- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
14k
-
Certificate:
-
CE ROHS
-
Product Name:
-
2U class TD 2 channel switching power amplifier
-
8 Ω stereo power:
-
2400W*2
-
4 Ω stereo power:
-
4400W*2
-
2Ω Stereo Power:
-
7000W*2
-
Input connector:
-
female XLR
-
Input impedance:
-
20 k Ω balance
-
THD:
-
20 Hz - 20 kHz for 1 W: <0.1%
-
Damping coefficient:
-
>600
-
Signal Noise Ration:
-
>112dB
Quick Details
-
Warranty:
-
3years
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
oem
-
Model Number:
-
14k
-
Certificate:
-
CE ROHS
-
Product Name:
-
2U class TD 2 channel switching power amplifier
-
8 Ω stereo power:
-
2400W*2
-
4 Ω stereo power:
-
4400W*2
-
2Ω Stereo Power:
-
7000W*2
-
Input connector:
-
female XLR
-
Input impedance:
-
20 k Ω balance
-
THD:
-
20 Hz - 20 kHz for 1 W: <0.1%
-
Damping coefficient:
-
>600
-
Signal Noise Ration:
-
>112dB
Specification
|
ITEM
|
14K
|
|
|
2 channels Class TD switch power Amplifier
8ΩStereo Power(RMS): 2400WX2
4ΩStereo Power(RMS): 4400WX2
2ΩStereo Power(RMS):7000WX2
8ΩBridged Power(RMS): 8800W
4ΩBridged Power(RMS): 14000W
Output Power: 20-20kHz,1W with 1 khz
Frequency Response(+o/-0.3dB,1W/8Ω): 20 Hz - 34 kHz
THD 20 Hz - 20 kHz for 1 W: 112 dB
Channel separation (Crosstalk) at 1 kHz: >70 dB
Input Connectors (per channel): 3-pin XLR, electronically balanced
Output Connectors (per channel): Binding Posts 2-pole
Tour Class Protection: ACL,IGM, Auto Ramp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic
input Operating voltage, 230 V / 115 V nominal: 130-265 V / 65-135 V selectable
Voltage Gain(dB): 23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance: 20 kOhm
Level adjustment (per ch.): Front-panel potentiometer, 31 position detented from -inf to 0 dB
Dimensions(W×H×D): 483×88×396mm,Net weight(kg): 16KG
Packing dimension: 595×145×610mm,Gross weight(kg): 19KG
|
Product Description
