Quick Details
-
Feed Mechanism:
-
Compound Feed
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Good Time
-
Power:
-
750W
-
Overall Dimensions:
-
120X120X110cm
-
Weight (KG):
-
379 KG
-
Keywords:
-
Shoe Sewing Machine
-
Product name:
-
Portable Bag Closer Sewing Machine
-
Suitable for:
-
Leather Bag Shoes Wallets
-
Application:
-
Clothing Shoes Handbag
-
Key words:
-
Leather Car Seats
-
Function:
-
Glove Stitching Glove Sewing
-
Usage:
-
Cotton Glove Leather Glove Sewing Machine
-
Sewing machine name:
-
Lockstich Sewing Machine
-
Motor:
-
AC Servo Motor 750W
-
Characteristics:
-
Operation High Speed
Quick Details
-
Type:
-
Industrial Sewing Machine
-
Max. Sewing Thickness:
-
17mm
-
Stitch Length:
-
0.1-12.7
-
Feed Mechanism:
-
Compound Feed
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Good Time
-
Power:
-
750W
-
Overall Dimensions:
-
120X120X110cm
-
Weight (KG):
-
379 KG
-
Keywords:
-
Shoe Sewing Machine
-
Product name:
-
Portable Bag Closer Sewing Machine
-
Suitable for:
-
Leather Bag Shoes Wallets
-
Application:
-
Clothing Shoes Handbag
-
Key words:
-
Leather Car Seats
-
Function:
-
Glove Stitching Glove Sewing
-
Usage:
-
Cotton Glove Leather Glove Sewing Machine
-
Sewing machine name:
-
Lockstich Sewing Machine
-
Motor:
-
AC Servo Motor 750W
-
Characteristics:
-
Operation High Speed
1. Exquisite sewing, reliable floriation sewing.
2. Large, high-visibility, easy-to- use LCD touch-type operation panel.
3. Powerful needle penetration force. Low power consumption and economical.
4. A programmable presser foot height function is incorporated. Skipped stitches and thread breakage can be prevented by changing the presser foot height according to the material thickness.
5. Feedback for the XY mechanism is incorporated to realize;
High-speed 2500rpm intermittent feed sewing ;
working time has been reduced by 20% compared to the conventional models.
Technical Specifications:
|
Sewing rang : |
400mm X 300mm |
|
Sewing speed : |
2500rpm/min (intermittent feed 3.0mm ) |
|
Work holder lift : |
25mm (max:30mm) |
|
Stepping foot lift : |
20mm |
|
Stepping foot stoke : |
4mm(0.1mm-10mm Optional) |
|
Hook : |
Double size rotary hook |
|
Memory figure number : |
Max: 99999 |
|
Memory count : |
Each pattern 20,000 needles. |
|
Needle : |
DP*17 (#16 - #24) |
|
Stitch type : |
single needle lock stitch |
|
Operation screen : |
7 inch LCD touch control panel |
|
Sewing thickness : |
≤ 80 mm |
|
Motor: |
750W direct drive servo motor |
|
Voltage : |
Single-phase 220-240V |
|
Memory device : |
USB |
|
Weight : |
200kgs |
Exquisite sewing, reliable beautifull sewing.
Large, high-visibility, easy-to- use LCD touch-type operation panel.
A programmable presser foot height function is incorporated. Skipped stitches and thread breakage can be prevented by changing the presser foot height according to the material thickness.
