· S
ingle phase
5kW 6kW 8kw
· 100% unbalanced output, each phase; Max. output up to 50% rated power
· AC couple to retrofit existing solar system
· Max. 16 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel ·Max.charging/discharging current
of 190A
·48V low voltage battery, transformer isolation design
· 6 time periods for battery charging/discharging
·Support storing energy from diesel generator
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Roof Mounting
-
Certificate:
-
CE,UL
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
MENRED ESS
-
Model Number:
-
LP1 8kw G3
-
Output Voltage (V):
-
220/380, 230/400Vac
-
Output Frequency:
-
50/60Hz; 3L/N/PE
-
Work Time (h):
-
24 Hours
-
Product name:
-
Hybrid Solar System
-
Battery:
-
Lifepo4 Lithium Battery
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Monocrystalline Silicon
-
Battery Type:
-
Lithium Ion
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Roof Mounting
-
Certificate:
-
CE,UL
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
MENRED ESS
-
Model Number:
-
LP1 8kw G3
-
Output Voltage (V):
-
220/380, 230/400Vac
-
Output Frequency:
-
50/60Hz; 3L/N/PE
-
Work Time (h):
-
24 Hours
-
Product name:
-
Hybrid Solar System
-
Battery:
-
Lifepo4 Lithium Battery
Products Description
|
Model
|
SUN-8K-SG05LP1-EU
|
|
|
||
|
Battery Input Data
|
|
|
|
||
|
Battery Type
|
Lead-acid or Li-lon
|
|
|
||
|
Battery Voltage Range (V)
|
40~60
|
|
|
||
|
Max. Charging Current (A)
|
190
|
|
|
||
|
Max. Discharging Current (A)
|
190
|
|
|
||
|
External Temperature Sensor
|
Yes
|
|
|
||
|
Charging Curve
|
3 Stages / Equalization
|
|
|
||
|
Charging Strategy for Li-Ion Battery
|
Self-adaption to BMS
|
|
|
||
|
PV String Input Data
|
|
|
|
||
|
Max. DC Input Power (W)
|
10400
|
|
|
||
|
Rated PV Input Voltage (V)
|
370 (125~500)
|
|
|
||
|
Start-up Voltage (V)
|
125
|
|
|
||
|
MPPT Voltage Range (V)
|
150-425
|
|
|
||
|
Full Load DC Voltage Range (V)
|
200-425
|
|
|
||
|
PV Input Current (A)
|
26+26
|
|
|
||
|
Max. PV ISC (A)
|
34+34
|
|
|
||
|
Number of MPPT / Strings per MPPT
|
2/2+2
|
|
|
||
|
AC Output Data
|
|
|
|
||
|
Rated AC Output and UPS Power (W)
|
8000
|
|
|
||
|
Max. AC Output Power (W)
|
8800
|
|
|
||
|
AC Output Rated Current (A)
|
36.4
|
|
|
||
|
Max. AC Current (A)
|
40
|
|
|
||
|
Max. Continuous AC Passthrough (A)
|
50
|
|
|
||
|
Peak Power (offff grid)
|
2 time of rated power, 10 S
|
|
|
||
|
Power Factor
|
0.8 leading to 0.8 lagging
|
|
|
||
|
Output Frequency and Voltage
|
50 / 60Hz; L1/L2/N(PE) 120/240Vac (split phase), 208Vac (2/3 phase),
L/N/PE 220/230Vac (single phase) |
|
|
||
|
Grid Type
|
Split phase; 2/3 phase; Single Phase
|
|
|
||
|
DC injection current (mA)
|
THD<3% (Linear load<1.5%)
|
|
|
||
|
Efficiency
|
|
|
|
||
|
Max.Efficiency
|
97.6%
|
|
|
||
|
Euro Efficiency
|
97%
|
|
|
||
|
MPPT Efficiency
|
99.9%
|
|
|
||
|
Protection
|
|
|
|
||
|
Integrated
|
PV Input Lightning Protection, Anti-islanding Protection, PV String Input Reverse Polarity Protection,
Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Surge protection |
|
|
||
|
Certififications and Standards
|
|
|
|
||
|
Grid Regulation
|
CEI 0-21, VDE-AR-N 4105, NRS 097, IEC 62116, IEC 61727, G99, G98,
VDE 0126-1-1, RD 1699, C10-11 |
|
|
||
|
Safety EMC / Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
|
|
||
|
General Data
|
|
|
|
||
|
Operating Temperature Range (℃)
|
-45~60℃, >45℃ derating
|
|
|
||
|
Cooling
|
Natural cooling
|
|
|
||
|
Noise (dB)
|
<30 dB
|
|
|
||
|
Communication with BMS
|
RS485; CAN
|
|
|
||
|
Weight (kg)
|
24
|
|
|
||
|
Size (mm)
|
365W x 580H x237D
|
|
|
||
|
Protection Degree
|
IP65
|
|
|
||
|
Installation Style
|
Wall-mounted
|
|
|
||
|
Warranty
|
5 years
|
|
|
||
· Optimized structural safety
· Efficient laser welding
· Comprehensive protection BMS
· Unique connection design
· Touchscreen EMS panel
· Upgrade with Touchscreen
EMS panel (optional)
· Flexible configuration
· Easy installation
· Efficient laser welding
· Comprehensive protection BMS
· Unique connection design
· Touchscreen EMS panel
· Upgrade with Touchscreen
EMS panel (optional)
· Flexible configuration
· Easy installation
|
Model
|
LFP.6144 .G2
|
LFP.6144 .G3
|
LFP.6144.G4
|
||
|
Battery Cell
|
Lithium Iron Phosphate (cobalt-free)-LiFePO4
|
|
|
||
|
Energy Capacity
|
12.28kWh
|
18.43kWh
|
24.57kWh
|
||
|
Usable Capacity
|
11.66kWh（DoD 95%）
|
17.50kWh（DoD 95%）
|
23.34kWh（DoD 95%）
|
||
|
Assembly method
|
1 Parallel Control Box
and 2 Battery Packs
|
1 Parallel Control Box
and 3 Battery Packs
|
1 Parallel Control Box
and 4 Battery Packs
|
||
|
Nominal Voltage
|
51.2Vdc
|
|
|
||
|
Operate Voltage Range
|
44.8Vdc-57.6Vdc
|
|
|
||
|
Max Charge Current
|
300Amp Max@15kW inverter
|
|
|
||
|
Max Discharge Current
|
300Amp Max@15kW Grid or PV Charge
|
|
|
||
|
Max Parallel
|
4PCS to 49.12kWh
|
4PCS to 73.72kWh
|
4PCS to 98.28kWh
|
||
|
Cycle Life
|
≥6000times @ 1C 0.5C & 25±2°C
|
|
|
||
|
Operate Temperature
|
Battery discharge:-10°C to +50°C, Battery Charge: 0°C to +50°C
|
|
|
||
|
Warranty
|
5Years/10Years(Option)
|
|
|
||
|
IP Grade
|
IP21（Indoor）
|
|
|
||
|
Installation
|
Floor Stand Installation
|
|
|
||
|
Communication Port
|
CAN/RS485
|
|
|
||
|
BMS Monitoring
|
SOC, System Voltage, I/O Current, Cell Voltage,
Cell Temp, Battery Status, Fault code
|
|
|
||
|
Support Inverter
Brands |
CAN:
Victron V1.0/SMA V2.0/ Studer V1.03/CNBOU V1.0/
PYLON V1.3/Goodwe V1.5/SUNGROW V1.3/Solis V1.0/
SOFAR V1.0/Growatt V1.05/Growatt V1.01/Luxpower V1.0/
Sol-Ark V1.2/TBB V1.02/Deye V1.0/LIVOLTEK V1.0/
Sorotec V1.0/MEGAREVO V1.01/Afore V1.0/Sacolar V1.05
RS 485:
PYLON V3.5/DEYE V1.0/SRNE V1.3/Growatt V2.01/
SMKSOLAR V2.01/EPEVER V1.4/Voltronic V1.0
|
|
|
||
|
Products Size(W*D*H)
|
600*1010*210 mm
|
600*1440*220mm
|
600*1870*220mm
|
||
|
Weight
|
140kg
|
205kg
|
270kg
|
||
|
Warranty
|
5Years/10Years(Option)
|
|
|
||
· Rated Power in Watts-Pmax:400~680 Wp · Cell Configuration: 108, 120 Cells · Frame: Silver, Black optional · Warranty:25 Years ·
TOP CON/Tier 1 Bankable Brand
