- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
HBSANCE
-
Model Number:
-
L20
-
Channel:
-
3 channels
-
Range:
-
0.0001-35.5cm/s
-
Accuracy:
-
5%
-
Record length:
-
1-200 sec
-
Clock precision:
-
≤5sec per month
Quick Details
-
Warranty:
-
1 Year
-
Power:
-
Electronic
-
Place of Origin:
-
Beijing, China
-
Brand Name:
-
HBSANCE
-
Model Number:
-
L20
-
Channel:
-
3 channels
-
Range:
-
0.0001-35.5cm/s
-
Accuracy:
-
5%
-
Record length:
-
1-200 sec
-
Clock precision:
-
≤5sec per month
L20 Blasting Vibration Monitor
Products Description
Specification
The L20 blasting vibration monitor satisfies all needs of blasting vibration recording, including mining, pile driving, Tunnel
construction, demolition blasting and so on. It is rugged, reliable and very easy to use. You can view peak vibration and
frequency immediately on the LCD screen after each event occurs. You can also analyse every blasting vibration event with the
computer software.
Authoritative
In order to accuracy measurement data, it has not only CMC logo that can prove test and measurement are legitimacy, but also
passed the test by national vibration laboratory.
Portable
You can use it easily for setting, collecting or reading event, because it has LCD, keypad, battery and SD card.
Usability
You can use the waveform recording mode to collect vibration signals without any setting after the boot, then itwil1 record events automatic cycle.
Technical Advantages
1. WIFI connection can realize remote monitoring.
2. All 3 speed sensors in one make cable setting easy.
3. A/D resolution reaches 24 bit, which makes waveform smooth and precise.
4. 8-keytactile keypad drives simple menu operations.
5. Without any setting in automatic mode.
6. Used fully transition away from compute.
Specification
|
System
|
24 bit A/D quantization precision1/16777216
|
|
Channel
|
3 channels
|
|
Range
|
Speed:0.0001-35.5cm/s Frequency: 1-500Hz
|
|
Accuracy
|
Precision for acquisition: 5%
|
|
Work pattern
|
Automatic or manual
|
|
Record length
|
1-200 sec or adaptation
|
|
Record mode
|
Continuous
|
|
Sample rate
|
1-50 KHz adjustable
|
|
PC interface
|
WIFI and Rj45
|
|
Storage
|
4G flash
|
|
LCD screen
|
3.5 inches LCD
|
|
Clock precision
|
≤5sec per month
|
|
Working temperature
|
-10°F~ 75°F
|
|
Battery
|
Rechargeable sealed lithium cell, capacityfor24 hours of continuous working
|
