
This hybrid laser cutting machine is suitable for metal cutting and nonmetal cutting, like stainless steel sheet,
carbon steel sheet metal materials,
and organic glass , leather, cloth, acrylic, wood , mdf, pvc, plywood, maple leaf, double-color sheet, bamboo,
plexiglas, paper, leather, marble, ceramics, etc. nonmetal materials.
Applicable Industries
Applicable Industries
This dual heads laser cutting machine is widely used in manufacture billboard, advertising, signs, signage,
metal letters, led letters, kitchen ware, advertising letters, sheet metal processing, metals components and parts,
ironware, chassis, racks & cabinets processing, metal crafts, metal art ware, elevator panel cutting, hardware,
auto parts, glasses frame, electronic parts, nameplates, advertisement, arts and crafts, leather, toys, garments,
model, building upholstery, computerized embroidery and clipping, packaging and paper industry,etc..
