Size
|
2250*5600*2860mm or 2600*5600*2860mm（Support customization）
|
|
Steel Structure
|
Prefab steel structure
|
|
Wall Panel
|
0.326/0.376/0.426/0.476mm THC steel sheet
50/75/100mm THC EPS/rock wool/glass wool/pu sandwich panel
|
|
Wall Color
|
Grey, white, red, blue and more(Depending on quantity)
|
|
Roof
|
0.326/0.376/0.426/0.476mm THC steel sheet
50mm THC EPS/rock wool/ glass wool/pu sandwich panel
|
|
Door
|
0.326/0.376/0.426/0.476mm THC steel sheet50mm THC EPS/ rock wool/glass wool /pu sandwich panel with lock
|
|
Window
|
Aluminum PVC sliding door with security bar
|
|
Floor
|
MGO/ cement fiber floor board
|
|
Electricity
|
Pre-wired with lighting and circuit distributor installed
|
|
Install
|
4 Workers+2 Hours=1 House
|
|
Parm
|
Wind Resistance : ≤120 km/h
Snow Loading: 0.6 kn/m
Wall Permitted Loading: 0.6 kn/m Service temperature: - 40°C-40°℃
Earthquake Resistance：Grade 8
Floor load：250kg/sqm
|
|
Advantages
|
1. Connected by bolts, no need to weld.
2. All the steel structures are galvanized & bake-painted.
3. Save transportation, installation and storage cost.
4. Fire proof, water proof, corrosion-resistant, sound-insulation.
|
