Quick Details
-
Feed Mechanism:
-
Multiple
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
ALLRAISE
-
Power:
-
200w, 220v,380v
-
Overall Dimensions:
-
1250mmx600mmx1200mm
-
Product name:
-
gloves overlock butterfly sewing machine sewing machine overlock price
-
Model:
-
OR-8400X
-
Size:
-
7/10G 13/15G
-
Capacity(Dozen/hour):
-
70-80 50-60
-
Stitch Width:
-
3-6mm
-
Machine group:
-
2 unit/group
-
Speed:
-
4500-5500 rpm
-
Voltage:
-
200w,50/60HZ
-
Application:
-
overlock for glove
-
After-sales Service Provided:
-
Video technical support, Online support
-
Certification:
-
CE
Quick Details
-
Type:
-
Industrial Sewing Machine
-
Max. Sewing Thickness:
-
gloves overlock butterfly sewing machine sewing machine overlock price
-
Stitch Length:
-
gloves overlock butterfly sewing machine sewing machine overlock price
-
Feed Mechanism:
-
Multiple
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
ALLRAISE
-
Power:
-
200w, 220v,380v
-
Overall Dimensions:
-
1250mmx600mmx1200mm
-
Product name:
-
gloves overlock butterfly sewing machine sewing machine overlock price
-
Model:
-
OR-8400X
-
Size:
-
7/10G 13/15G
-
Capacity(Dozen/hour):
-
70-80 50-60
-
Stitch Width:
-
3-6mm
-
Machine group:
-
2 unit/group
-
Speed:
-
4500-5500 rpm
-
Voltage:
-
200w,50/60HZ
-
Application:
-
overlock for glove
-
After-sales Service Provided:
-
Video technical support, Online support
-
Certification:
-
CE
gloves overlock butterfly sewing machine sewing machine overlock price
karen@ allmachine.cn +86 18838190080
Parameter of gloves overlock butterfly sewing machine sewing machine overlock price
Usage |
gloves overlock butterfly sewing machine sewing machine overlock price |
|||
Model |
OR-8400X |
OR-8400S |
||
Size |
7/10G |
13/15G |
7/10G |
13/15G |
Capacity : Dozen/hour |
70-80 |
50-60 |
60-70 |
45-55 |
Stitch Width |
3-6mm |
3-6mm |
||
M achine group |
2 unit/group |
2 unit/group |
||
Speed |
4500-5500 rpm |
4500-5500 rpm |
||
Power |
220v,380v |
220v,380v |
||
Pressure |
4-5Bar |
4-5Bar |
||
V oltage |
200w,50/60HZ |
200w,50/60HZ |
||
P acking size |
1250mmx600mmx1200mm |
1250mmx600mmx1400mm |
||
Net Weight |
78KG |
93KG |
||
Gross Weight |
118KG |
130KG |
OR-8400X: air suction model. Adopts air suction device with short thread residue on rib top and with better effect;
OR-8400W:thread residue free model. Adopts cutting die for thread cutting without waste of thread residue, more economic;
OR-8400P:rubber band model. Rib top with ribber ring, thread oriented, suitable for gloves not possible to use rubber band on the rib top.
OR-8400X:trade mark model. Marks are sewed automatically with external and internal marks switched by one button.
Features of gloves overlock butterfly sewing machine sewing machine overlock price
1. Computer control system: 32-bit micro-controller is used, which simplifies the complex control devices with more stable and reliable performance, as well as automatic switching among edging modes.
2. Opening panel:LCD with simple and easy operation, automatically counting.
3. Rubber band feeding device: sectional speed setting; able to rotate forward and backward; suitable for different glove seaming;
4. Machine head system: controlled by variable frequency motor with high speed, small noise and durable.
5. Threading device: upper and lower looper structure with reasonable design, making he alignment smoother with less breaking.
6. Suction device: controls scissor and suction motions accurately to reduce thread residue, thus reduce the waste.
7. Scissor device: trimming quickly, durable.
8. Big and small jockey pulley device: ensures stable rotation of glove, thus to ensure the edging effect.
9. Air channel system: adopts imported solenoid valve, cylinder, connector and air pipe with more stable and reliable performance.
