Quick Details
-
Power:
-
50hz
-
Dimension(L*W*H):
-
custom
-
Weight (KG):
-
5000
Quick Details
-
Place of Origin:
-
Shandong, China
-
Marketing Type:
-
Hot Product
-
Voltage:
-
3Phase 380V
-
Power:
-
50hz
-
Dimension(L*W*H):
-
custom
-
Weight (KG):
-
5000
Product Description
|
item
|
value
|
|
Place of Origin
|
China
|
|
|
Shandong
|
|
Type
|
Straightener & Cutter
|
|
Condition
|
New
|
|
Use
|
Sheet
|
|
Video outgoing-inspection
|
Provided
|
|
Machinery Test Report
|
Provided
|
|
Marketing Type
|
Hot Product
|
|
Warranty of core components
|
1 Year
|
|
Core Components
|
PLC, Engine, Gearbox, Motor
|
|
Brand Name
|
|
|
Voltage
|
3Phase 380V
|
|
Power
|
50hz
|
|
Dimension(L*W*H)
|
custom
|
|
Warranty
|
1 Year
|
|
Key Selling Points
|
Automatic
|
|
Applicable Industries
|
Building Material Shops, Machinery Repair Shops, Energy & Mining
|
|
Showroom Location
|
None
|
|
Weight (KG)
|
5000
|
|
|
|
Product Paramenters
|
Model
|
NCHW5-400A
|
NCHW5-600A
|
NCHW5-800A
|
NCHW5-1000A
|
|||
|
Material Width
|
70-400
|
70-600
|
70-800
|
70-100
|
|||
|
Material Thickness
|
1-12
|
|
|
|
|||
|
Coil Weight MAX
|
5000
|
5000
|
7000
|
7000
|
|||
|
Coil O.D
|
1500
|
|
|
|
|||
|
Coil I.D
|
508/610
|
|
|
|
|||
|
Max Feed Length
|
0-9999.99
|
|
|
|
|||
|
Feed Speed
|
12-16
|
|
|
|
|||
|
Straightening Roller
|
Upper 4 / Lower 3
|
|
|
|
|||
|
Straightening Diameter
|
114
|
|
|
|
|||
|
Feed Roller
|
1
|
|
|
|
|||
|
Feed Roller Diameter
|
120
|
120
|
144
|
144
|
|||
|
Main Motor
|
AC15
|
AC15
|
AC22
|
AC22
|
|||
|
Mandrel Expansion
|
Hydraulic
|
|
|
|
|||
|
Decoiler Motor
|
5.5
|
5.5
|
7.5
|
7.5
|
|||
|
Power Supply
|
3Phase 380V / 50HZ/ AS customer request
|
|
|
|
|||
|
Air Pressure
|
0.5
|
|
|
|
|||
|
Feeding line height adjust method
|
Electric Adjustment
|
|
|
|
|||
Features
·
Suitable for medium and high-strength plates, stainless steel and other materials, thickness range of 1.0-12.0 mm.
·
The housing-type structure is specially designed for high-strength plates, and the upper and lower leveling rollers have reinforcement structures to ensure that the stress relief effect meets the standard.
·
Electric adjusting straightener gap, replacing manually adjusting via turning handle wheels, making operation easier.
·
The innovative mechanical structure minimizes the working space required by the whole machine.
·
Full set of Siemens servo control system: high-precision feeding; humanized design and safety protection system etc.,convenient for operating.
