Quick Details
-
Warranty(Year):
-
2-Year
-
Color Temperature(CCT):
-
2700K-8500K
-
Product Weight（kg）:
-
0.2
-
Lamp Luminous Flux(lm):
-
1800LM(18W)
-
CRI (Ra>):
-
80
-
Working Lifetime(Hour):
-
30000
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
TIMPLE
-
Model Number:
-
TP-PL
-
Product Name:
-
LED panel light
-
Dimensions:
-
101*30mm/116*30mm/145*30mm/195*32mm/220mm*32
-
Hole Size:
-
65mm/80mm/105mm/125mm/140mm/175mm
-
Power:
-
5W 9W 12W 15W 18W 24W 32w
-
CCT:
-
2700-7000K
-
Luminous flux:
-
480lm-3200lm
-
Driver:
-
Inner DOB Linear IC
-
Certs:
-
CE, ERP(Energy class E),ROHS
-
Warranty:
-
3 years
-
Color:
-
White Color
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
100
-
Application:
-
RESIDENTIAL
-
Lamp Body Material:
-
Plastic
-
Warranty(Year):
-
2-Year
-
Color Temperature(CCT):
-
2700K-8500K
-
Product Weight（kg）:
-
0.2
-
Lamp Luminous Flux(lm):
-
1800LM(18W)
-
CRI (Ra>):
-
80
-
Working Lifetime(Hour):
-
30000
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
TIMPLE
-
Model Number:
-
TP-PL
-
Product Name:
-
LED panel light
-
Dimensions:
-
101*30mm/116*30mm/145*30mm/195*32mm/220mm*32
-
Hole Size:
-
65mm/80mm/105mm/125mm/140mm/175mm
-
Power:
-
5W 9W 12W 15W 18W 24W 32w
-
CCT:
-
2700-7000K
-
Luminous flux:
-
480lm-3200lm
-
Driver:
-
Inner DOB Linear IC
-
Certs:
-
CE, ERP(Energy class E),ROHS
-
Warranty:
-
3 years
-
Color:
-
White Color
Product Description
Detailed Images
Plastic housing
PBT material panel housing, making the cost lower. Excellent mold brings Unique and exquisite appearance.
PCB and LED chips
International standard aluminium material for PCB board and brings excellent heat releaseing.
San'an chips brings stand abd high performance.
Driver
Standard glass fiber board
Top brand components, like Yunxing capacitor, BP ic, etc
Advanced design
Excellent soldering
Skillful assembly
All of these factors make the lamp quality good and stable
Product Presentation
|
Product Name
|
LED panel round slim
|
|
Material
|
PBT Housing + Aluminium PCB inside
|
|
Power
|
5w/8w/12w/18w/24w
|
|
Voltage
|
180-260v
|
|
Type of Lamp-house
|
Plastic housing
|
|
Model
|
TPSR
|
|
Style
|
Triditional
|
-
Size introduction
|
Power
|
Lumen
|
CCT
|
Voltage(V)
|
Size(mm)
|
Install hole(mm)
|
|
5W
|
380lm
|
3000-6500K
|
180-265
|
Φ92
|
65
|
|
8W
|
480lm
|
3000-6500K
|
180-265
|
Φ104
|
80
|
|
12W
|
1050lm
|
3000-6500K
|
180-265
|
Φ148
|
105
|
|
18W
|
1400lm
|
3000-6500K
|
180-265
|
Φ172
|
140
|
|
24W
|
1920lm
|
3000-6500K
|
180-265
|
Φ225
|
170
|
|
32W
|
2600lm
|
3000-6500K
|
180-265
|
Φ225
|
170
|
