Blanket Geosynthetic Clay Liner for Landfill/Bentonite Waterproof Pad (GCL) Geosynthetic Clay Liner for Basement

Blanket Geosynthetic Clay Liner for Landfill/Bentonite Waterproof Pad (GCL) Geosynthetic Clay Liner for Basement

FOB Reference Price: Get Latest Price

≥1000 Square meters

US $1.41

≥100000 Square meters

US $1.39

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Application:: Outdoor

Design Style:: Modern

Place of Origin:: Shandong, China

Brand Name:: Shandong Bring Plenitude

Model Number:: GCL-NP

Specification:: 4000g,4500g,5000g,5500g

Product name:: Blanket Geosynthetic Clay Liner

Standard:: Export standard

Material:: Bentonite

Textile1:: 120g Woven geotextile with plastic flat filament

Textile2:: 200g nonwoven geotextile

Weight:: 4000g,4500g,5000g,5500g

Length:: 20m,30m

Width:: 3m, 4.5m, 5m

MOQ:: 1000 Square Meter

Keyword:: geosynthetic clay liner price

Quick Details

Warranty:: More than 5 years

After-sale Service:: Online technical support, Free spare parts, Other, NONE

Project Solution Capability:: graphic design, total solution for projects, NONE, Others

Application:: Outdoor

Design Style:: Modern

Place of Origin:: Shandong, China

Brand Name:: Shandong Bring Plenitude

Model Number:: GCL-NP

Specification:: 4000g,4500g,5000g,5500g

Product name:: Blanket Geosynthetic Clay Liner

Standard:: Export standard

Material:: Bentonite

Textile1:: 120g Woven geotextile with plastic flat filament

Textile2:: 200g nonwoven geotextile

Weight:: 4000g,4500g,5000g,5500g

Length:: 20m,30m

Width:: 3m, 4.5m, 5m

MOQ:: 1000 Square Meter

Keyword:: geosynthetic clay liner price

Product Description

Product Description

Geosynthetic Clay Liners is called bentonite composite waterproof blanket (GCL), also known as bentonite waterproof blanket,waterproof mat, GCL waterproof mat and other bentonite composite waterproof blanket (GCL) which is a new type of geosynthetic material. It is a blanket waterproofing membrane made by mixing the natural sodium-based bentonite particles and the corresponding admixtures into raw materials, and fixing the bentonite particles between the geotextile and the plastic woven fabric through a needle punching process and equipment. The bentonite waterproof blanket has all the characteristics of geotechnical materials and excellent waterproof (permeability) properties.

Our Specification

SPECIFICATION

Product Name	Geosynthetic Clay Liner(GCL)
Standard	Export standard
Raw material	Nowoven geotextile+Bentonite+Woven geotextile
Unit weight	4000g,4500g,5000g,5500g
Width	3m,4.5m,5m
Length	20m-30mm
Min order	1000sqm
Packing	Roll with PP woven bags
Port	Qingdao

geosynthetic clay liner pricegeosynthetic clay liner price geosynthetic clay liner price

Item		Item
Item		GCL-NP	GCL-OF	GCL-AH
Unit weight(g/m2)		≥4000	≥4000	≥4000
Bentionite swell index/ (mL/2g)		≥24	≥24	≥24
Ethylene blue adsorbed/(g/100g)		≥30	≥30	≥30
Tensile strength/(N/100mm)		≥600	≥700	≥600
Elongation at maximum load/%		≥10	≥10	≥10
Peel strenghth/(N/100mm)	Nonwoven and woven geotextile	≥40	≥40	/
Peel strenghth/(N/100mm)	PE membrane and nonwoven textile	/	≥30	/
Permeability/(m/s)		≤5.0×10 ¹¹	≤5.0×10 ¹²	≤5.0×10 ¹²
Hydrostatic pressure		0.4Mpa,1h, no leakage	0.4Mpa,1h, no leakage	0.6Mpa,1h, no leakage
Filtrate loss/ mL		≤18	≤18	≤18
Bentionite compatibility/(ml/2g)		≤20	≤20	≤20

Product Uses

APPLICATION

1. Municipal project, subway, underground and roof waterproofing
2. Landfill, wastewater treatment, industrial waste
3. Waterproofing and reinforcement in water conservancy, river lake, and dam
4. Artificial lake, golf course, and fish pond
5. Petrifaction and mineral waterproofing

Packaging & Shipping

Packing&Shipping

Packed in roll and put in woven bags,plastic bags or customized.
Customer's logo on package available. bentonite gcl for golf course lake liners

COMPANY INFORMATION

COMPANY INFORMATION

Shandong Bring Plenitude New Materials is located in Tai'an, Shandong ,China. which is a high tech enterprise specializing in designing and manufacturing of geosynthetic materials. It covers up 33000 square meters, and have geotextile, steel and plastic geogrid, geomembrane, geocell and other total five production lines, more than 110 employees, annual output of new materials more than 12,000 tons.Main products include geogrid, non woven geotextile, geomembrane, waterproof board/sheet, geocell, composite geotextile and so on. The company has passed ISO9001 / ISO14001 / OHSAS18001 and CE certificate. The products are widely used in reinforcement of railway, highway construction, water conservancy, electric power construction, municipal engineering, port works etc., The products are also exported to Southeast Asia, Japan, Korea, North America , Australia and other 20 countries.

CERTIFICATE

CERTIFICATE

The company has passed ISO9001 / ISO14001 / OHSAS18001 and CE certificate.
