Quick Details
-
Model Number:
-
hn-506
-
Type:
-
silicone sealant
-
Product name:
-
Silicone Sealant Glue
-
Application:
-
Electronic adhesive sealant transparent adhesive
-
Color:
-
White
-
MOQ:
-
100pcs
-
Keywords:
-
Metal, glass, ceramic, PCB board, plastic
-
Packing:
-
100ml aluminum tube, 310ml, 2600ml plastic tube
-
Shelf life:
-
6 Months
-
Brand:
-
Hanast
-
Delivery time:
-
7-15days
-
Sample:
-
Free(1PCS)
Quick Details
-
CAS No.:
-
68410-45-7
-
Place of Origin:
-
China
-
Brand Name:
-
Hanast
-
Model Number:
-
hn-506
-
Type:
-
silicone sealant
-
Product name:
-
Silicone Sealant Glue
-
Application:
-
Electronic adhesive sealant transparent adhesive
-
Color:
-
White
-
MOQ:
-
100pcs
-
Keywords:
-
Metal, glass, ceramic, PCB board, plastic
-
Packing:
-
100ml aluminum tube, 310ml, 2600ml plastic tube
-
Shelf life:
-
6 Months
-
Brand:
-
Hanast
-
Delivery time:
-
7-15days
-
Sample:
-
Free(1PCS)
Product Description
506 Series One- Component RTV Bond Sealing Silicone Rubber
506 Series One- Component RTV Bond Sealing Silicone Rubber
❆ Product use:
It is widely used for adhesion of electronic components, lighting components, instruments, motors, home appliances and other
equipment, sealing, moisture -proof, shock absorption, and insulation.
❆ Product characteristics:
1. Has excellent adhesion, fixing, sealing, electrical, insulation, moisture -proof, shockproof, sealing, high temperature
resistance, aging resistance and other properties;
2. The hardening silicone RTV silicon rubber can exert the electrical characteristics of the original silicone, and in the
temperature of -50 ℃ ~ 200 ℃, it has a good extension rate (can also maintain its original rubber elasticity) , And have
weather resistance, heat resistance, cold resistance;
3. Excellent adhesion, can have good adhesion with metal, glass, tiles, plastics (except PE, PP) and its alloy;
4. Comply with EU ROHS instructions.
❆ How to use:
According to the amount of dosage, cut the head of the nozzle to the head, and put it with a special syringe (air gun or pistol)
to use it to use it. The room temperature is curing.
❆ Precautions:
1. If you need to obtain the best bonding performance, the surface of the adhesive substrate should be clean, without rust, dust and oil pollution. It can be expressed in the bonding substrate such as water -free ethanol or propane.
2. You can manually or use the dot -glue device to apply it to the substrate that needs to be bonded. The moisture in the exposure of the rubber in the air is solidified from the manifestation to the inside. Their drying and curing speed are related to the environmental temperature and humidity used. The thickness of the glue layer: the thickness of the rubber layer ≤1mm, at the temperature of 25 ± 2 ° C, the relative humidity 50 ± 5 5 Under the conditions of %, it can be put into use for 24 hours. The thicker the glue, the longer the curing time.
3. After the operation is completed, the unused glue should be tightened immediately, the seal is stored, and when it is appropriate again, if there is a little skin at the seal, it can be removed without affecting the normal use. During the storage process, a small amount of solidification or oil analysis may also occur at the mouth of the tube. After removing it,it can be used normally without affecting product performance.
4. Avoid contact with the eyes and skin. If you accidentally contact your eyes during operation, immediately rinse medical rescue with a lot of water. Keeping ventilation in the place of use is limited to industrial journey.
❆ Product packaging
100ml/branch, 310ml/support, 2600ml/support
❆ Storage
1. Store below 30 ° C in a cool and dry place with a storage period of 6 months.
2. Products that exceed the storage period should be confirmed that there are abnormalities before they can be used.
3. Such products are non -dangerous goods and can be transported according to general chemicals.
4.It must be kept secret and be careful of leakage during transportation.
It is widely used for adhesion of electronic components, lighting components, instruments, motors, home appliances and other
equipment, sealing, moisture -proof, shock absorption, and insulation.
