Continuous flow screen worm scroll centrifuge for salt solid liquid decanter machine

Continuous flow screen worm scroll centrifuge for salt solid liquid decanter machine

FOB Reference Price: Get Latest Price

≥1 Sets

US $11000

≥2 Sets

US $10500

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Voltage:: Customized

Power:: 3kw

Weight:: 450

Dimension(L*W*H):: 1120*1050*800mm

Model:: LWL200

Drum diameter:: 200mm

Drum length:: 176mm

Speed:: 4000rpm

Separation factor:: 1790

Feed rate:: 0.5-1.5Cubic meters/h

Motor power:: 3kw

Quick Details

Place of Origin:: Jiangsu, China

Marketing Type:: New Product

Brand Name:: Blovebird

Voltage:: Customized

Power:: 3kw

Weight:: 450

Dimension(L*W*H):: 1120*1050*800mm

Model:: LWL200

Drum diameter:: 200mm

Drum length:: 176mm

Speed:: 4000rpm

Separation factor:: 1790

Feed rate:: 0.5-1.5Cubic meters/h

Motor power:: 3kw

Product Description

Performance and Use:

Blovebird's horizontal screen scroll centrifuge is widely used in chemical, food, pharmaceutical and mining industries, and is suitable for the separation of solid-phase suspensions containing coarse crystals and short fibers.

* Raw material requirements:

①Solid particle size more than 0.05mm

②Solid content 10-90%

MAIN FEATURES

1. Strong pertinence to materials, the crystal size is between 0.05-10mm

2. Continuous operation, Screw unloading, large production capacity, good solid phase dehydration, low energy consumption and light weight.

3. The solid phase has low moisture content, good washing effect and high separation efficiency

4. Dedicated filter screen, material optional, filter screen thickness up to 0.5mm, longer service life

5. Stepless speed regulation of drum speed

6. Simple and reliable lubrication

7. Compact structure, easy operation and maintenance

8. Safety protection: speed detection, oil-free protection, motor overload and overheat protection, spiral zero differential protection.

★ LWL series has hundreds of cases in the waste salt treatment industry , including sodium chloride, sodium sulfate, ammonium chloride, ammonium sulfate, ferric chloride, and ferrous chloride. In addition, we have rich experience in plant extraction (tea, ginkgo, iron powder, kudzu root, hemp leaves, etc.), magnesium sulfate, copper sulfate, sodium gluconate, sodium metabisulfite, marine snowmaking, and other industries. Welcome customers from related industries to inquire.

--------------------------------------------------------------------------------------------------------------------------------------------------------

PARAMETERS

Model	Drum Dia (mm)	Drum Length (mm)	Speed (r/min)	Factor	Feeding (m³/h)	Power (kw)
200	200	176	4000	1790	0.5-1.5	3
250	250	208	3500	1712	1-5	4
350	350	287	3000	1762	3-15	11
450	450	356	2600	1700	3-18	22
530	530	405	2200	1434	6-20	30
630	630	496	1850	1205	10-30	37
800	800	525	1500	1008	15-40	55
1000	1000	664	1000	560	20-50	90

DETAILED PICTURES

--------------------------------------------------------------------------------------------------------------------------------------------------------

The improvements made by Blovebird in ammonium sulfate, ammonium chloride, ammonium thiocyanate, sodium chloride and other waste liquid salt extraction equipment:

1. The feeding pipe device is improved, the cloth is more uniform, and the equipment operation is more stable;

2. The lubrication system is improved, the lubrication is more adequate and reasonable, and the bearing weight is increased;

3. Improve the bearing sealing system and adopt labyrinth oil seals to prevent mother liquid from entering the lubrication system;

4. The drum spiral is treated with nitriding and wear-resisting, and the service life is longer.

5. The discharging system is improved, and a scraper device is added to prevent the silo from accumulating.

WORKING PRINCIPLE

Under full speed operation: continuous feeding, washing, dewatering, unloading and other technological operations of the suspension.

The suspension enters the spiral cavity from the feed pipe, and enters the drum through the nozzle at the bottom of the screw head near the bottom of the cone.
Unde r the action of the centrifugal force field, the liquid phase in the slurry is separated by the creen set on the rotating wall When going out, the solid particles are trapped in the drum; at the same time, the solid particles in the drum move from the small end of the drum to the big end of the drum under the action of centrifugal force and the differential speed between the

spiral and the drum.
During the movement, the centrifugal force increases rapidly due to the increase of the rotation diameter. The solid phase changes from the high moisture content solid phase when it initially enters to the low moisture content solid phase when it is discharged from the drum, thus realizing automatic and continuous solid and liquid phase separation.

LWL Series Screw Screen Centrifuge has been successfully used in the following:

Adipic Acid	Potash	Rock Salt	Date Stones
Salt Cake	lon Excgange Resin	Sodium Nitre	Polystyrene Alcohol
Arsenic Triazole	Sodium Chloride	Sodium Perborate	Sodium Thiosulphate
Ah-salt	Anth Racene	Nylon Chips	Copper Sulphate
Naphthenic Sulfonic Acid Ester	Iron Sulphate Hepta Hydrate	Hops From Dichlorc Methare	Ammonium Thiosulphate
Greaves	Sodium Chlorate	Citric Acid	Tarteric Acid
Aminiacetic Acid	Aspirin	Oxalic Acid	Crystal Soda
Gun Powder	Lactose	Sodium Sulphate	Potash Alum
Regenerated Rubber	Sodium Formate	Polymethacrylate	Tin Sulphate
Ammonium Persulphate	Bisphenol	Sodium Sulphite	Dinitro Methylarlin
Gypsum	Managanese Sulphate	Polysyrene	Potash Solvent Residue
Silver Nitrate	Sodium Gliconate	Sodium Tetraborate	Trisodium
Ammonium Phosphate	Borax	Two Nitro Methylaniline	Extraction from Methanol
Urotropin	Methyl Cellulose	Disodium Phosphate	Potassium Bica Rbonate
Sodium Acetate	Sodium Metaborate	Potassium Lore	Zinc Sulphate
Ammonium Sulphate	Calcium Formiate	Potassium Chloride	Potassium Bichromate
Sodium Phosphate	Monosod lumphasphate	Polyvinyl Chloride	Potassium Pensuphate
Sodium Ca Rbonate	Sodium Nitrate	Potassium Sulphate	Fungal Mycel

