* High life span, can work without oil.
* The installation direction can be chosen at will.
* Two three passs/two five passageways can be interchanged. (Patent Design)
* Low temperature environment is optional.
* High temperature environment is optional.
* The two three links are self-respiration designed(which can be used in high dust and strong acid and alkali gas environments).(Patent Design)
* 0.3 W low power option.
* It can be connected with a large-caliber gas control valve without a pipe.
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
ALPHA
-
Product name:
-
Solenoid directional valve
-
Valve body material:
-
all stainless steel, all aluminum alloy
-
Surface treatment:
-
stainless steel electrolytic polishing, aluminum alloy oxidation
-
Medium contact material:
-
stainless steel 316, NBR
-
Air source interfaces:
-
G1 / 4, NPT1 / 4, G1 / 2, NPT1 / 2
-
Working temperature:
-
- 25 ~ 65, - 45 ~ 70
-
Working pressure:
-
1-8bar
-
Protection grade:
-
IP66
-
Electrical strength:
-
1000V
-
Working life:
-
10millions
Quick Details
-
Port Size:
-
NPT1/2,NPT1 / 4
-
Warranty:
-
12 months
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ALPHA
-
Product name:
-
Solenoid directional valve
-
Valve body material:
-
all stainless steel, all aluminum alloy
-
Surface treatment:
-
stainless steel electrolytic polishing, aluminum alloy oxidation
-
Medium contact material:
-
stainless steel 316, NBR
-
Air source interfaces:
-
G1 / 4, NPT1 / 4, G1 / 2, NPT1 / 2
-
Working temperature:
-
- 25 ~ 65, - 45 ~ 70
-
Working pressure:
-
1-8bar
-
Protection grade:
-
IP66
-
Electrical strength:
-
1000V
-
Working life:
-
10millions
Products Description
Product features
Product Paramenters
|
Parameter Name
|
Value
|
|
|
|
|
Direct-Acting
|
Pilot-Operated
|
|
|
Case code
|
RV 718C111N
|
RV 518CN111N
|
|
|
Model
|
RV
|
RV
|
|
|
Acting type
|
7.Direct-Acting
|
3.3/2 Way
|
|
|
|
|
5.5/2 Way
|
|
|
|
|
5.5/3 Way
|
|
|
Switching Method
|
1.Return Type
|
1.Return Type
|
|
|
|
|
2.Detent Type
|
|
|
Voltage
|
1.AC 48V
|
1.AC 48V
|
|
|
|
2.AC 110V
|
2.AC 110V
|
|
|
|
3.AC 240V
|
3.AC 240V
|
|
|
|
5.AC 220V
|
5.AC 220V
|
|
|
|
8.DC 24V
|
8.DC 24V
|
|
|
|
9.DC 220V
|
L8.0.3W DC 24V
|
|
|
|
0.special
|
F8.0.8W DC 24V
|
|
|
|
|
Z8.1.2W DC 24V
|
|
|
Explosion Proof type
|
G.Non-explosion Proof
|
G.Non-explosion Proof
|
|
|
|
M.EExmbII T5
|
M.EExmbII T5
|
|
|
|
I.ExiaIICT6
|
I.ExiaIICT6
|
|
|
|
C.Ex d IIC T5/T6
|
C.Ex d IIC T5/T6
|
|
|
Mounting Type
|
|
D.Pipe joint type
|
|
|
|
|
N.NAMUR
|
|
|
Air connection
|
1.G1/4
|
1.G1/4
|
|
|
|
2.NPT1/4
|
2.NPT1/4
|
|
|
|
|
3.G1/2
|
|
|
|
|
4.NPT1/2
|
|
|
Conduit entry
|
0.for ordinary solenoid valves
|
0.for ordinary solenoid valves
|
|
|
|
1.NPT1/2
|
1.NPT1/2
|
|
|
|
2.M20x1.5
|
2.M20x1.5
|
|
|
Ambient Temp
|
1.-25℃~60℃
|
1.-25℃~60℃
|
|
|
|
2.-45℃~70℃
|
2.-45℃~70℃
|
|
|
Surface treatment
|
N.Ａluminium Ａlloy
|
N.Ａluminium Ａlloy
|
|
|
|
SS.Stainless steel
|
SS.Stainless steel
|
|
|
|
C.Ceram
|
C.Ceram
|
|
Arguments
Physical dimension
(mm)
Single coil solenoid valve
Double coil solenoid valve
Explosion proof Single coil valve
Explosion proof Double coil valve
Direct acting valve
Single coil solenoid valve
