Quick Details
-
Cutting Area:
-
depend on model
-
Cutting Thickness:
-
depend on material
-
Control Software:
-
DSP
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
G.weike
-
Weight (KG):
-
480 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Online support, Field installation, commissioning and training, Video technical support
-
laser type:
-
co2 laser
-
Engraving speed:
-
0 - 60,000mm/min
-
Resetting positioning:
-
±0.05mm
-
Certification:
-
ce
-
After Warranty Service:
-
Video technical support, Online support, Field maintenance and repair service
-
Local Service Location:
-
Egypt, Italy, Germany, Peru, Indonesia, Russia, Thailand, Malaysia, Argentina, Chile, Sri Lanka, South Africa, Kazakhstan, Tajikistan
-
Showroom Location:
-
Canada, United Kingdom, France, Viet Nam, Philippines, India, Mexico, Argentina, South Korea, UAE, Colombia, Romania, Nigeria, Uzbekistan, Australia
-
Marketing Type:
-
Ordinary Product
Quick Details
-
Laser Type:
-
CO2
-
Cutting Speed:
-
50 mm/s
-
Cooling Mode:
-
WATER COOLING
-
Cutting Area:
-
depend on model
-
Cutting Thickness:
-
depend on material
-
Control Software:
-
DSP
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
G.weike
-
Weight (KG):
-
480 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Online support, Field installation, commissioning and training, Video technical support
-
laser type:
-
co2 laser
-
Engraving speed:
-
0 - 60,000mm/min
-
Resetting positioning:
-
±0.05mm
-
Certification:
-
ce
-
After Warranty Service:
-
Video technical support, Online support, Field maintenance and repair service
-
Local Service Location:
-
Egypt, Italy, Germany, Peru, Indonesia, Russia, Thailand, Malaysia, Argentina, Chile, Sri Lanka, South Africa, Kazakhstan, Tajikistan
-
Showroom Location:
-
Canada, United Kingdom, France, Viet Nam, Philippines, India, Mexico, Argentina, South Korea, UAE, Colombia, Romania, Nigeria, Uzbekistan, Australia
-
Marketing Type:
-
Ordinary Product
machines for
small factories Cut machines lenses 100w
laser cutter laser cnc cutting machine rubber
gasket
cutting machine rubber gasket Introduction
1. English version Lasercut software supporting 10 commonly used graphic formats.
2. DSP off-line control with USB port interface
3. US Imported focusing lenses , choice of 4", 2.5" focal lengths.
4. Focusing is simple by touching two button, takes only 3 seconds
6. All models feature a red dot alignment pointer , helping you to properly position your work under the laser head
7. Un-limited feed -through door , we can only add the auto-feeding system allows the use of roll material and unlimited sheet length
8. Air asist ,we will provide you one set air compressor, you can turn up/down the switch between the laser head to control the strength of air blowing. To avoid getting fired and blow away the dusk /smoke.
9. Exhaust fan&vacuum table , this pulls fumes and debris away from the work piece; the resulting vacuum is strong enough to straighten and flatten thin materials against the work table for cutting and engraving in perfect focus.
10. The price include one set EXLAS, exhaust fan, air assist compressor , one tool box, CD friendly training video and user macnual,and one year warranty.
cutting machine rubber gasket Fe ature:
1. Clean cut edges without burr for more efficient material utilization
and reduced secondary operations.
2. Cutting of various material thicknesses and combinations in one operation
3. No material deformation due to contactless material processing
4. Highly controllable, repeatable and accurate processing.
Etc.
cutting machine rubber gasket Applicable industries:
|
Laser type |
Sealed CO2 laser tube |
|
Laser power |
60w(80W,100W,130W,150W,180W optional) |
|
Engraving area |
500*300mm(600x400mm,600x900mm,600x1000mm,900x1200mm, 900x1300mm,900x1400mm,1200x1500mm,1200x1600mm and 1300x2500mm,1500x3000mm etc) |
|
Whole machine size |
1360*780*1100mm |
|
Engraving speed |
0 - 60,000mm/min |
|
Resetting positioning accuracy |
±0.05mm |
|
Working voltage |
AC 110 - 220V±10%, 50 - 60Hz |
|
Gross power |
<1,000W |
|
Operating temperature |
0 - 45°C |
|
Operating humidity |
5- 95% |
|
Minimum shaping character |
English 1 x 1mm |
|
Graphic format supported |
BMP,PLT, DST, DXF, and AI |
|
Driving system |
stepper |
|
Cooling mode |
water-cooling and protection system |
|
Auxiliary equipments |
Exhaust-fans, air-exhaust pipe |
|
Controlling software |
DSP control system |
|
Compatible software |
CorelDraw AutoCAD Photoshop |
|
Net Weight |
150kg(depends on models) |
