Quick Details
-
Brand Name:
-
STUAA
-
Product Name:
-
Carrying RGV
-
Application:
-
Transfer Materials
-
Type:
-
Atuomatic
-
Usage:
-
Heavy Duty
-
After-sales Service Provided:
-
Online Support
-
Name:
-
Electric Trolley
-
Key Words:
-
Warehouse RGV Car
-
Material:
-
Steel
-
Function:
-
Conveying Goods
-
Advantage:
-
High Efficiency
Quick Details
-
Warranty:
-
1 Year
-
Weight (KG):
-
430
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
STUAA
-
Product Name:
-
Carrying RGV
-
Application:
-
Transfer Materials
-
Type:
-
Atuomatic
-
Usage:
-
Heavy Duty
-
After-sales Service Provided:
-
Online Support
-
Name:
-
Electric Trolley
-
Key Words:
-
Warehouse RGV Car
-
Material:
-
Steel
-
Function:
-
Conveying Goods
-
Advantage:
-
High Efficiency
AGV logistics trolley, also known as AGV logistics handling robot, can achieve straight line walking, left and right turn, in situ rotation (turn around), there are a wide range of applications in industry, such as: machinery processing plants, textile factories, food factories, warehouse transfer, etc.
At present, our company can standardize the mass production of AGV logistics trolleys with a bearing capacity of 1 ton, 3 tons and 30 tons, and we can also customize AGV logistics trolleys according to specific needs.
Our company produces AGV trolley has 3 kinds of navigation, one is laser navigation, two is magnetic stripe navigation, three is two-dimensional code navigation. Laser navigation, used in the factory environment is not much change occasions, if the factory environment changes too much, AGV will not be able to identify the road conditions, thus reducing the utilization rate of AGV trolley; magnetic strip navigation, for the ground in the factory laid magnetic strip, AGV through its own magnetic sensors and wireless network control for movement, less affected by the outside world, widely used; two-dimensional code navigation, the use of its own recognition of two-dimensional code function and factory Wireless network control, movement, less affected by the outside world, widely used.
At present, our company can standardize the mass production of AGV logistics trolleys with a bearing capacity of 1 ton, 3 tons and 30 tons, and we can also customize AGV logistics trolleys according to specific needs.
Our company produces AGV trolley has 3 kinds of navigation, one is laser navigation, two is magnetic stripe navigation, three is two-dimensional code navigation. Laser navigation, used in the factory environment is not much change occasions, if the factory environment changes too much, AGV will not be able to identify the road conditions, thus reducing the utilization rate of AGV trolley; magnetic strip navigation, for the ground in the factory laid magnetic strip, AGV through its own magnetic sensors and wireless network control for movement, less affected by the outside world, widely used; two-dimensional code navigation, the use of its own recognition of two-dimensional code function and factory Wireless network control, movement, less affected by the outside world, widely used.
1. The purchaser must specify the weight (with or without pallets) and size of the products to be transferred.
2. The purchaser shall provide a road map of the operation of the AGV (with examples of the road map below), with video or photos of the AGV operation road (the supplier relies on the photos or videos to determine whether there is a risk of off-loading in the middle of the operation); if there are special sections, such as slopes, the length and slope of the slope and photos shall be provided (the supplier relies on the data and photos to determine whether there is a risk of the AGV chassis being scratched).(risk). The operation path must be clear, from the pickup place to the destination, how many times a day it needs to turn around, and how much the distance is, these three issues determine the area covered by the LAN and the time beat operation.
3. It is recommended that the purchaser purchase two charging piles (determined by the purchaser) to prevent running out of power midway and making charging difficult (AGVs have no power and are difficult to push and need to be charged with forklifts and other consignments).
4. Whether the pallet of AGV is provided by the buyer or the supplier must be clear.
2. The purchaser shall provide a road map of the operation of the AGV (with examples of the road map below), with video or photos of the AGV operation road (the supplier relies on the photos or videos to determine whether there is a risk of off-loading in the middle of the operation); if there are special sections, such as slopes, the length and slope of the slope and photos shall be provided (the supplier relies on the data and photos to determine whether there is a risk of the AGV chassis being scratched).(risk). The operation path must be clear, from the pickup place to the destination, how many times a day it needs to turn around, and how much the distance is, these three issues determine the area covered by the LAN and the time beat operation.
