Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
DOSSY
-
Dimension(L*W*H):
-
70x75x60mm
-
Weight:
-
0.3 KG, 0.3KG -0.4KG-0.5KG-0.7KG
-
Working Temperature Range:
-
-45 - 700 ℃
-
Heating element:
-
PTC Resistor - Temperature Limiting
-
Power:
-
15W-150W
-
fitting postion:
-
vertical
-
Operating voltage:
-
120-240V AC/DC (min110V max.265V)
-
Certification:
-
CE
-
Protection class:
-
IP20(double insulated)
-
Operating/storage:
-
Max.90%RH(non-condensing)
-
material:
-
Aluminum Alloy
-
Mounting:
-
35mm Din rail
Quick Details
-
Type:
-
Air Heater
-
Power Source:
-
Electric
-
Voltage:
-
110-220VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
DOSSY
-
Dimension(L*W*H):
-
70x75x60mm
-
Weight:
-
0.3 KG, 0.3KG -0.4KG-0.5KG-0.7KG
-
Working Temperature Range:
-
-45 - 700 ℃
-
Heating element:
-
PTC Resistor - Temperature Limiting
-
Power:
-
15W-150W
-
fitting postion:
-
vertical
-
Operating voltage:
-
120-240V AC/DC (min110V max.265V)
-
Certification:
-
CE
-
Protection class:
-
IP20(double insulated)
-
Operating/storage:
-
Max.90%RH(non-condensing)
-
material:
-
Aluminum Alloy
-
Mounting:
-
35mm Din rail
HG140 Series Fan Heater
(15W/30W/45W/60W/75W/100W/150W)
·What is a Fan heater:
A fan heater is a heater that works by using a fan to pass air over a heat source (e.g. a heating element). This heats up the air, which then leaves the heater, warming up the surrounding room. They can heat an enclosed space such as a room faster than a heater without fan, but, like any fan, create audible noise.
·Where is Fan Heater applied:
1. Pressure clamp connectors
2. Dynamic heating up
3. Wide voltage range
4. Temperature limiting
5. Energy saving
6. Clip fixing
7. Quick installation
·These heaters are used in enclosures where damage from condensation must be prevented, or where the temperature may not fall below a minimum value. The aluminium profile heater body design has a chimney effect and distributes the heat evenly. The pressure clamp connectors save time and simplify installation.
·What is the Futures of Fan Heater?
aluminum profile heater body
simplify installation
PTC resistor, self regulating and temperature limiting
Vertical Fitting
High efficiency, long life and high reliability
1 years warranty
| Operating Voltage | 120-250VAC |
| Heating Element | PTC resistor - temperature limiting |
| Heater body | extruded aluminium profile, anodised |
| Connection |
3 pressure clamps for stranded wire 0.5-1.5mm^2 (with wire and terrule); and rigid wire 0.5-2.5mm^2 |
| Connection casing | plastic according to UL94 V-0, black |
| Mounting | clip for 35mm DIN rail, EN50022 |
| Fitting position | Vertical |
|
Operating /Storage Temperature |
-45 to +70°C (-49 to +158°F) |
| Protection type/Class | IP20/ I (earthed) |
| Certification | CE |
·Specification
| P/N | Type |
Heating Capacity |
Inrush current max. (A) |
Pre-fuse T (time-delay) (A) |
Length (mm)(L) |
Weight ( Approx. kg) |
| DS-HG1 | HG140 | 15W | 1.5 | 1 | 65 | 0.3 |
| DS-HG2 | HG140 | 30W | 3 | 2.5 | 65 | 0.3 |
| DS-HG3 | HG140 | 45W | 3.5 | 2.5 | 65 | 0.3 |
| DS-HG4 | HG140 | 60W | 2.5 | 2.5 | 140 | 0.4 |
| DS-HG5 | HG140 | 75W | 4 | 4 | 140 | 0.5 |
| DS-HG6 | HG140 | 100W | 4.5 | 4 | 140 | 0.5 |
| DS-HG7 | HG140 | 150W | 9 | 6.3 | 220 | 0.7 |
·Size
·Connection Drawing
