Quick Details
-
Engine Brand:
-
xinchai
-
Weight:
-
6700 KG
-
Length:
-
4080mm
-
Width:
-
1750mm
-
High:
-
2650mm
-
Wheelbase:
-
2010mm
-
Engine:
-
4C6-10035
-
Rated speed:
-
2400r/min
-
Gear box:
-
F12/R12
-
Min.using mass:
-
3030kg
-
Steering system type:
-
All hydraulic steering
-
Min.ground clearance:
-
330mm
Quick Details
-
Brand Name:
-
LTMG
-
Place of Origin:
-
China
-
Marketing Type:
-
Hot Product 2022
-
Engine Brand:
-
xinchai
-
Weight:
-
6700 KG
-
Length:
-
4080mm
-
Width:
-
1750mm
-
High:
-
2650mm
-
Wheelbase:
-
2010mm
-
Engine:
-
4C6-10035
-
Rated speed:
-
2400r/min
-
Gear box:
-
F12/R12
-
Min.using mass:
-
3030kg
-
Steering system type:
-
All hydraulic steering
-
Min.ground clearance:
-
330mm
Product Specification
LTA904 90HP
Specifications
|
model
|
|
LT1004B
|
|
|
type
|
|
4X4
|
|
|
Overall dimension(mm)
|
Length
|
4080
|
|
|
|
Width
|
1750
|
|
|
|
High
|
2650
|
|
|
wheelbase(mm)
|
|
2010
|
|
|
Front wheel tread(mm)
|
|
1285
|
|
|
Rear wheel tread(mm)
|
|
1340
|
|
|
Min.turning radius(m)
|
One side brake
|
4.2±0.3
|
|
|
|
One side not brake
|
4.9±0.3
|
|
|
Min.using mass
|
|
3030
|
|
|
Gear box
|
|
12F+12R
|
|
|
Speed(km/h)
|
going
|
0.44-33.34
|
|
|
|
retread
|
0.59-10.31
|
|
|
Engine
|
model
|
4C6-10035
|
|
|
|
Rated power(kw)
|
73.5
|
|
|
|
Rated speed(r/min)
|
2400
|
|
|
Tyre type
|
Front tyre
|
9.5-24
|
|
|
|
Rear tyre
|
14.9-30
|
|
|
Steering system type
|
|
All hydraulic front wheel steering
|
|
|
Max.lift-off weight(KN)
|
|
17.7
|
|
|
PTO type
|
|
Rear-mounted semi-detached
|
|
|
PTO speed(r/min)
|
|
760/1000(540/1000 or 540/760 or 760/850 is also available)
|
|
|
PTO power(kw)
|
|
62.5
|
|
|
Roots in control mode
|
|
Height adjustment,floating control
|
|
|
Max.traction(KN)
|
|
23.2
|
|
|
Counterweight quality(kg)
|
front
|
270
|
|
|
|
rear
|
470
|
|
