Quick Details
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
4300*1700*1600mm
-
Weight (KG):
-
3200 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Peeling log:
-
970mm
-
Log diameter:
-
Max 500mm
-
Thickness range:
-
0.8~8mm
-
Peeling output speed:
-
60~120m/min
-
Reducer model:
-
R87
-
Quality grade:
-
Top
-
Color:
-
Green
-
Application:
-
Veneer peeler
Quick Details
-
Place of Origin:
-
Shandong, China
-
Type:
-
peeling machine, For hard wood
-
Brand Name:
-
Ruifeng hard wood peeler
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
4300*1700*1600mm
-
Weight (KG):
-
3200 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Peeling log:
-
970mm
-
Log diameter:
-
Max 500mm
-
Thickness range:
-
0.8~8mm
-
Peeling output speed:
-
60~120m/min
-
Reducer model:
-
R87
-
Quality grade:
-
Top
-
Color:
-
Green
-
Application:
-
Veneer peeler
High quality 4 feet spindleless veneer peeling machine
| Length of log | Max1350mm |
| Log diameter | 30mm-500mm |
| Veneer thickness | 0.8mm-8.0mm |
| Peeling output speed | Constant speed:60m/s adjustable speed:60-120m/s |
| Double roller motor | 11kw |
| Single roller motor | 5.5kw+5.5kw |
| Feeding motor | 11kw |
| Shearing motor | 2.2kw |
| Cot motor | 2.2kw |
| Total power | 37.4kw |
| Reduce motor | R87 helical gear reducer |
| Overall size | 4300*1700*1600mm |
| Weight | 6000kg |
| Production capacity | 120cbm 0.6mm veneer with 8 days working |
Advantages
1.Auto triming of the tail veneer
2.Automatically hit residual log core by cylinder
3.Alloy lead screw and tin bronze nut
4.Taiwan Hiwen liner Montion Products&technology
5.Easy knife function, convenient disassembly
6.The surface function is smooth on both size
7.Specially designed for rubber wood hard wood
Our main products: complete plywood equipment, complete particleboard equipment, complete MDF equipment, short-cycle laminating equipment, complete block board equipment and other wood-based machinery. Moreover we can produce hot press, cold press, forming machine, edge trim saw, glue spreader and other woodworking machines according to customers' requirement.
Plywood is the ideal products are widely used in all kinds of furniture, office equipment, combination of speaker, packaging industry exhibition.
We can accept OEM service,we can change the working length and diameter as your requirement, also can change the motor type (DC or AC). we have rich technology experience and can design machine according to your requirement.