❆ Product characteristics:
1. Has excellent adhesion, fixing, sealing, electrical, insulation, moisture -proof, shockproof, sealing, high temperature
resistance, aging resistance and other properties;
2. The hardening silicone RTV silicon rubber can exert the electrical characteristics of the original silicone, and in the
temperature of -50 ℃ ~ 200 ℃, it has a good extension rate (can also maintain its original rubber elasticity) , And have
weather resistance, heat resistance, cold resistance;
3. Excellent adhesion, can have good adhesion with metal, glass, tiles, plastics (except PE, PP) and its alloy;
4. Comply with EU ROHS instructions.
❆ How to use:
According to the amount of dosage, cut the head of the nozzle to the head, and put it with a special syringe (air gun or pistol)
to use it to use it. The room temperature is curing.
❆ Precautions:
1. If you need to obtain the best bonding performance, the surface of the adhesive substrate should be clean, without rust, dust and oil pollution. It can be expressed in the bonding substrate such as water -free ethanol or propane.
2. You can manually or use the dot -glue device to apply it to the substrate that needs to be bonded. The moisture in the exposure of the rubber in the air is solidified from the manifestation to the inside. Their drying and curing speed are related to the environmental temperature and humidity used. The thickness of the glue layer: the thickness of the rubber layer ≤1mm, at the temperature of 25 ± 2 ° C, the relative humidity 50 ± 5 5 Under the conditions of %, it can be put into use for 24 hours. The thicker the glue, the longer the curing time.
3. After the operation is completed, the unused glue should be tightened immediately, the seal is stored, and when it is appropriate again, if there is a little skin at the seal, it can be removed without affecting the normal use. During the storage process, a small amount of solidification or oil analysis may also occur at the mouth of the tube. After removing it,it can be used normally without affecting product performance.
4. Avoid contact with the eyes and skin. If you accidentally contact your eyes during operation, immediately rinse medical rescue with a lot of water. Keeping ventilation in the place of use is limited to industrial journey.
❆ Product packaging
100ml/branch, 310ml/support, 2600ml/support
❆ Storage
1. Store below 30 ° C in a cool and dry place with a storage period of 6 months.
2. Products that exceed the storage period should be confirmed that there are abnormalities before they can be used.
3. Such products are non -dangerous goods and can be transported according to general chemicals.
4.It must be kept secret and be careful of leakage during transportation.
Specification
|
Model
|
HN-506W-1
|
HN-506B-2
|
HN-506W-1
|
HN-506W-2
|
HN-506G-1
|
|
Type
|
Ketoxime RTV
|
Alcohol
RTV |
Ketoxime RTV
|
Alcohol RTV
|
Ketoxime RTV
|
|
Exterior
|
white, flowing
|
black, flowing
|
white, creamy
|
white, semi-fluid
|
grey, semi-fluid
|
|
Viscosity (mPa.S)
|
15000~17000
|
18000~25000
|
-------
|
----------
|
35000~45000
|
|
Specific gravity (25℃)
|
1.0~1.04
|
1.0~1.1
|
1.15~1.2
|
1.25~1.35
|
1.8~2.2
|
|
Surface dry time (min25℃)
|
10~30
|
5~15
|
10~30
|
5~15
|
10~30
|
|
Shore hardness (JISA)
|
25~35
|
20~30
|
40~50
|
40~50
|
50~60
|
|
Elongation at break (%)
|
150~230
|
300~400
|
200~280
|
200~280
|
150~250
|
|
Tensile strength (Kgf/cm2)
|
15~25
|
15~30
|
15~30
|
15~30
|
20~30
|
|
Volume resistivity (Ω.cm)
|
≥3×1014
|
≥3×1014
|
≥3×1014
|
≥3×1014
|
≥3×1014
|
|
Breakdown voltage (kv/mm)
|
18～25
|
18～25
|
18～25
|
18～25
|
18～25
|
|
Positive dielectric loss angle (1MHZ)
|
≤4×10-3
|
≤4×10-3
|
≤4×10-3
|
≤4×10-3
|
≤4×10-3
|
|
High and low temperature resistance (℃)
|
-50℃～250℃
|
-50℃～200℃
|
-50℃～250℃
|
-50℃～200℃
|
-50℃～250℃
|
Packing & Delivery
Aluminum tube + color box + K/A paper dividers + carton box
100 ml is packed in aluminum tube
Both 310 ml and 2600 ml are packaged in plastic tubes
100 ml is packed in aluminum tube
Both 310 ml and 2600 ml are packaged in plastic tubes
