Quick Details
-
Model Number:
-
ceramic seal parts
-
Product name:
-
Silicon carbide sealing ring
-
Color:
-
Black
-
Density:
-
3.05-3.2 g/cm3
-
Material:
-
Silicon Carbide
-
Application:
-
Industry Ceramic
-
Feature:
-
High Temperature Resistance
-
Advantage:
-
Long Working Life
-
Standard or Nonstandard:
-
Customizable Acceptable
-
MOQ:
-
2 PCS
-
OEM:
-
Accpetable
Quick Details
-
Size:
-
Customize according to drawings
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Yangzhou Dongbao
-
Model Number:
-
ceramic seal parts
-
Product name:
-
Silicon carbide sealing ring
-
Color:
-
Black
-
Density:
-
3.05-3.2 g/cm3
-
Material:
-
Silicon Carbide
-
Application:
-
Industry Ceramic
-
Feature:
-
High Temperature Resistance
-
Advantage:
-
Long Working Life
-
Standard or Nonstandard:
-
Customizable Acceptable
-
MOQ:
-
2 PCS
-
OEM:
-
Accpetable
Product Description
Technical Specification
|
Properties
|
Conditions
|
Units
|
DB101(RBSiC)
|
DB102(SSiC)
|
|
Density
|
－
|
g/cm3
|
3.05
|
3.12
|
|
Rockwell Hardness
|
－
|
HRA
|
90.4
|
95.3
|
|
Modulus of Elasticity
|
－
|
GPa
|
367
|
418
|
|
Bending Strength
|
3 point
|
－
|
387
|
401
|
|
Compression Strength
|
－
|
MPa
|
2097
|
2206
|
|
Thermal Coefficient
|
25℃
|
W/(M.K)
|
164
|
119
|
|
Thermal Expansion Coefficient
|
25-1000℃
|
1×10-6/℃
|
4.3
|
4
|
|
Silicon Carbide
|
－
|
%
|
≥90
|
<10
|
|
Free-Silicon
|
－
|
%
|
≥98
|
－
|
Product Features:
• The precision seal ring is made of high quality materials by an advanced process with several patented technologies
• The seal ring has a very complicated shapes, high accuracy, stable mechanic properties
• It has much higher wear and corrosion resistance properties, and a service life of more than twenty thousand hours in the normal case
• The precision seal ring is made of high quality materials by an advanced process with several patented technologies
• The seal ring has a very complicated shapes, high accuracy, stable mechanic properties
• It has much higher wear and corrosion resistance properties, and a service life of more than twenty thousand hours in the normal case
Notice: In addition to the regular size, we can also supple the products according to customer’s drawings, samples and performance requirement. Please tell us your needs freely.
