ROCKER SWITCH MODEL :
|
LXW-3-6C-A22Q-R1
|
|
QUICK CONNECTOR TYPE :
|
SINGLE POLE DOUBLE THROW
|
|
RATING :
|
16 250V/120vAC μ T125/85
|
|
CONTACT RESISTANCE ：
|
<50mΩ(INITIAL)
|
|
INSULATION RESISTANCE ：
|
≥100MΩ(DC500V/1MIN)
|
|
DIELECTRIC STRENGTH ：
|
1500V/0.5mA /1MIN
|
|
MECHANICAL LIFE ：
|
>50000 CYCLES
|
|
ELECTRICAL LIFE ：
|
>10000 CYCLES
|
|
OPERATION FORCE ：
|
550±150gf
|
|
MATERIALS ：
|
ALL MATERIALS ARE ROHS COMPLIANT
|
* Automatic workshope, More efficient, Higher standard. Keep the cost down.
* All the material RoHS Compliant, Materials bulk purchase keep the cost down.
* ENEC, NEMKO, VDE, CQC, CD, CB certification and Our Own patents.
* Mechanical life more than 50,000 cycles, ELECTRICAL life more than 10,000 cycles.
YIMINGDA
, Specific on series of slide switch, rocker switch, micro switch etc, Widely used in the household electronic appliance such as Hairdryer, Vacuum cleaner, Desk Lamp, Micro Oven ETC…
In order to produce safe products for whole world's use,we strictly control chemistry materials which do harm to the world. Re RoHS directive(Restriction of the use of certain hazardous substances in electrical and electronic equipment) carried out after July 2006,we have carried out after March 2006. All of Our products are comply to ENEC, NEMKO, VDE, CQC, CD, CB and so On.
OEM and ODM were Welcome.
A: We are factory, It's Our honour if you can pay us a visit.
A: Generally it is 6,000,000 pcs per month.
A: Yes, we offer free sample but do not pay the freight cost.
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
