Quick Details
-
Brand Name:
-
EWIND
-
Use:
-
Office
-
Warranty Time:
-
3-years warranty
-
Product Name:
-
10G Managed Media Converter 1 SFP to 1 RJ45
-
Installation:
-
Desktop, wall mountable Media convert Chassis installation
-
Power requirement:
-
12V 1A
-
Power Built in Type:
-
0.8kg
-
Dimensions:
-
118*86*27mm
-
Transmission Bandwidth:
-
10G
-
Warranty:
-
1 Year
-
Applications:
-
Data Center, Telecom network, Cloud computing
-
Certification:
-
CE,FCC,RoHS
-
Keywords:
-
SFP Madia Converter 12V1A
Quick Details
-
Type:
-
Fiber optic media converter
-
Model Number:
-
EW-10GSFP-SR
-
Place of Origin:
-
GUA
-
Brand Name:
-
EWIND
-
Use:
-
Office
-
Warranty Time:
-
3-years warranty
-
Product Name:
-
10G Managed Media Converter 1 SFP to 1 RJ45
-
Installation:
-
Desktop, wall mountable Media convert Chassis installation
-
Power requirement:
-
12V 1A
-
Power Built in Type:
-
0.8kg
-
Dimensions:
-
118*86*27mm
-
Transmission Bandwidth:
-
10G
-
Warranty:
-
1 Year
-
Applications:
-
Data Center, Telecom network, Cloud computing
-
Certification:
-
CE,FCC,RoHS
-
Keywords:
-
SFP Madia Converter 12V1A
1G/2.5G/5G/10G SFP Ethernet Media Converter Managed Network Media Converter Desktop and Wall-mountable
Products Description
Technology Specification
|
Technical specification
|
|
EW-610SFP-FE
|
|
|
Interface
|
1 x 10G/5G/2.5G/1G/100BASE-T RJ45
Auto-MDI/MDI-X, auto-negotiation |
SFP
|
|
|
|
1 x 10GBASE-X R SFP+ interface
|
100Mbps
|
|
|
LED
|
POWER
100M 1000M 10G LINK/ACT Fiber |
Full duplex
|
|
|
Switch Processing Scheme
|
Store and Forward
|
MM 50/125um,62.5/125um
SM 9/125um |
|
|
ESD Protection
|
6KV DC
|
20KM
|
|
|
Enclosure
|
Compact-sized metal case
|
MM 850nm,1310nm
SM 1310nm,1550nm WDM Tx1310/Rx1550nm(A side),Tx1550/Rx1310nm(B side) WDM Tx1490/Rx1550nm(A side),Tx1550/Rx1490nm(B side) |
|
|
Installation
|
Desktop, wall mountable
Media convert Chassis installation |
RJ45
|
|
|
Dimension(W*D*H)
|
118×86×27mm
|
100Mbps
|
|
|
Weight
|
0.8KGS
|
Half/full duplex
|
|
|
Power requirement
|
12V 1A
|
Cat5,Cat6
|
|
|
Power consumption
|
3.75 watts / 12.8 BTU per hour max.
|
DC5V
|
|
|
Flow Control
|
Back pressure for half duplex
IEEE 802.3x pause frame for full duplex |
AC100~240V
|
|
|
Fabric
|
20Gbps
|
Power
|
|
|
Throughput
(packet per second) |
2.48Mpps@64bytes
|
Full Duplex Indication
|
|
|
Address Table
|
9K entries, automatic source address learning and aging
|
Fiber/Rj45 Link/Act
|
|
|
Jumbo Frame
|
16K
|
RJ45 Port Speed 100M
|
|
|
Network Cables
|
10G/5G/2.5G/1G/100M BASE-T:
10G--Cat 6A/Cat 7 5G--Cat 6/Cat 6A/Cat 7 1G/2.5G--Cat 5e/Cat 6/Cat 6A/ Cat 7 100M--Cat 5/Cat 5e/Cat 6/Cat 6A/ Cat 7 Cat 5/5e/6/6A/7 UTP cable (100 meters, max.) EIA/TIA-568 100-ohm STP (100 meters, max.) 10GBASE-LR/SR/BX: 50/125μm or 62.5/125μm multi-mode fiber optic cable, up to 300m 9/125μm single-mode fiber optic cable, up to 80km |
0.39kg
|
|
|
Regulatory Compliance
|
FCC Part 15 Class A, CE
|
0.67kg
|
|
|
Operating environment
|
0 ~ 50 degrees C
|
94*70.5*26.5mm
|
|
|
Storage environment
|
0 ~ 70 degrees C
|
140.5*111*30mm
|
|
|
Operating Humidity
|
5 ~ 95%, relative humidity (non-condensing)
|
＜3W
|
|
|
Storage Humidity
|
5 ~ 95%, relative humidity (non-condensing)
|
0~50℃ Operating; -40~70℃ Storage
|
|
|
Standards Compliance
|
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T IEEE 802.3bz 2.5G/5GBASE-T IEEE 802.3an 10GBASE-T IEEE 802.3ae 10Gbps Ethernet IEEE 802.3x full-duplex flow control |
5~95%(no condensing)
|
|
|
|
|
≥10.0000h
|
|
|
Warranty
|
1-year warranty
|
CE,FCC,RoHS
|
|
|
|
|
3 years warranty
|
|
|
|
|
3-years warranty
|
|
|
|
|
|
|
|
|
|
|
|
FEATURES
* Transparent Transport and very low delay
* Support ITUT prescribed DWDM/CWDM wavelength
* Support DMI function for SFP+ fiber module
* Support Loop-back test function
* Economic In-band Management function
* Powerful Network Management function
* Support hot plugging
* Support 2U Rack (16 channel) and standalone use
* Full State Led display
* Easy installation
* UTP cable length detection（only RJ45 interface）
KEY ADVANTAGES
Provide reliable long-distance connection
Fast connection with multi-function
Small portable size case
Plug and play
1 year warranty
* Transparent Transport and very low delay
* Support ITUT prescribed DWDM/CWDM wavelength
* Support DMI function for SFP+ fiber module
* Support Loop-back test function
* Economic In-band Management function
* Powerful Network Management function
* Support hot plugging
* Support 2U Rack (16 channel) and standalone use
* Full State Led display
* Easy installation
* UTP cable length detection（only RJ45 interface）
KEY ADVANTAGES
Provide reliable long-distance connection
Fast connection with multi-function
Small portable size case
Plug and play
1 year warranty
|
CONTENT
|
QTY
|
UNIT
|
|
10G Fiber media Converter
(EW-10GSFP-SR) |
1
|
SET
|
|
User Guide
|
1
|
PC
|
|
Warranty Card
|
1
|
PC
|
