Main parameters
|
FL704-1
|
|
Engine Type
|
QC4108T70
|
|
Max. Torque (Nm @ engine rpm)
|
(265~275)@1700
|
|
Displacement (L)
|
4.324
|
|
Fuel tank capacity (L)
|
70L/90L
|
|
Rating power of engine
|
51.5/2400
|
|
Fuel consumption @ nominal power
|
≤248
|
|
Air Intake Type
|
Natually-Aspirated
|
|
N / Displacement
|
4/4.324
|
|
No. of gears
|
12F+12R
|
|
Shift method
|
Sliding sleeve/Synchronizer
|
|
Max. speed
|
33.59km/h
|
|
Gear position
|
Command aside
|
|
PTO Speed
|
540/760rpm
540/1000rpm(Optional)
|
|
The whole machine size (dimensions) mm
|
4064×1828×2200(ROPS)
4050×1828×2654(CABIN)
|
|
Min. operation mass (kg)
|
2400(ROPS)
2870(CABIN)
|
|
Mini turning Radius (m)
|
4.5
|
|
Rated traction force(KN)
|
16.5
|
|
Deck
|
Flat Deck
|
|
Wheelbase(mm)
|
2071
|
|
Minimum ground clearance(mm)
|
370
|
|
Front/rear wheel track
|
1350/1450
|
|
Tyre size
|
8.3-24/14.9-30
|
|
Steering type
|
Hydraulic steering
|
|
Steering Angle (4 x4)
|
34°
|
