1400℃ nickel-chromium heating wire
SUS316L stainless steel heating tube
SUS304 stainless steel water pipe
AL99.90 aluminum alloy
By extra high pressure die-casting process
With fine shot-blasting process for surface treatment
To guarantee:
Complete water-electricity separation to avoid electric leakage
No limescale generation at any kind of water supply
Heat efficiency: ≥ 92%
Hot water output: 4 - 6s
Pressure resistant: ≥ 0.8MPa
Long lifespan: ≥ 8 years
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
HANNOVER
-
Model Number:
-
LF3
-
Power (W):
-
6500W/7500W/8500W
-
Voltage (V):
-
220-240V, 50/60Hz
-
Capacity:
-
Instant / Tankless
-
Heat efficiency:
-
≥ 92%
-
Hot water output:
-
4-6s
-
Starting flow rate:
-
≥ 1.2L/min
-
Hot water temperature:
-
32 - 55℃
-
Precise constant temperature control:
-
+/- 0.5℃ during whole course of bathing
-
Heating element:
-
aluminum alloy
-
Material:
-
tempering glass and ABS
-
Long lifespan:
-
≥ 8 years
-
Advantage:
-
Built-in 5G chip, equilibrium temperature, intelligent heating
-
Operation mode:
-
Electronic touch panel
Quick Details
-
Warranty:
-
1 Year
-
Application:
-
Hotel, Commercial, Household
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HANNOVER
-
Model Number:
-
LF3
-
Power (W):
-
6500W/7500W/8500W
-
Voltage (V):
-
220-240V, 50/60Hz
-
Capacity:
-
Instant / Tankless
-
Heat efficiency:
-
≥ 92%
-
Hot water output:
-
4-6s
-
Starting flow rate:
-
≥ 1.2L/min
-
Hot water temperature:
-
32 - 55℃
-
Precise constant temperature control:
-
+/- 0.5℃ during whole course of bathing
-
Heating element:
-
aluminum alloy
-
Material:
-
tempering glass and ABS
-
Long lifespan:
-
≥ 8 years
-
Advantage:
-
Built-in 5G chip, equilibrium temperature, intelligent heating
-
Operation mode:
-
Electronic touch panel
Product Features
|
TECHNICAL SPECIFICATION
|
|
|
|
|
||||
|
Model No.
|
|
LF3 Offer On-demand Water heating Instant water heater
|
|
|
||||
|
Rated voltage
|
|
220 - 240V~ 50/60Hz
|
|
|
||||
|
Rated power
|
|
6500W / 7500W / 8500W
|
|
|
||||
|
Rated water pressure
|
|
0.03-0.6MPa
|
|
|
||||
|
Heating element
|
|
Patented aluminum die-cast heating plate
|
|
|
||||
|
Cover
|
|
Tempered glass
|
|
|
||||
|
Operation mode
|
|
Rotary knob
|
|
|
||||
|
Hot water temperature
|
|
Normal ~ 55℃
|
|
|
||||
|
Hot water capacity
|
|
Endless
|
|
|
||||
|
Protection against electric shock
|
|
Class 1
|
|
|
||||
|
Degree of ingress protection
|
|
IPX4
|
|
|
||||
|
Starting flow rate
|
|
1.2 L/min.
|
|
|
||||
|
Hot water flow rate
|
|
6 - 8 L/min. (1.6 - 2.1 GPM)
|
|
|
||||
|
Product size
|
|
230mm x 350mm x 60mm (L x H x T)
|
|
|
||||
|
Gross weight
|
|
5.8kg
|
|
|
||||
|
Heat efficiency
|
|
≥ 92%
|
|
|
||||
|
Hot water output
|
|
4 - 6s
|
|
|
||||
|
Pressure resistant
|
|
≥ 0.8MPa
|
|
|
||||
|
Long lifespan
|
|
≥ 8 years
|
|
|
||||
|
Application
|
|
Apartment, office, hotel, school, hospital, hair salon etc.
|
|
|
||||
|
Water inlet
|
|
Bottom inlet / Side inlet / Up inlet
|
|
|
||||
|
Inlet/outlet connection
|
|
G 1/2 BSP, pure brass connector
|
|
|
||||
|
Installation
|
|
Wall mounted
|
|
|
||||
|
Installation method
|
|
Concealed / Unconcealed
|
|
|
||||
|
Compatibility
|
|
Compatible to solar system or central heating system
|
|
|
||||
Products Description
Offer
On-demand
Water heating
Digital microprocessor
Patented 5G smart chip
Automatic power regulation
Automatic constant temperature
Patented 5G smart chip
Automatic power regulation
Automatic constant temperature
Genuine materials and state-of-the-art technology:
