Quick Details
-
Type:
-
Fishing engine
-
Volts/Power Rated:
-
DC24V/2520W
-
Amp-Rated:
-
105A
-
Shaft Power:
-
5HP
-
Comparable petrol outboards(thrust):
-
6HP
-
Speed (FWD / REV):
-
Stepless speed control
-
Prop Type/Size:
-
3 blade prop/10.7 inch diamete
-
Prop Speed at full power:
-
Max.1450 rpm. underwater
-
Shaft Length:
-
800mm
-
Weight (N.W):
-
15.7kg
-
Battery Type(Suggestion):
-
2X120AH deep cycle battery(not incl
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HASWING
-
Model Number:
-
50752-80_B
-
Type:
-
Fishing engine
-
Volts/Power Rated:
-
DC24V/2520W
-
Amp-Rated:
-
105A
-
Shaft Power:
-
5HP
-
Comparable petrol outboards(thrust):
-
6HP
-
Speed (FWD / REV):
-
Stepless speed control
-
Prop Type/Size:
-
3 blade prop/10.7 inch diamete
-
Prop Speed at full power:
-
Max.1450 rpm. underwater
-
Shaft Length:
-
800mm
-
Weight (N.W):
-
15.7kg
-
Battery Type(Suggestion):
-
2X120AH deep cycle battery(not incl
|
Voltage — Rated/Max |
24V |
|
Power — Rated / Max |
2520W |
|
Static Thrust (Lb/Kg) |
160LBS |
|
Amp — Rated / Max |
105A |
|
Prop Type/Size |
Three-blade prop,/10.7inch |
|
Decibel level (Db) |
≤ 55dB |
|
Prop Speed at full power |
1450rpm underwater |
|
Shaft Type |
S tainless S teel + Aluminum |
|
Depth Adjustment |
Not Available |
|
Shaft t ype (inch / mm) |
800mm |
|
Steering |
Steering Angle -45° ~ +45° |
|
Control Type |
Steering Wheel Control |
|
Driving Type |
Stepless forward/reverse |
|
Total Height |
1170mm |
|
Waterproofing grade |
IP67 |
|
|
|
|
Motor |
Brushless Motor |
|||
|
Thrust in HP |
Comparable petrol outboards: 6HP |
|||
|
B attery type (Suggestion) |
2X120Ah Deep Cycle Battery |
|||
|
Max boat length |
(Suggestion) 8M |
|||
