High Strength Thread Locking Adhesive & Sealant for Product Category

263 is a single component, high strength, thixotropic viscosity, anaerobic thread locking and sealant. This product cures when isolated from air between two closely fitting metals. Typical application
It is mainly used for locking and sealing of permanent thread. Excellent resistance to chemical solvents. Suitable thread types less than M25. Typical performance
Typical value range test criteria
Chemical composition methacrylate diester
Exterior red
Viscosity (mPa.s@25℃) Brookfield-RVT
Rotor 3 1800 1200-2400 GB/T2794-1995
Specific gravity (@25℃) 1.1 1.00-1.15GB /T13354-1992
Maximum filling gap (mm) 0.13
Failure torque (N.m) 22 16-32 GB/T18747.1-2002
Average torque (N.m) 33 30-40
Operating temperature (℃) -54-149
Initial setting time (min@25℃) 15 10-20
Full solidification time (h@25℃) 24
Instructions for use:
In order to achieve the best locking effect, the coated surface should be free of oil and dust, and ensure that the glue is filled with the entire mesh gap.
For through holes, apply a few drops of glue to the part where the thread engages with the hole.
For blind holes, apply a few drops of glue to the inner thread of the hole to the bottom.
For sealing, apply a circle of 360 ° C glue on the main thread. Keep the first thread free of glue. Push it into the threaded hole. For large threads and holes, adjust the amount of glue and apply a circle of glue to the thread. Do not move until sufficient assembly strength has been achieved. Matters needing attention
This product cannot be used in pure oxygen or oxygen enriched systems. Nor can it be used to store substances with strong oxidation such as chlorine gas.
