Quick Details
-
Color:
-
full color
-
Panel Size:
-
960x960mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW-FA
-
Brightness:
-
10000≥6500 cd/m²
-
pixel density:
-
15625dots/m2
-
Contrast Ratio:
-
5000:1
-
Color Depth:
-
1R1G1B
-
Lifespan (hours):
-
100000 hours
-
IP Rating:
-
IP65
-
Resolution:
-
120*120dots/cabinet
-
View Angle（H/V）:
-
160/160
-
Module size:
-
480*320mm
-
Lamp type:
-
SMD2727
-
Usage:
-
Outdoor HD
-
Cabinet material:
-
Alumimum
-
Cabinet Weight:
-
28kg
-
Refresh rate:
-
3840Hz
-
Control system:
-
Novastar System
-
Maintenance mode:
-
Front or rear maintenance
-
Gray Scale:
-
14bit
Quick Details
-
Application:
-
Outdoor
-
Type:
-
LED
-
Brand Name:
-
DDW
-
Color:
-
full color
-
Panel Size:
-
960x960mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW-FA
-
Brightness:
-
10000≥6500 cd/m²
-
pixel density:
-
15625dots/m2
-
Contrast Ratio:
-
5000:1
-
Color Depth:
-
1R1G1B
-
Lifespan (hours):
-
100000 hours
-
IP Rating:
-
IP65
-
Resolution:
-
120*120dots/cabinet
-
View Angle（H/V）:
-
160/160
-
Module size:
-
480*320mm
-
Lamp type:
-
SMD2727
-
Usage:
-
Outdoor HD
-
Cabinet material:
-
Alumimum
-
Cabinet Weight:
-
28kg
-
Refresh rate:
-
3840Hz
-
Control system:
-
Novastar System
-
Maintenance mode:
-
Front or rear maintenance
-
Gray Scale:
-
14bit
Discover Your Right Application , Make Your Business Possible !
Common warranty in LED field is 2 years, ours is 3 years Longer warranty
periods, better after-sale services, worry-free user experience
Project Case
Rental LED displays have been exported to many countries and rigions
in the World, and we are highly praised by our customers.
Products Description
|
Part Number
|
P5.7
|
P6.66
|
P8
|
P10
|
||||
|
Pixel Pitch
|
5.7mm
|
6.66mm
|
8mm
|
10mm
|
||||
|
LED Configuration
|
SMD2727
|
|
|
|
||||
|
Pixel Density
|
30625dot/m2
|
22500dot/m2
|
15625dot/m2
|
10000dot/m2
|
||||
|
Module size
|
480*320mm
|
|
|
|
||||
|
Module Resolution
|
84*56 dot
|
72*48 dot
|
60*40 dot
|
48*32dot
|
||||
|
Cabinet Size
|
960*960*77mm
|
|
|
|
||||
|
Cabinet Resolution
|
168*168dot
|
144*144dot
|
120*120dot
|
96*96dot
|
||||
|
Cabinet Weight
|
28kg
|
|
|
|
||||
|
IP Rating ( front/back)
|
IP65
|
|
|
|
||||
|
Brightness Intensity
|
|
|
|
|
||||
|
Viewing Angle (H/V)
|
140°/140°
|
|
|
|
||||
|
View Distance
|
＞5m
|
|
|
|
||||
|
Gray Scale
|
14bit
|
|
|
|
||||
|
Display Scale
|
16.7M
|
|
|
|
||||
|
Brightness Adjustment
|
0-100 levels adjustable
|
|
|
|
||||
|
Max.Power Consumption
|
650W/㎡
|
|
|
|
||||
|
Ave.Power Consumption
|
200W/㎡
|
|
|
|
||||
|
Drive Mode
|
1/7S
|
1/6S
|
1/4S
|
1/2S
|
||||
|
Refresh Frequency
|
≥3840HZ
|
|
|
|
||||
|
Gamma Correction
|
-5.0~+5.0
|
|
|
|
||||
|
Environmental
|
OUTDOOR
|
|
|
|
||||
|
Control Mode
|
Synchronous display with control PC by DVI
|
|
|
|
||||
|
Support Input
|
Composite,S-Vido,Component,VGA,DVI,HDMI,HD_SDI
|
|
|
|
||||
|
Operation Power
|
AC100~240 50/60HZ
|
|
|
|
||||
|
Operating Temperature
|
-20℃~+50℃
|
|
|
|
||||
|
Operating Humidity
|
10~95% RH
|
|
|
|
||||
|
Operating Life
|
100,000hours
|
|
|
|
||||