3. It is recommended that the purchaser purchase two charging piles (determined by the purchaser) to prevent running out of power midway and making charging difficult (AGVs have no power and are difficult to push and need to be charged with forklifts and other consignments).
4. Whether the pallet of AGV is provided by the buyer or the supplier must be clear.
|
STUAA 1T heavy-duty AGV performance parameters table
|
|
|
|
|
|
|||||
|
Working Environment
|
|
Indoor and outdoor, temperature 0℃-45℃, humidity 20%-85%
|
|
Walking style
|
Forward, backward, left and right turn/spin in place
|
|||||
|
Basic parameters
|
type
|
1T heavy-duty handling robot
|
|
Drive method
|
Servo/differential drive
|
|||||
|
|
Dimension (length)
|
1150mm
|
|
Rated running speed (no load) (m/s
|
0.2-2
|
|||||
|
|
Dimension (width)
|
820mm
|
|
Rated running speed (full load) (m/s)
|
0.2-1.8
|
|||||
|
|
Dimension (height)
|
256mm
|
|
Maximum running speed (no load) (m/s)
|
0.8
|
|||||
|
|
Lifting table size
|
1030×770
|
|
Maximum running speed (full load) (m/s)
|
0.8
|
|||||
|
|
Carrying capacity
|
1T-AGV
|
|
Stable running speed (no load) (m/s)
|
1
|
|||||
|
|
Chassis height from the ground
|
25mm
|
|
Stable running speed (full load) (m/s)
|
0.5
|
|||||
|
|
Lifting height
|
60mm
|
|
Maximum acceleration (no load) (m/s^2)
|
0.25
|
|||||
|
|
Equipment weight
|
185KG
|
|
Maximum acceleration (full load) (m/s^2)
|
0.14
|
|||||
|
|
Navigation
|
QR code navigation / laser navigation / magnetic navigation
|
|
Maximum climbing (full/no load)
|
3
|
|||||
|
|
Navigation and positioning accuracy
|
±10mm
|
|
Barrier crossing capability (full/no load)（mm）
|
5
|
|||||
|
|
Positioning method
|
QR code navigation / laser navigation / magnetic navigation
|
|
Trench crossing capacity (full load/no load)（mm）
|
8
|
|||||
|
|
Wheel diameter
|
Φ350mm
|
|
Traveling adjustable angle positioning accuracy
|
±1°
|
|||||
|
|
Single wheel carrying capacity
|
0.5T
|
|
Traveling adjustable position positioning accuracy
|
±10mm
|
|||||
|
|
Number of rounds
|
2
|
|
Lifting and lowering adjustable precision
|
±1mmm
|
|||||
|
|
Type of suspension/self-erection
|
Hydraulic independent type / electric
|
|
Minimum turning radius
|
1.2m
|
|||||
|
|
Maximum pressure on the ground
|
8Mpa
|
|
Maximum pressure on the ground
|
8Mpa
|
|||||
|
|
Motor type
|
DC servo motor
|
|
Hanging
|
Spring/hydraulic independent type
|
|||||
|
|
Number of drive motors
|
2
|
|
Adaptation to the ground
|
Concrete, self-leveling, asphalt, steel plate floors
|
|||||
|
|
Battery Type
|
Lithium iron phosphate batteries
|
|
|
Laser detection (front side)
|
|||||
|
|
Battery CapacityAh
|
51.2V/48V
|
|
|
Mounting height 182mm
|
|||||
|
|
Battery CapacityAh
|
28
|
|
|
Opening angle 260 degrees
|
|||||
|
|
Typical endurance
|
8h(customizable)
|
|
Maximum detection range
|
25m
|
|||||
|
|
Charging method
|
Online autonomous charging / manual charging
|
|
Collision bar detection
|
Front and rear pneumatic crash bars
|
|||||
|
|
Charger power supply
|
AC220V/AC380V
|
|
Emergency stop butto
|
Front and back 2
|
|||||
|
|
Charger power
|
|
|
Off-load detection
|
None
|
|||||
|
|
Number of charge cycles
|
Fully charge and discharge 1500 times
|
|
Overweight detection
|
None
|
|||||
|
|
|
|
Others
|
Protection level
|
IP54
|
|||||
|
|
Charging time after complete discharge
|
≤1.5h
|
|
