Quick Details
-
Drilling capacity:
-
32mm
-
Spindle Speed Range:
-
115-1700 r.pm
-
Table size:
-
800x240mm
-
Weight:
-
360kg
-
Face milling cutter diameter:
-
63mm
-
End mill diameter:
-
20mm
-
Spindle travel:
-
130mm
Quick Details
-
Range of Spindle Speed(r.p.m):
-
115 - 1700
-
Place of Origin:
-
Shandong, China
-
Keyword:
-
Milling Machine Manual
-
Drilling capacity:
-
32mm
-
Spindle Speed Range:
-
115-1700 r.pm
-
Table size:
-
800x240mm
-
Weight:
-
360kg
-
Face milling cutter diameter:
-
63mm
-
End mill diameter:
-
20mm
-
Spindle travel:
-
130mm
|
Specification |
ZAY7025FG |
ZAY7032FG |
ZAY7040FG |
ZAY7045FG |
|
Maximum drilling diameter |
25mm |
32mm |
40mm |
45mm |
|
Maximum face milling cutter diameter |
63mm |
63mm |
80mm |
80mm |
|
Maximum end mill diameter |
20mm |
20mm |
32mm |
32mm |
|
Maximum distance from the spindle end to the table |
445mm |
450mm |
450mm |
450mm |
|
Minimum distance from spindle axis to column surface |
203mm |
260mm |
260mm |
260mm |
|
Spindle travel |
85mm |
130mm |
130mm |
130mm |
|
Spindle taper |
M.T.3 or R8 |
M.T.3 or R8 |
M.T.4 or R8 |
M.T.4 or R8 |
|
Spindle speed range 50Hz |
95-1420 r.p.m |
80-1250 r.p.m |
80-1250 r.p.m |
80-1250 r.p.m |
|
60Hz |
115-1700 r.p.m |
95-1500 r.p.m |
95-1500 r.p.m |
95-1500 r.p.m |
|
Headstock swivel angle (horizontal / vertical) |
90° |
90° |
90° |
90° |
|
Workbench area |
520×160mm |
800×240mm |
800×240mm |
800×240mm |
|
Worktable front and rear stroke |
140mm |
175mm |
175mm |
175mm |
|
Motor Power |
0.37KW |
0.75KW(1HP) |
1.1KW(1.5HP) |
1.5KW(2HP) |
|
Net weight / gross weight |
180kg/240kg |
320kg/370kg |
323kg/373kg |
325kg/375kg |
|
Package dimensions |
680×750×1000mm |
770×880×1160mm |
770×880×1160mm |
770×880×1160mm |
