Quick Details
-
Size:
-
12135*2440*1405mm
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
Semi Trailer
-
Axle:
-
2/3/4 Axle
-
Function:
-
Transport 20ft 40ft Container
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
>50000 kg
-
Brand Name:
-
CIMC
-
Size:
-
12135*2440*1405mm
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
Semi Trailer
-
Axle:
-
2/3/4 Axle
-
Function:
-
Transport 20ft 40ft Container
Products Description
CIMC Semi Trailer Characteristic
Our Standard Frame 40′ 3-way Skeletal B Trailer is both ideal and specialized to work well in the wharf environment of the Australian market with vast customization options to tailor the product to the requirements of your business. With the versatility as a 3-Way Twist-lock and configured as a B-Double or Single trailer operation, the CIMC Standard B Skeletal is a robust vehicle for your container transport needs.
Contact
sales Manager ：
Marco Jiang
Whatsapp/wechat/mobile:
+86 13868117431
E-mail:
marco@liebty.com
Company :
liebty Machinery Technology(Hangzhou) Co.,Ltd
Address:
Room 208,Building 3, No.1866, Binxing Road, Changhe street,Bingjiang District,Hangzhou,Zhejiang,China
Specifications
|
Parameter
|
Dimension(Mm)
|
length×width×height:12,480×2,740×H（The height will be adjusted according to the tractor specification）
|
|
|
Sidewall Height(Mm)
|
600
|
|
|
Fifth Wheel Height(Mm)
|
The height will be adjusted according to the tractor specification
|
|
|
Payload （Kg）
|
50,000
|
|
Fabric
|
Main Beam(Mm)
|
500,submerged arc welding
|
|
|
Flange And Web(Mm)
|
16/10/18
|
|
|
Lock
|
12 units.
|
|
|
Floor
|
2.5mm checker plate
|
|
|
Paint
|
primer + top coat,polyurethane paint
|
|
OEM
|
Landing Gear
|
Jost Landing gear
|
|
|
Kingpin
|
3.5”JOST, exchangeable
|
|
|
Brake System
|
30/30 type on each axle, WABCO brake valve
|
|
|
ABS
|
No
|
|
|
Suspension
|
Front axle: air suspension, can lift; Rear two axles: Mechanical suspension with 8 leaf spring
|
|
|
Axle
|
CIMC or FUWA 13T, ISO10 Holes
|
|
|
Tire
|
Linglong Brand, type: 12.00R20, equip 13 per chassis
|
|
|
Rim
|
8.5*20, ISO10, equip 13 per chassis
|
|
|
Toolbox
|
1 set, steel box,1m
|
|
|
Spare Tire Carrier
|
2 units per chassis
|
|
Color
|
|
Following the customer’s request.
|