--------------------------------------------------------------------------------------------------------------------------------------------------------

Customer Cases

Company： Jiangsu Victor Co., Ltd.

Material： Sodium chloride

Capacity：LWL350

Company： Pingxiang Xianwang Industrial Co., Ltd.

Material： Sodium chloride
Capacity：LWL450

Company： Hangzhou Jihua Jiangdong Chemical Co., Ltd.

Material： Ammonium sulfate
Capacity：LWL450

Company： Linhuan Coking Co., Ltd.

Material： Ammonium sulfate
Capacity：LWL450

Company： Heze Yuandong Qiangya Chemical Co., Ltd

Material： Ferric chloride
Capacity：LWL450

Company： Tangshan Siruier Chemical Co., Ltd.

Material： Ferrous chloride
Capacity：LWL450

Company： Linhuan Coking Co., Ltd.

Material： Ammonium sulfate
Capacity：LWL450

Company： Jiangxi Yongtong Technology Co., Ltd.

Material： Sodium sulfate
Capacity：LWL450

Company： Tangshan Zhongrun Coal Chemical Co., Ltd.

Material： Magnesium sulfate
Capacity：LWL350

Company： Zhengzhou Yuda Chemical Co., Ltd.

Material： Copper sulfate
Capacity：LWL450

Company： Kaidi Chemical Co., Ltd.

Material： Sodium gluconate
Capacity：LWL350

Company： Bangze Chemical Co., Ltd.

Material： Sodium pyrosulfite
Capacity：LWL530

Company： Zibo Huayan Chemical Co., Ltd.

Material： Sodium sulfate
Capacity：LWL450

Company： Dongjiang Environmental Co., Ltd.

Material： Sodium chloride
Capacity：LWL350

Company： Nantong Chenlong Chemical Co., Ltd.

Material： Ammonium chloride
Capacity：LWL450

Company： Shandong Aochuang Chemical Co., Ltd.

Material： Magnesium sulfate
Capacity：LWL630

Packing&Shipping

Our Service

Pre-sales Service

1- Inquiry and consulting support.
2 - OEM service is available.

24 hours online service.

1-Machine operation video
2-Watch our factory online
3-Contact us for more services

After-sales Service

1 - The warranty period is 12 months from the date of arrival of the machine. Offer the free spare parts.
2 - Follow up regularly until the machine works normally.3 - We will remind you of routine maintenance.

Installation, commissioning and training

1- If the customer has demand, we will arrange experienced engineers to go to the local equipment installation, debugging and test
production.

2-Workers can receive training in our factory and in your factory.

Why Choose Us

Jiangsu Blovebird Centrifuge Co. Ltd

-Verified Supplier

- Holding 40 Patents

- CE & ISO certificated

- Innovative R&D Team

- 30 Years' Experience in this field

- Awarded as a High-tech Enterprise

- No. 1 Machinery Plant in Zhangjiagang

- Precise Production Line Meeting the GMP Requirements

- 8500 Square Meter Facilities in Strategic Location in Yangze River Delta

Blovebird Separations Cetificates and Patents.

International certification, National Certificate of equipment verification, and more than 40 invention patents are done in Blovebird Separations.
Verification Certificates of equipments: ISO9001, CE, TUV

FAQ

HOW TO FIND BLOVEBIRD?
● Search Alibaba, Youtube and find suppliers and manufactrue and not traders
● Visit exhibition in different countries
● Send Blovebird an request and tell your basic inquiry
● Blovebird sales manager will reply you in short time and add instant chatting tool

YOU ARE WELCOME TO OUR FACTORY AT ANY TIME.
● If we can fullfill your request and you interested in our products, you may pay a visit to Blovebird Separations site
● The meaning of visiting supplier, because seeing is believing, Blovebird Separations with own manufacture and developed& research team,

HOW TO GUARANTEE YOUR FUNDS TO BE SAFE AND DELIVERY TO BE ON TIME?
● Through Alibaba letter guarantee service, it will ensure the on time delivery and the quality of the equipment you want to buy.
● By letter of credit, you can lock the delivery time easily.
● After the factory visit, You can ensure the facticity of our bank account.

SEE BLOVEBIRD SEPARATIONS HOW TO ENSURE THE QUALITY!
● In order to ensure the accuracy of each part, we are equipped with a variety of professional processing equipment and we have accumulated professional processing methods over the past years.
● Each component before assembly needs strictly control by inspecting personnel.
●After all the equipment are completed, we will conduct a trial run before shipment to ensure the stable running in customers' factory

THE AFTER-SALE SERVICE OF BLOVEBIRD SEPARATIONS!
● After finish the production, we will test the machine, take photos, videos and send them to customers via mail or instant tools
● After the commissioning, we will package the equipment by standard export package for shipment.
● According to the customer's request, we can arrange our engineers to customers' factory to do the installation and training.
● Engineers, sales managers and after-sales service manager will form a after-sales team, online and off line, to follow the customers' project.
