Quick Details
-
Model Number:
-
KC-USA-067
-
AC leakage Current:
-
0.25mA Max .At 240V ac input
-
Input voltage:
-
240V, AC100~240V
-
Output plug:
-
5.5*2.5mm, 4.0*1.7mm, 3.5*1.35mm or others
-
Cable length:
-
1m, 2m, customized
-
Cable:
-
2464/2468 20/22AWG
-
Over voltage protection:
-
120% min
-
Over current protection:
-
120% min
-
Short circuit protect:
-
Auto Recovery
-
Safety approval:
-
FCC CE
-
Warranty:
-
12 Months
Quick Details
-
Output Type:
-
DC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KUNCAN
-
Model Number:
-
KC-USA-067
-
AC leakage Current:
-
0.25mA Max .At 240V ac input
-
Input voltage:
-
240V, AC100~240V
-
Output plug:
-
5.5*2.5mm, 4.0*1.7mm, 3.5*1.35mm or others
-
Cable length:
-
1m, 2m, customized
-
Cable:
-
2464/2468 20/22AWG
-
Over voltage protection:
-
120% min
-
Over current protection:
-
120% min
-
Short circuit protect:
-
Auto Recovery
-
Safety approval:
-
FCC CE
-
Warranty:
-
12 Months
12V 2A Power Supply AC Adapter, AC 100-240V to DC 12 Volt 2amp Transformers, 2.1mm X 5.5mm US Wall Plug
What is the Specifications of our power supply cable?
| Input | Input voltage | AC 100~240V |
| Variation Frequency | 50-60Hz | |
| Input frequence | 50~60Hz | |
| Output | Output voltage | 12v |
| Output current | 2A | |
| Output power | 24W | |
| Input plug types |
EU/ US /UK /AUS /South Korea /South African Plugs
|
|
| Out plug types | DC jack, XLR, JST, Cigar Lighter, Alligator Clips,Viation Plug, Din Plug.etc | |
| DC jack size | 5.5*2.1mm, 5.5*2.5mm, 3.5*1.35mm, 3.5*1.0mm, 4.0*1.7mm, 2.5*0.7mm .etc | |
| Safety protection | Over voltage protection | 120% min |
| Over current protection | 120% min | |
| Short circuit protection | auto recovery | |
| Over hot protection | auto recovery | |
| Electronic characteristics | Operating Temperature | -40~50°C |
| Storage Temperature |
-40 to +85
°C
|
|
| Humidity | 10%~95%RH | |
| Efficiency | 80% | |
| Ripple And Noise | Output voltage 1%, Ripple&Noise≤120mv | |
| Turn-on Delay Time | 3 second max | |
| Overshoot at Turn-on | 10% max when turn on or off | |
| AC leakage Current | 0.25mA max at AC 240V voltage | |
| Load Regulation | ±5% | |
| Line Regulation | ±5% | |
| High-Voltage test | Primary to secondary: 3 kV / 5mA 60S | |
| Drop Test | 0.75m drop test, 6 times | |
| Burn-In Test | 100% load, 5hours | |
| Application | CD/DVD,MP3/MP4,Digital camera,Comunication Terminals Etc | |
| Safe Certificate | CE ROHS FCC CB BS SAA C-tick PSE KC | |
Q1.
Are you factory or trade company
?
A:
We are factory
of
more than 10 years export expe
r
ience.
Q2.
What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q3.
What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4.
S
amples ?
A : 2-5 pieces free samples are available ,fright on you. delivery time usually is 2-3 days. Customized samples will take 5-10days.
Q 5. How to order and cooperate with you ?
A1 : Send your inquiry request → Feedback with quotation → Confirm quotation ( →Make mold→Mold test ) →Making samples→Samples test → P rice confirmed → P r o forma invoice provided→deposit payment→ Mass production→ balance payment → Packing →Delivery →After Service →Repeat Order...
A2
:
Send your
inquiry
request → Feedback with quotation → Confirm quotation and make payment
of fright
→Making
FREE
samples→Samples test →
P
rice confirmed
→
P
r
o
forma invoice provided→deposit payment→
Mass production→
balance payment
→
Packing →Delivery
→After Service →Repeat Order...
( Large order usually pay 30% deposit to start the production, balance before delivery )
Q
6
.
Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q
7
:
How will you maintain our long-term business
relationship?
A: Quality is priority.We will keep offering products good in quality and competitive in price to ensure our customers benefit ;
Q
8
:
how to ship out the cargo?
A:At your request, by sea, by air, by express, all are available.
