Quick Details
-
Max. Weight of Workpiece(kg):
-
300
-
Width of bed (mm):
-
400 mm
-
Spindle Motor Power(kW):
-
7.5
-
Max. Turned Length (mm):
-
400
-
Travel (X Axis)(mm):
-
300 mm
-
Travel (Z Axis)(mm):
-
440 mm
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
2500x1800x2000
-
Voltage:
-
customized
-
Weight (KG):
-
2900
-
Core Components:
-
Bearing Motor
Quick Details
-
Type:
-
TURNING CENTER
-
Max. Length of Workpiece (mm):
-
300
-
Max. Spindle Speed (r.p.m):
-
4500 r.p.m
-
Max. Weight of Workpiece(kg):
-
300
-
Width of bed (mm):
-
400 mm
-
Spindle Motor Power(kW):
-
7.5
-
Max. Turned Length (mm):
-
400
-
Travel (X Axis)(mm):
-
300 mm
-
Travel (Z Axis)(mm):
-
440 mm
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
2500x1800x2000
-
Voltage:
-
customized
-
Weight (KG):
-
2900
-
Core Components:
-
Bearing Motor
Products Performance
Feature
1.45 degrees slant bed CNC lathe;
2.Higher accuracy Taiwan linear guideways;
3.Chip conveying capacity is large and convenient , customer could choose chip conveying in the right or in the back;
4.Spindle unit has two types , the heavy cutting type and the high speed type. Heavy type cutting unit is suitable for bearing and gear processing , High speed unit is suitable for the high speed and high precision processing .Customers could choose any type of them;
5.Screw pre-stretching structure;
6.Gang type tool standard;
7.Optional turret.
2.Higher accuracy Taiwan linear guideways;
3.Chip conveying capacity is large and convenient , customer could choose chip conveying in the right or in the back;
4.Spindle unit has two types , the heavy cutting type and the high speed type. Heavy type cutting unit is suitable for bearing and gear processing , High speed unit is suitable for the high speed and high precision processing .Customers could choose any type of them;
5.Screw pre-stretching structure;
6.Gang type tool standard;
7.Optional turret.
Machine Photos
Product Paramenters
|
Specification
|
Unit
|
TCK6332
|
TCK6340(S)
|
TCK6350
|
|
Max.Swing Over Bed
|
mm
|
320
|
400
|
520
|
|
Swing Over Cross Slide
|
mm
|
110
|
140
|
220
|
|
Max.Processing Length
|
mm
|
200
|
300
|
410/330
|
|
X/Z Axis Travel
|
mm
|
300/250
|
400/300(500)
|
500/500
|
|
Spindle Unit
|
mm
|
140
|
140/170
|
200
|
|
Spindle Nose
|
|
A2-5
|
A2-5
|
A2-6
|
|
Spindle Bore
|
mm
|
48
|
48/56
|
66
|
|
Bar Capacity
|
mm
|
40
|
40/45
|
55
|
|
Max.Spindle Speed
|
rpm
|
4000
|
4000
|
3000
|
|
Chuck Size
|
in
|
6
|
6/8
|
10
|
|
Spindle Motor
|
Kw
|
3.7
|
3.7/5.5
|
7.5/11
|
|
X/Z Axis Repeatability
|
mm
|
±0.003
|
±0.003
|
±0.003
|
|
X/Z Axis Feed Motor Torque
|
N.m
|
4/6
|
6/6
|
7.5/7.5
|
|
X/Z Rapid Traverse
|
m/min
|
15/15
|
18/15(18/18)
|
18/18
|
|
Turret type
|
|
Gang Tool Post
|
Gang Tool Post
|
Gang Tool Post
|
|
Cutting Tool Size
|
mm
|
20*20
|
20*20
|
25*25
|
|
Guide Way Type
|
|
45° Guide Way
|
45° Guide Way
|
45° Guide Way
|
|
Total Power Capacity
|
KVA
|
9/11
|
9/11
|
14/18
|
|
Dimension (L*W*H)
|
mm
|
1920*1350*1700
|
2200*1530*1780
|
2500*1620*1890
|
|
N.W
|
KG
|
2580/2860
|
2650/2930
|
2900
|
