Quick Details
-
Brand Name:
-
Lunyee
-
Model Number:
-
3RK15
-
Frequency:
-
50HZ/60HZ
Quick Details
-
AC Voltage:
-
110V/120V/220V/230V
-
Warranty:
-
12 MONTHS
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Lunyee
-
Model Number:
-
3RK15
-
Frequency:
-
50HZ/60HZ
|
Model Type
Lead Wire Type |
Output power | Voltage | Frequency | Current | Starting Torque | Rated Torque | Rated Speed | Capacitor | |
| W | V | Hz | A | mN.m | mN.m | r/min | μF | ||
| Pinion shaft | Round shaft | ||||||||
| 3RK15GN-A | 3RK15A-A | 15 | 1ph100 | 50 | 0.4 | 110 | 125 | 1200 | 7 |
| 60 | 0.56 | 105 | 105 | 1450 | |||||
| 3RK15GN-E | 3RK15A-E | 15 | 1ph110 | 60 | 0.43 | 85 | 105 | 1450 | 6 |
| 1ph120 | 0.42 | ||||||||
| 3RK15GN-C | 3RK15A-C | 15 | 1ph220 | 50 | 0.23 | 110 | 125 | 1200 | 1.5 |
| 1ph230 | |||||||||
| 3RK15GN-H | 3RK15A-H | 1ph220 | 60 | 0.2 | 85 | 105 | 1450 | ||
| 1ph230 | 90 | ||||||||
Note:
1. When the motor is approved under various safety standards, the model name on the nameplate is the approved model name.
2. “ -A ” it means the voltage 110V, the assembly capacitor value it is according the label.
Parallel Shaft Gearhead(Sold Separately)
| Type | Gear ratio | 3 | 3.6 | 5 | 6 | 7.5 | 9 | 12.5 | ||
| motor/gearhead | speed r/min | 50Hz | 500 | 417 | 300 | 250 | 200 | 166 | 120 | |
| 60Hz | 600 | 500 | 360 | 300 | 240 | 200 | 144 | |||
| 3RK15GN-A | 3GN-K | 50Hz | 0.3 | 0.36 | 0.51 | 0.61 | 0.67 | 0.91 | 1.3 | |
| 3RK15GN-E | 3.06 | 3.67 | 5.2 | 6.22 | 7.75 | 9.28 | 13.2 | |||
| 3RK15GN-C | 60Hz | 0.26 | 0.31 | 0.43 | 0.51 | 0.64 | 0.77 | 1.1 | ||
|
3RK15GN-H |
2.65 | 3.16 | 4.63 | 5.2 | 6.53 | 7.85 | 11.2 | |||
