Quick Details
-
voltage:
-
3 phase 380v 50-60hz
-
certification:
-
CE ISO9001
-
frequency:
-
1-8khz
-
depth:
-
5-10mm
-
power factor:
-
>95%
-
duty cycle:
-
100%
-
converter:
-
igbt
-
warranty:
-
1 year
-
origen:
-
Chengdu, Sichuan, China
Quick Details
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
JKZ
-
power:
-
200kw
-
voltage:
-
3 phase 380v 50-60hz
-
certification:
-
CE ISO9001
-
frequency:
-
1-8khz
-
depth:
-
5-10mm
-
power factor:
-
>95%
-
duty cycle:
-
100%
-
converter:
-
igbt
-
warranty:
-
1 year
-
origen:
-
Chengdu, Sichuan, China
Application range:
1. Hot forming, hot forging, hot upsetting,hot pressing of metal.Hot forging of standard components,bolts & nuts; hot forming of fasteners and metallic tools,hot pressing of automobile and motorcycle parts.
2. Heat Penetration
Hot forging of bar material, round steel,square steel,hot punching of copper rod.
3. Continues hot forging of metal
Hot forging of gear parts,axle shaft,continues hot forging of connecting rod, precious forging of bearing.
4. Heat distortion
Heat distortion of pipes, bending of pipes, heat distortion of stainless pipe,heat distortion of copper rod, heat distortion of steel billet,heat bending of steel pipe.
5. Hot Rolling Heating
Hot rolling of steel rod,steel billet,copper rod,square steel,bar material,hot coating.
6. Other forge heating applications, such as hot squeezing, partial heating, heating before hot cutting, hot fitting, thermal refining.
7. Suitable for workpiece with various shape and different diameter.
8. Solution of customized forging product.
Product feature:
1. High conversion efficiency with IGBT(SIEMENS) technology.
2. Energy saving 15%-30% compared to SCR/KGPS technology.
3. Much more efficient than gas-fired and coal-fired method.
4. 100% start-up success rate; power factor > 95%.
5. Perfect and complete protection functions, which increase the machine's reliability & stability.
6. No special foundations required, the operating cost is low,and the operation is easy.
7. Modular design, convenient to maintaining and repairing.
8. JKZ medium frequency machines adopt parallel oscillating structure,IGBT module power components and our inverting control technologies of fourth generation.
9. The frequency ranges from 1KHZ to 20KHZ, it is easy to match the machine according to the parts and the heating.
10.Due to the parallel oscillating structure, it is easy to get the best matching of the machine to get high heating efficiency and full power output of generator.
11.Due to the high technologies of inverting control of our fourth generation, soft and accurate switching control is realized to assure the high reliability and low repair of the machine.
Product advantage:
1. Energy saving, nvironmental protection, and low pollution level.
2. Easy operation, can be equiped with PLC controller.
3. Miniature and light weight, economic space occupation, Easy installation.
4. Enhanced monitoring and diagnostics system-"JKZ-PS" device, guarantee the machine of high stability, reliability and security.
5. Strict Supplier Management System and ISO9001-2008 Quality Management System guarantee high quality of each equipment.
6. Customized services, which made machines suit as every customer's requirement.
Factory
Packing Details : Plywood box, 1pc/box
Delivery Details : sea shipping, air shipping, express shipping