Working Environment
|
Indoor, temperature: -10~+45℃; humidity: 20%~85%
|
|||||
|
|
|
|
|
Navigation
|
Laser / QR code / magnetic stripe navigation
|
|||||
|
|
Working time under rated working condition
|
8h
|
|
Control method
|
Remote control operation/auto navigation/acceptance of communication command control from the host computer
|
|||||
|
|
|
|
|
Gravimetric function (optional)
|
Weight measurement, center of gravity position detection, overload alarm, off-load alarm
|
|||||
|
STUAA 3T heavy-duty AGV performance parameters table
|
|
|
|
|
|
|||||
|
Basic parameters |
model
|
3T heavy-duty handling robot (omnidirectional)
|
Sports Performance |
Walking style
|
Forward, backward, left and right turn / rotation in place / traverse
|
|||||
|
|
Dimension (length)
|
1800mm
|
|
Drive method
|
steering engine
|
|||||
|
|
Dimension (width)
|
1500mm
|
|
Rated running speed (no load) (m/s)
|
0.2-0.5
|
|||||
|
|
Dimension (height)
|
500mm
|
|
Rated running speed (full load) (m/s)
|
0.2-0.4
|
|||||
|
|
Carrying capacity
|
3T-AGV
|
|
Maximum running speed (without load) (m/s)
|
0.5
|
|||||
|
|
Chassis height from the ground
|
50mm
|
|
Maximum running speed (full load) (m/s)
|
0.5
|
|||||
|
|
Lifting height
|
50-200mm
|
|
Stable running speed (no load) (m/s)
|
0.4
|
|||||
|
|
Equipment weight
|
Less than 2T
|
|
Stable running speed (full load) (m/s)
|
0.4
|
|||||
|
Navigation Performance |
Navigation
|
Magnetic Navigation
|
|
Maximum acceleration (no load) (m/s^2)
|
0.25
|
|||||
|
|
Navigation and positioning accuracy
|
±10mm
|
Maximum acceleration (full load) (m/s^2)
|
|
0.14
|
|||||
|
|
Positioning method
|
Magnetic stripe + RFID
|
Maximum climbing (full/no load)
|
|
3
|
|||||
|
Drive unit |
Wheel diameter
|
Φ200mm
|
|
Obstacle traversing capacity (full/no load) (mm)
|
5
|
|||||
|
|
Single wheel carrying capacity
|
2T
|
Trench crossing capacity (full load/no load) (mm)
|
|
8
|
|||||
|
|
Number of rounds
|
4
|
Lifting speed
|
|
|
|||||
|
|
Self-topping type
|
Electric or hydraulic
|
Traveling adjustable accuracy
|
|
|
|||||
|
|
Maximum pressure on the ground
|
8Mpa
|
Lifting and lowering adjustable precision
|
|
|
|||||
|
|
Motor type
|
AC/DC servo motor
|
Minimum turning radius
|
|
0m
|
|||||
|
|
Number of drive motors
|
4
|
Movement speed
|
|
0-0.5m/s
|
|||||
|
Power Battery |
Battery Type
|
Lithium iron phosphate battery/lead-acid battery
|
|
Positioning accuracy
|
±10mm
|
|||||
|
|
Rated voltage V
|
51.2V/48V
|
Maximum pressure on the ground
|
|
8Mpa
|
|||||
|
|
Battery CapacityAh
|
60-250
|
Hanging
|
|
Spring/hydraulic independent type
|
|||||
|
|
Typical endurance
|
8h(customizable)
|
Climbing ability
|
|
5
|
|||||
|
|
Charging method
|
Online autonomous charging / manual charging
|
Adaptation to the ground
|
|
Concrete, self-leveling, asphalt, steel plate floors
|
|||||
|
|
Charger power supply
|
AC220V/AC380V
|
others |
Protection level
|
IP54
|
|||||
|
|
Charger power
|
|
|
|
|
|||||
|
|
Full discharge charging time
|
8-10h
|
|
Working Environment
|
Indoor, temperature: -10~+45℃; humidity: 20~85
|
|||||
|
Security |
Obstacle detection method
|
Laser detection (diagonal)
|
|
|
|
|||||
|
|
Maximum detection range
|
5m
|
Navigation
|
|
Magnetic Navigation
|
|||||
|
|
Collision bar detection
|
Perimeter collision bar detection
|
|
|
|
|||||
|
|
Emergency stop button
|
4
|
Control method
|
|
