Quick Details
-
Brand Name:
-
LNA
-
Model Number:
-
LNA_G200
-
Engine:
-
200cc
-
Drive Mode:
-
Chain
-
Wheel Size:
-
21*7-12 / 22*10-12
-
Oil Tank Capacity:
-
12L
-
Maximum Speed:
-
75-95 km/h
-
Displacement:
-
200cc
-
Brake Type:
-
Hydraulic disk brake
-
Model Name:
-
G200
-
Dimensions:
-
2530*1457*1426mm
-
Wheelbase:
-
1980mm
-
Drive:
-
Chain
-
Clutch:
-
Automatic
-
Brake:
-
Hydraulic Disc Brake
-
Engine type:
-
4 Stroke
-
Weight:
-
385kg
-
Seatbelt:
-
Sport seatbelts
-
Colors:
-
Customized
Quick Details
-
Type:
-
Pedal Go Karts
-
Engine Capacity:
-
50-200CC
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
LNA
-
Model Number:
-
LNA_G200
-
Engine:
-
200cc
-
Drive Mode:
-
Chain
-
Wheel Size:
-
21*7-12 / 22*10-12
-
Oil Tank Capacity:
-
12L
-
Maximum Speed:
-
75-95 km/h
-
Displacement:
-
200cc
-
Brake Type:
-
Hydraulic disk brake
-
Model Name:
-
G200
-
Dimensions:
-
2530*1457*1426mm
-
Wheelbase:
-
1980mm
-
Drive:
-
Chain
-
Clutch:
-
Automatic
-
Brake:
-
Hydraulic Disc Brake
-
Engine type:
-
4 Stroke
-
Weight:
-
385kg
-
Seatbelt:
-
Sport seatbelts
-
Colors:
-
Customized
Product Description
Specification
|
Model Number
|
LNA-G200
|
Engine
|
200cc
|
|
Size
|
2530*1457*1426mm
|
Top speed
|
75km/h
|
|
Clutch
|
Automatic
|
Start
|
Electric
|
|
Wheelbase
|
1980mm
|
Cooling
|
Oil cooled
|
|
Weight
|
345kg
|
Max weight load
|
200-300kg
|
|
Front track
|
278
|
Rear track
|
177
|
|
Battery
|
12v,12AH
|
Fuel Tank
|
12L
|
|
Brake
|
Hydraulic Disc Brake
|
Front wheel
|
21*7-12
|
|
Rear wheel
|
22*10-12
|
Minimum turning radius
|
3.5m
|
|
Color
|
Black,Green,Red etc
|
Packing size
|
2300*1460*865mm
|
|
Engine model
|
xy170mm-k
|
Clearance
|
285mm
|
|
Engine type
|
4 stroke
|
Acrot orque
|
17nm/5000rpm
|
|
Cylinder diameter,stroke
|
70*66.8mm
|
Power
|
12.5kw
|
|
Compression ratio
|
9:1
|
|
|
Detailed Pictures
Roomy Driver Seat
The roomy driver-seat provides spacious space for the riders even you are tall and strong ,the knees and legs will be comfortable when drive.
Electric start and Lights
Full Lights and switches including steering lights and brake light etc.
The Sport Styling Seats
The sport styling seaters with 5-points seat belts,it provides much more safety when drive.
Automatic engine
Close-up picture of the engine, automatic with oil cooled
Hydraulic Disc Brake
Brake is important,we use Hydraulic Discs only
The Roomy driving seat
The roomy driving seat fits most any sizes drivers
Forward and Backward Avail Seater
The seat able to adjust forward and backward
Certifications
Product packaging
Packing Picture
The packing is made by steel frame with carbon box and covered by plastic. strong enough for the transport.
