Quick Details
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
RuiLian
-
Model Number:
-
Aluminum foil polyurethane foam board
-
Product name:
-
Aluminum foil polyurethane foam board
-
Core material:
-
Hard Polyurethane Foam
-
Surface material:
-
0.06mm or 0.08mm Alumnium foil
-
Length:
-
Less than 6m
-
Width:
-
Maximum 1.2m
-
Thickness:
-
10mm~130mm
-
Density:
-
More than 38kg/m³
-
Fire rating:
-
B1,B2,B3
-
Thermal conductivity:
-
Less than 0.024w/mk
-
MOQ:
-
One 40 feet high container
Quick Details
-
Project Solution Capability:
-
graphic design, Cross Categories Consolidation
-
Application:
-
exterior and interior wall and roofing
-
Design Style:
-
Contemporary
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
RuiLian
-
Model Number:
-
Aluminum foil polyurethane foam board
-
Product name:
-
Aluminum foil polyurethane foam board
-
Core material:
-
Hard Polyurethane Foam
-
Surface material:
-
0.06mm or 0.08mm Alumnium foil
-
Length:
-
Less than 6m
-
Width:
-
Maximum 1.2m
-
Thickness:
-
10mm~130mm
-
Density:
-
More than 38kg/m³
-
Fire rating:
-
B1,B2,B3
-
Thermal conductivity:
-
Less than 0.024w/mk
-
MOQ:
-
One 40 feet high container
Products Description
Aluminum foil polyurethane insulation board has the following advantages:
1.Excellent thermal insulation performance: polyurethane foam has low thermal conductivity, and aluminum foil can reflect thermal radiation, thus improving the thermal insulation effect.
2.Good moisture-proof performance: The surface of the aluminum foil polyurethane insulation board is covered with a layer of aluminum foil, which can effectively prevent water vapor penetration and ensure the insulation effect.
3.Corrosion resistance: polyurethane foam has good corrosion resistance and can resist the corrosion of acid, alkali and other chemicals.
4.Easy installation: Aluminum foil polyurethane insulation board is lightweight and easy to install, which can significantly reduce construction costs.
5.Environmental protection and energy conservation: Aluminum foil polyurethane insulation board materials are all environmentally friendly materials, which will not cause pollution to the environment, and have good energy-saving effects, which can significantly reduce energy consumption.
In summary, aluminum foil polyurethane insulation board has advantages such as excellent insulation performance, moisture resistance, corrosion resistance, and easy installation, making it an excellent insulation material.
Product Application
Scope of use of the product
1. Building wall and roof insulation board
2. Pipeline and ventilation pipeline insulation board
3. Solar insulation system
4. Building insulation insulation system
Product Structure Diagram
Product Paramenters
|
Product Name
|
Rigid core polyurethane foam board
|
|
|
|
|||
|
Skin Surface Material
|
Aluminum Foil/Fiber Glass Paper (Mortar Paper)
|
|
|
|
|||
|
Brand
|
RuiLian/Can be customized/OEM/ODM
|
|
|
|
|||
|
Skin Thickness
|
Aluminum Foil
|
|
0.06mm or 0.08mm
|
|
|||
|
Skin Thickness
|
Fiber Glass Paper (Mortar Paper)
|
|
0.4mm or 0.8mm
|
|
|||
|
Tensile Bond Strength
|
≥1.0 MPa
|
|
|
|
|||
|
Density
|
≥35 kg/m³
|
|
|
|
|||
|
Thermal Conductivity
|
≤0.024 W/m•K
|
|
|
|
|||
|
Dimensional Stability
|
≤1.0 %
(70℃±2℃, 48h, Length/width/Thickness)
|
|
|
|
|||
|
Water Absorption Rate
|
≤3.0 %
(volume fraction)
|
|
|
|
|||
|
Compression Strength
|
≥150 KPa
(10% compression deformation)
|
|
|
|
|||
|
Tensile Strength Perpendicular to
Panel Direction |
≥0.10 MPa
|
|
|
|
|||
|
Bending Deformation
|
≥6.5 mm
|
|
|
|
|||
|
Moisture Permeability Coefficient
|
≤6.5 ng/Pa•m•s
|
|
|
|
|||
|
Combustion Performance Level
|
B1(equal to R1 and better than Class 0 )
|
|
|
|
|||