Remote control operation/auto navigation/acceptance of communication command control from the host computer
|
|||||
|
|
Off-load detection
|
None
|
|
|
|
|||||
|
|
Overweight detection
|
None
|
Weighing function
|
|
|
|||||
|
STUAA 30T heavy-duty AGV performance parameters table
|
|
|
|
|
|
|||||
|
Basic parameters |
Model
|
30T heavy-duty handling robot (omnidirectional)
|
Sports Performance |
Walking style
|
Forward, backward, left and right turn / in situ rotation / traverse
|
|||||
|
|
Dimension (length)
|
4000mm
|
|
Drive method
|
Steering Engine
|
|||||
|
|
Dimension (width)
|
2000mm
|
|
Rated running speed (no load) (m/s)
|
0.2-0.5
|
|||||
|
|
Dimension (height)
|
720mm
|
|
Rated running speed (full load) (m/s)
|
0.2-0.4
|
|||||
|
|
Carrying capacity
|
30T-AGV
|
|
Maximum running speed (no load) (m/s)
|
0.5
|
|||||
|
|
Chassis height from the ground
|
50mm
|
|
Maximum running speed (full load) (m/s)
|
0.5
|
|||||
|
|
Lifting height
|
50-200mm
|
|
Stable running speed (no load) (m/s)
|
0.4
|
|||||
|
|
Equipment weight
|
6T
|
|
Stable running speed (full load) (m/s)
|
0.4
|
|||||
|
Navigation Performance |
Navigation
|
Magnetic Navigation / Laser Navigation
|
|
Maximum acceleration (no load) (m/s^2)
|
0.25
|
|||||
|
|
Navigation and positioning accuracy
|
±10mm
|
Maximum acceleration (full load) (m/s^2)
|
|
0.14
|
|||||
|
|
Positioning method
|
magnetic stripe + rfid / laser + rfid
|
Maximum climbing (full/no load)
|
|
3
|
|||||
|
Drive unit |
Wheel diameter
|
Φ410mm
|
|
Barrier crossing capacity (full/no load) (mm)
|
5
|
|||||
|
|
Single wheel carrying capacity
|
4.5T
|
Trench crossing capacity (full load/no load) (mm)
|
|
8
|
|||||
|
|
Number of rounds
|
8
|
Lifting speed
|
|
|
|||||
|
|
Self-topping type
|
Electric or hydraulic
|
Traveling adjustable accuracy
|
|
|
|||||
|
|
Maximum pressure on the ground
|
8Mpa
|
Lifting and lowering adjustable precision
|
|
|
|||||
|
|
Motor type
|
AC/DC servo motor
|
Minimum turning radius
|
|
0m
|
|||||
|
|
Number of drive motors
|
4
|
Movement speed
|
|
0-0.5m/s
|
|||||
|
Power Battery |
Battery Type
|
Lithium iron phosphate battery/lead-acid battery
|
|
Positioning accuracy
|
±10mm
|
|||||
|
|
Rated voltage V
|
51.2V/48V
|
Maximum pressure on the ground
|
|
8Mpa
|
|||||
|
|
Battery CapacityAh
|
60-250
|
Hanging
|
|
Spring/hydraulic independent type
|
|||||
|
|
Typical endurance
|
8h(customizable)
|
Climbing ability
|
|
5
|
|||||
|
|
Charging method
|
Online autonomous charging / manual charging
|
Adaptation to the ground
|
|
Concrete, self-leveling, asphalt, steel plate floors
|
|||||
|
|
Charger power supply
|
AC220V/AC380V
|
Others |
Protection level
|
IP54
|
|||||
|
|
Charger power
|
|
|
|
|
|||||
|
|
Full discharge charging time
|
8-10h
|
|
Working Environment
|
Indoor, temperature: -10~+45℃; humidity.
20~85 |
|||||
|
Security |
Obstacle detection method
|
Laser detection (diagonal)
|
|
|
|
|||||
|
|
Maximum detection range
|
6m
|
Navigation
|
|
Magnetic Navigation / Laser Navigation
|
|||||
|
|
Collision bar detection
|
Perimeter collision bar detection
|
|
|
|
|||||
|
|
Emergency stop button
|
4
|
Control method
|
|
Remote control operation/auto navigation/acceptance of communication commands from the host computer
Command control |
|||||
|
|
Off-load detection
|
None
|
|
|
|
|||||
|
|
Overweight detection
|
None
|
Weighing function
|
|
|
|||||
