Quick Details
-
Fork Length:
-
1220
-
Fork Width:
-
125
-
Overall Dimensions:
-
3300*1760*2325mm
-
Weight (KG):
-
5450 kg
-
forklift:
-
diesel forklift
-
diesel forklift:
-
4t 4WD rough terrain forklift
-
Marketing Type:
-
New Product 2022
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
SOCMA
-
Fork Length:
-
1220
-
Fork Width:
-
125
-
Overall Dimensions:
-
3300*1760*2325mm
-
Weight (KG):
-
5450 kg
-
forklift:
-
diesel forklift
-
diesel forklift:
-
4t 4WD rough terrain forklift
-
Marketing Type:
-
New Product 2022
SOCMA 6 tons 6t 4WD rough terrain forklift
| 6Ton Rough Terrain Forklift | |||
| 1.1 | Model | HNY60 | |
| 1.2 | Power Type | Diesel | |
| 1.3 | Rated Capacity | kg | 6000 |
| 1.4 | Load Center Distance | mm | 580 |
| 1.5 | Drive Type | All-time 2WD/4WD | |
| Dimension Parameter | |||
| 2.1 | Lift Height | mm | 6000 |
| 2.2 | Fork Size(L*W*H) | mm | 1220×150×60 |
| 2.3 | Mast inclination angle (F/R) | Deg | 6\12 |
| 2.4 | Overall Length (without fork) | 3650 | |
| 2.5 | (Overall Width) | mm | 1860 |
| 2.6 | Mast Height | mm | 3142 |
| 2.8 | Head Guard Height | mm | 2450 |
| 2.10 | Ground Clearance | mm | 320 |
| 2.11 | Maximum Turning Radius | mm | 3970 |
| 2.12 | Wheelbase | mm | 1950 |
| 2.13 | Front wheel tread | mm | 1480 |
| 2.14 | Rear wheel tread | mm | 1380 |
| 2.15 | Self Weight | kg | 7600/7800 |
| 2.20 | Overall Height(3 Stage 6m Mast) | mm | 3142 |
| Performance Parameter | |||
| 3.1 | Maximum Travel Speed | Km\h | 36 |
| 3.2 | Lifting Speed | mm\s | 430 |
| 3..3 | Lowering Speed | mm\s | 460 |
| 3.4 | Maximum Gradeability | % | 40 |
| Tire | |||
| 4.1 | Front Tyre | 16/70-20 | |
| 4.2 | Rear Tyre | 10-16.5 | |
| Engine and Gearbox | |||
| 5.1 | Battery | V\Ah | 24\60 |
| 5.2 | Engine Manufacturer | Nissan | |
| 5.3 | Engine Model | ZD30N15-3D1 | |
| 5.4 | Rated Power/RPM | kw | 85/2400 |
| 5.5 | Fuel Tank Capacity | L | 110 |
| 5.6 | Gearbox Model | 280 | |
| 5.7 | Transmission Type | Hydraulic | |
