Quick Details
-
Max. Resolution:
-
8 dots/mm, 384 dots/line
-
Brand Name:
-
HCCTG
-
Model Number:
-
HCC-EC58B
-
Place of Origin:
-
Guangdong, China
-
Effective Printing Width:
-
48mm
-
Auto cutting frequency:
-
1 million times
-
Character Set:
-
ASCII,GB2312-80(Chinese)
-
Print Font:
-
ANK:8*16,9*17,9*24,12*24, GBK: 16*16,24*24
-
PaperThickness:
-
60-85mm
-
Paper Roll Diameter:
-
Max: 50mm
-
MCBF:
-
5 million lines
-
Interface:
-
RS232+USB With electromagnetic lock
-
Power Supply (Adapter):
-
12V
-
Outline Dimension (WxDxH):
-
80x82x52mm
Quick Details
-
Interface Type:
-
RS232+USB
-
Max Paper Size:
-
58mm
-
Black Print Speed:
-
50-80mm/s
-
Max. Resolution:
-
8 dots/mm, 384 dots/line
-
Brand Name:
-
HCCTG
-
Model Number:
-
HCC-EC58B
-
Place of Origin:
-
Guangdong, China
-
Effective Printing Width:
-
48mm
-
Auto cutting frequency:
-
1 million times
-
Character Set:
-
ASCII,GB2312-80(Chinese)
-
Print Font:
-
ANK:8*16,9*17,9*24,12*24, GBK: 16*16,24*24
-
PaperThickness:
-
60-85mm
-
Paper Roll Diameter:
-
Max: 50mm
-
MCBF:
-
5 million lines
-
Interface:
-
RS232+USB With electromagnetic lock
-
Power Supply (Adapter):
-
12V
-
Outline Dimension (WxDxH):
-
80x82x52mm
Products Description
Feature
1.Smart appearance
Easy paper loading
Low noise thermal printing
Different interfaces optional
Front panel makepaper replacement easily
Easily embedded to any kinds of instruments and meters
Support Cash Drawer port.
Support RS232+USB, with electromagnetic lock
Support big Paper Roll Diameter 50mm
Support security locks foropen top cover
SupportAuto Cutter
Support Windows2000/XP/7/8/10, Linux,Android
|
PaperType
|
Thermal paper
|
|
Paper Width
|
57.5± 0.5mm
|
|
PaperThickness
|
60-85mm
|
|
Paper Roll Diameter
|
Max: 50mm
|
|
MCBF
|
5 million lines
|
|
Outline Dimension (WxDxH)
|
80x82x52mm
|
|
Installation Port Size
|
77x78x48mm
|
|
OperatingTemp
|
5°C ~ 50°C
|
|
Operating Humidity
|
10% ~ 80%
|
|
StorageTemp
|
-20°C ~ 60°C
|
|
StorageHumidity
|
10% ~ 90%
|
Applications:
kiosk & vending machine, queuing machine, Promotion coupon printing machine Parking system, Gas station filling machine, Game machine & vote machine
Hot Printers
OEM Company
OEM Handheld Pos, Retail Desktop Pos,Bus validator,Barcode scanner,BT printer,Smart card reader
Most of our products have passed CE, FCC, RoHS international standard, and also approved by Unionpay, EMV, PCI, Visa, MasterCard Industry Professional Certifications, which greatly ensure the highest level safety and quality of our products.
