Quick Details
-
Type:
-
Tinplate Coil
-
Place of Origin:
-
Hebei, China
-
Product Name:
-
Printed Tin Plate
-
Material:
-
SPCC/MR/08AL/SPTE
-
Surface Finish:
-
Stone Sliver Matte
-
Tin Coating:
-
1.1g/m2-11.2g/m2
-
Temper:
-
T1--T4 DR8-DR9
-
Oil:
-
Electro Statically Oiled
-
Certification:
-
ISO9001:2008
-
Package:
-
Customer`s Demand
-
Payment:
-
T/T
Quick Details
-
Standard:
-
AiSi, ASTM, bs, DIN, GB, JIS
-
Grade:
-
MR
-
Thickness:
-
0.15-0.5mm
-
Type:
-
Tinplate Coil
-
Place of Origin:
-
Hebei, China
-
Product Name:
-
Printed Tin Plate
-
Material:
-
SPCC/MR/08AL/SPTE
-
Surface Finish:
-
Stone Sliver Matte
-
Tin Coating:
-
1.1g/m2-11.2g/m2
-
Temper:
-
T1--T4 DR8-DR9
-
Oil:
-
Electro Statically Oiled
-
Certification:
-
ISO9001:2008
-
Package:
-
Customer`s Demand
-
Payment:
-
T/T
Tinplate for food packing
1. Reference standard:GB2520-2000,JISG3303-2002and DINEN10202-2001
2. Material:MR,SPCC
3. Thickness:available:0.15mmto0.50m m
4.Width:available:600mmto1010m m
5.Temper grade:T1-T5,DR8-DR10,BAandCAboth.
6. Tin coating: ordinary 2.8g/2.8g, 5.6g/5.6g, We also can produce according to customers' requests
7. Coil diameter: ID 420/ 508mm, OD from 1,000 to 1,250m
8. Package: Seaworthy Standard with wooden pallet
Hardness Of Tinplate
|
Hardness level |
Target thickness |
Use |
|
T-1 |
49±3 |
Cans, nozzles, spouts and other applications involving deep drawing that requires large flexibility |
|
T-2 |
53±3 |
Rings and plugs ,shallow drawn, items that require moderate draw ability and some stiffness |
|
T-2.5 |
55±3 |
Battery can bodies, items that require the draw ability of T-2 in combination with the stiffness of T-3 for general use |
|
T-3 |
57±3 |
Can ends and bodies, proper stiffness is imported to prevent buckling for general uses |
|
T-4 |
61±3 |
Crown caps and small screw closures that require comparatively large stiffness |
|
T-5 |
65±3 |
Can ends, bodies for non corrosive products and other applications that require excellent buckling resistance |
|
DR-8 |
73 |
Applicable to the requirements of certain rigidity strength beer ,carbonated beverage tank body and the tank |
Surface Finish
|
Code |
Classification |
Specific Finishes |
|
B |
Bright Finish |
A luster surface provided by a flow-brightened tin coating on a smoothly grindstone finished steel base. |
|
R |
Stone Finish |
A luster surface provided by a flow-brightened tin coating on a steel base characterized by a directional grindstone pattern. |
|
S |
Silver Finish |
A luster surface provided by a flow-brightened tin coating on a coarse dull finish steel base. |
|
M |
Matte Finish |
A dull surface provided by an unmelted coating generally on dull finished steel base.
|
Qian’an Rentai Metal Products Co.,Ltd founded in 2011,is located at Qian’an city, Hebei province, the biggest steel product base in North China, which is 240km away from Beijing air port and 200km from Tianjin port.
The unique geographical position makes our company enjoy the abundant mineral resources and the export and import become very convenient.
Our main products include flat bar, steel plate, channels, angle steel, I-beams, H-beams, diamond plate, hot rolled /cold rolled steel plate / coils. Moreover, we can produce special specifications of steel products according to orders, fulfilling all customers’ requests by providing convenient "one-stop" service.
Our company have 7 sets of slitting flat steel production lines, and the year production will be 200,000 tons. 70% of our products (around 140,000 tons) are exported to the countries of Middle East, Europe, America and Asia, such as Iraq, Kuwait, Thailand, Brazil, Vietnam and Korea.
Our company has been certified by ISO9001, and our production process strictly conforms to the international standard of DIN/AISI /JIS/ASTM/BS to ensure the quality. We have passed and got the product quality certificates by BUREAU VERITAS of France.
Our company will always adhere to honesty and trustworthiness for the service concept and continue to meet customer demand for the purpose of, sincerely looks forward to making cooperation with all users and friends from at home and abroad and provides excellent services for you.
1) Competitive price
2) Best quality
3) On time delivery
4)Strong production capacity
