Quick Details
-
Brand Name:
-
KATU
-
Model Number:
-
LS500
Quick Details
-
Grade:
-
Industrial
-
Warranty:
-
1 year
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KATU
-
Model Number:
-
LS500
Products Description
Product principle
|
Wiring protection:
|
Wiring protection:
|
reverse phase, overload, short circuit protection
|
|
|
Medium density:
|
Medium density:
|
≥0.7g/cm
|
|
|
No-load current consumption:
|
No-load current consumption:
|
maximum 40mA,24Vdc power supply
|
|
|
Switch output
|
Output type:
|
PNP/NPN switchable,
Normally open (NO)/Normally closed (NC) can be set
|
|
|
|
SP1, SP2 load:
|
< 11/24VDC
|
|
|
|
Response time:
|
＜10ms
|
|
|
Current mode
|
Analog output:
|
≤±0.5% range
|
|
|
|
Output type:
|
4... 20mA can be configured
|
|
|
|
Load RA:
|
≤0.5KOhm
|
|
|
|
Linearity:
|
≤0.5% range
|
|
|
Display
|
Design:
|
Red 4-bit 12mm high brightness LED
|
|
|
|
Display range:
|
-1999... 9999
|
|
|
Material
|
Watch head housing:
|
engineering plastic
|
|
|
|
Flame retardant class:
|
UL-94 V-0
|
|
|
|
Housing:
|
stainless steel 304
|
|
|
|
Medium contact part:
|
stainless steel 304/NBR
|
|
