"CHONGQING WOIDEAL SPECIAL VEHICLE CO., LTD." was founded in March 2016. The company's main business is R&DIMP&EXP sales of the components for motorcycles, snowmobles, ATVs, tricycles and other special vehicles. Especially onsnowmobile R&D and sales, our company is the forerunner in China.
These years, WOlDEAL company provided our customers with stable quality products and excellent after-sales serviceEspecially in 2017 and 2018, we have launched two new models one after another, the WD150 and the WD300 with independentintellectual properly rights. With their brand-new appearance design and excellent product performance, they have wonunanimous recognition and praise from domestic and foreign customers, and set off a new wave of snowmobiles.Till now, WOlDEAL had sold more than 30000 units snowmobiles and the export volume exceeded 45 milion dollars. Our mainmarket is Canada, Russia and Nordics.
Nowadays, WOlDEAL is the biggest supplier and R&D company of snowmobile industry in China!
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Master Transmission Type:
-
Chain, type SC302 (Pitch 9.525 mm), 86 section
-
Track Type:
-
Rubber, Reinforced
-
Track Width:
-
380 mm
-
Track Length:
-
3285 mm, 45 teeth
-
Starting acceleration capability:
-
≤10S (100 m)
-
consumption of fuel (L/100km):
-
10.5
-
Carburation:
-
EFI
-
40' HC:
-
16 units
Quick Details
-
Displacement:
-
292.4cc
-
Brand Name:
-
fomen
-
Dimension:
-
2960*1200*1235mm
-
Place of Origin:
-
Zhejiang, China
-
Master Transmission Type:
-
Chain, type SC302 (Pitch 9.525 mm), 86 section
-
Track Type:
-
Rubber, Reinforced
-
Track Width:
-
380 mm
-
Track Length:
-
3285 mm, 45 teeth
-
Starting acceleration capability:
-
≤10S (100 m)
-
consumption of fuel (L/100km):
-
10.5
-
Carburation:
-
EFI
-
40' HC:
-
16 units
Products Description
FEATURES
Pictures
Products Detais
Product Specifications
|
Engine
|
|
|
|
|
||||
|
Engine Type
|
Single, 4 Stroke, Water Cooling, SOHC
|
|
Max Power
|
18.3 KW / 24.54 HP (at 8500 r/m)
|
||||
|
Max Torque
|
24.5 N·M (at 7000 r/m)
|
|
Carburation
|
EFI
|
||||
|
Engine Displacement
|
292.4 cm3
|
|
Bore × Stroke
|
78 × 61.2 mm
|
||||
|
Clutch Type
|
CVT, with Independent Reverse gear
|
|
Shift Pattern
|
Electronic Reverse gear
|
||||
|
Starting System
|
Electric, with hand-pull starter
|
|
Fuel Tank Capacity
|
27 Liter
|
||||
|
Wheel brake
|
|
|
|
|
||||
|
Dimensions (L × W × H)
|
2960 × 1200 × 1235 (mm)
|
|
Seat Height
|
745 (mm)
|
||||
|
Net Weight
|
235 KG
|
|
Front Suspension
|
Aluminum Alloy Steering Knuckle, Independent Double A-shape Swing Arm
|
||||
|
Max Front Suspension Stroke
|
155 mm
|
|
Brake System
|
Hydraulic
|
||||
|
Master Transmission Type
|
Chain, type SC302 (Pitch 9.525 mm), 86 section
|
|
Propeller
|
Rubber Track With Front Driving Wheel
|
||||
|
Suspension
|
|
|
|
|
||||
|
Track Type
|
Rubber, Reinforced
|
|
Track Width
|
380 mm
|
||||
|
Track Length
|
3285 mm, 45 teeth
|
|
Climbing Ability
|
30˚
|
||||
|
Max Load
|
175 KG
|
|
Max Speed
|
65 km/h
|
||||
