Quick Details
-
Storage Type:
-
DRY AND NORMAL TEMPERATURE
-
The charging ratio:
-
80%
-
The discharge rate:
-
95%
-
Warranty:
-
1 years, 1 years
-
Battery Size:
-
12XV 120AH lead acid battery
-
Brand Name:
-
None
-
Model Number:
-
US-EM12V120-20
-
Place of Origin:
-
Anhui, China
-
Weight:
-
30 KGS
-
Product name:
-
24v battery
-
Voltage:
-
24 Volt
-
Type:
-
Lead Acid
-
Capacity:
-
200Ah@20hr-rate to 1.75V per cell @25℃
-
Features:
-
Deep Cycle Life
-
Electrolyte:
-
GEL Acid Battery
-
Material:
-
High Pure Lead
-
OEM/ODM:
-
Avaiable
-
Container Material:
-
Strong ABS
Quick Details
-
Chargeable:
-
Yes
-
Battery Type:
-
Deep Cycle: Sealed Gel
-
Cycle Life:
-
15 years (floating charge)
-
Storage Type:
-
DRY AND NORMAL TEMPERATURE
-
The charging ratio:
-
80%
-
The discharge rate:
-
95%
-
Warranty:
-
1 years, 1 years
-
Battery Size:
-
12XV 120AH lead acid battery
-
Brand Name:
-
None
-
Model Number:
-
US-EM12V120-20
-
Place of Origin:
-
Anhui, China
-
Weight:
-
30 KGS
-
Product name:
-
24v battery
-
Voltage:
-
24 Volt
-
Type:
-
Lead Acid
-
Capacity:
-
200Ah@20hr-rate to 1.75V per cell @25℃
-
Features:
-
Deep Cycle Life
-
Electrolyte:
-
GEL Acid Battery
-
Material:
-
High Pure Lead
-
OEM/ODM:
-
Avaiable
-
Container Material:
-
Strong ABS
Recommend Products
Product Description
Solar energy power systems storage:
24v battery
solar battery
Specification
|
Model
|
6-GFM(G)-100Ah
|
6-GFM(G)-150Ah
|
6-GFM(G)-200Ah
|
6-GFM(G)-250Ah
|
|||
|
Weight
|
29 KG
|
42 KG
|
58.5 KG
|
67 KG
|
|||
|
Cells Per Unit
|
6
|
1 PCS
|
|
|
|||
|
Voltage Per Unit
|
12V
|
20 PCS
|
|
|
|||
|
Capacity
|
100Ah@10hr-rate to 1.80V per cell @25°C
|
150Ah@10hr-rate to 1.80V per cell @25°C
|
200Ah@10hr-rate to 1.80V per cell @25°C
|
250Ah@10hr-rate to 1.80V per cell @25°C
|
|||
|
Internal Resistance
|
Approx. 6mΩ
|
Approx. 4mΩ
|
Approx. 3.5mΩ
|
Approx. 2mΩ
|
|||
|
Terminal
|
F1/F2
|
4~8 PCS
|
|
|
|||
|
Design Life
|
10~15 years
|
1 SET
|
|
|
|||
|
Maximum Charging Current
|
25A
|
37.5A
|
50A
|
62.5A
|
|||
|
Float Charging Voltage
|
13.6 V~13.8 V @ 25°C
Temperature Compensation: -20mV/°C/Cell |
20 Prs
|
|
|
|||
|
Cycle Use Voltage
|
14.4 V~14.9 V @ 25°C
Cycle Use Voltage
Temperature Compensation: -30mV/°C/Cell
|
|
|
|
|||
|
Operating Temperature Range
|
Discharge: -20°C~60°C
Charge: 0°C~50°C
Storage: -20°C~60°C
|
|
|
|
|||
|
Container Material
|
A.B.S. UL94-HB, UL94-V0 Optional.
|
|
|
|
|||
|
Max. Discharge Current
|
1500A(5s)
|
1500A(5s)
|
3000A(5s)
|
3000A(5s)
|
|||
