3. Customized services are available
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
XJ-GJG
-
Size:
-
0.5~80MM
-
Product name:
-
Silicone OEM Hose
-
Material:
-
100% Silicone
-
Color:
-
Customized Color
-
Working temperature:
-
-40℃~200℃
-
Application:
-
Machine
-
Feature:
-
High Temperature Resistance
-
Hardness:
-
40~80A
-
Shape:
-
Round Tube
-
Certification:
-
ISO9001
Quick Details
-
Processing Service:
-
Cutting
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XJ
-
Model Number:
-
XJ-GJG
-
Size:
-
0.5~80MM
-
Product name:
-
Silicone OEM Hose
-
Material:
-
100% Silicone
-
Color:
-
Customized Color
-
Working temperature:
-
-40℃~200℃
-
Application:
-
Machine
-
Feature:
-
High Temperature Resistance
-
Hardness:
-
40~80A
-
Shape:
-
Round Tube
-
Certification:
-
ISO9001
Product Description
|
Product Description
|
|
|
|
Product Name
|
Food grade silicone tube
|
|
|
Material
|
Silicone
|
|
|
Function
|
Insulation protection
|
|
|
Package
|
Carton
|
|
Our Advantages
advantage
1. High temperature resistance 200 ℃, low temperature - 40 ℃
2. It is made of food grade silica gel and has been certified by the food and drug administration
Product application
Performance characteristics
1. Non toxic, odorless, high transparency and no yellowing;
2. It is soft, elastic, resistant to kink and deformation;
3. No cracking, long service life, cold and high temperature resistance;
4. It has higher tear strength and superior electrical performance;
Product features
|
Item
|
parameter
|
|
Tensile strengthMPa(Kg/cm2)
|
≧6.9
|
|
Elongation
|
≧300%
|
|
Tear strength kN/m(kg f/cm)
|
≧24.5
|
|
Physical resistivity Ω·m(Ω·cm)
|
≧2×1014
|
|
Dielectric strength KV/mm
|
≧25
|
|
Dielectric constant（ε）50Hz
|
≧3.2
|
|
Dielectric loss tangent 50Hz
|
0.001
|
|
Use temperature range℃
|
-40～+200
|
|
Asing condition 200°C
|
4h No cracking
|
|
Breakdown strength
|
20kv/mm
|
|
Ozone resistance
|
No crack
|
|
Internal diameter
|
|
|
|
Wall thickness
|
|
|
|
||||
|
Standard
|
Tolerance
|
Standard
|
Tolerance
|
Standard
|
Tolerance
|
Standard
|
Tolerance
|
||||
|
Φ0.8
|
0.1
|
0.8
|
±0.1
|
Φ0.4
|
0.1
|
0.4
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ1.0
|
0.1
|
0.5
|
±0.1
|
Φ1.0
|
0.2
|
0.6
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ1.2
|
0.2
|
0.5
|
±0.1
|
Φ1.2
|
0.2
|
0.6
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ1.8
|
0.2
|
0.5
|
±0.1
|
Φ1.8
|
0.2
|
0.6
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ2.0
|
0.2
|
0.5
|
±0.1
|
Φ2.0
|
0.2
|
0.6
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ2.5
|
0.2
|
0.5
|
±0.1
|
Φ2.5
|
0.2
|
0.6
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ3.0
|
0.2
|
0.5
|
±0.1
|
Φ3.0
|
0.2
|
0.6
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ3.5
|
0.2
|
0.5
|
±0.1
|
Φ3.5
|
0.2
|
0.6
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ4.2
|
0.1
|
0.5
|
±0.1
|
0.5
|
0.1
|
0.5
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ4.5
|
0.2
|
0.5
|
±0.1
|
Φ4.5
|
0.2
|
0.6
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ5.0
|
0.2
|
0.5
|
±0.1
|
Φ5.0
|
0.2
|
0.6
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ6.0
|
0.2
|
0.5
|
±0.1
|
Φ6.0
|
0.2
|
0.6
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ7.0
|
0.2
|
0.7
|
±0.1
|
Φ7.0
|
0.2
|
0.8
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ8.0
|
0.2
|
0.7
|
±0.1
|
Φ8.0
|
0.2
|
0.8
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ9.0
|
0.2
|
0.8
|
±0.1
|
Φ9.0
|
0.2
|
0.9
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ10.0
|
0.2
|
0.8
|
±0.1
|
Φ10.0
|
0.2
|
0.9
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ11.0
|
0.2
|
0.9
|
±0.1
|
Φ11.0
|
0.2
|
1
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ12.0
|
0.2
|
0.9
|
±0.1
|
Φ12.0
|
0.2
|
1
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ13.0
|
0.2
|
1
|
±0.1
|
Φ13.0
|
0.2
|
1.1
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
|
Φ14.0
|
0.2
|
1
|
±0.1
|
Φ14.0
|
0.2
|
1.1
|
±0.1
|
||||
|
|
-0.1
|
|
|
|
-0.1
|
|
|
||||
Details Images
Hardness:
40 ~ 80 degrees;
Common colors:
transparent, white, black, red, green, blue, gray
Food grade silica gel is made of high quality silica gel (a brand new imported food grade silica gel material) through scientific formula and advanced technology. The product has the characteristics of softness, high temperature resistance and stability. In today's healthy diet, food grade silicone has gradually replaced food grade plastic.
