Quick Details
-
Brand Name:
-
KXD
-
Model Number:
-
3.7V 850mah 802540
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
15g, 16g
-
The charging ratio:
-
0.5c
-
The discharge rate:
-
1c
-
Battery type:
-
Li-polymer Battery
-
OEM/ODM:
-
Warmly Welcomed
-
Charge rate:
-
0.5C
-
Warranty:
-
1 year, 1 year
-
Battery Size:
-
8.0*25*42 mm with PCB
-
Cycle life:
-
500 Times
-
Discharge rate:
-
1C
-
Payment:
-
Credit Card.Paypal.TT.Escrow.Western Union
-
Battery Type:
-
Lithium Ion
Quick Details
-
Storage Type:
-
dry
-
Anode Material:
-
LCO
-
Application:
-
Toys, Power Tools, Home Appliances, Consumer Electronics, Electric Power Systems, Solar Energy Storage Systems
-
Brand Name:
-
KXD
-
Model Number:
-
3.7V 850mah 802540
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
15g, 16g
-
The charging ratio:
-
0.5c
-
The discharge rate:
-
1c
-
Battery type:
-
Li-polymer Battery
-
OEM/ODM:
-
Warmly Welcomed
-
Charge rate:
-
0.5C
-
Warranty:
-
1 year, 1 year
-
Battery Size:
-
8.0*25*42 mm with PCB
-
Cycle life:
-
500 Times
-
Discharge rate:
-
1C
-
Payment:
-
Credit Card.Paypal.TT.Escrow.Western Union
-
Battery Type:
-
Lithium Ion
Hot Sales
Products Description
atl-polymer-battery 3.7v 5v 7.4v 523450 802540 850mah 2200mah 20000mah 10000mah 12000mah lithium polymer battery
Main Features:
1. Lighter in weight, heavier on power than lead acid battery.
2. Use a grade cells. More than 800 cycle times.
3. Max discharge continuous current, 1C TO 3C 5C.
4. Maintenance free. Can connect in parallel and series.
5. Safer performance. batteries have passed different safety tests.
2. Use a grade cells. More than 800 cycle times.
3. Max discharge continuous current, 1C TO 3C 5C.
4. Maintenance free. Can connect in parallel and series.
5. Safer performance. batteries have passed different safety tests.
6. Optional: Lithium Battery built with BMS
|
Normal parameters
|
|
|
||
|
NO.
|
Item
|
General Parameter
|
||
|
1
|
Type
|
Lithium polymer Battery
|
||
|
2
|
Model
|
3.7v 850mah
|
||
|
3
|
Color
|
Bule/as your requirement
|
||
|
4
|
Standard capacity(0.2C5A)
|
850mAH
|
||
|
5
|
Rated voltage
|
3.7V
|
||
|
6
|
Max.charge voltage
|
4.2V
|
||
|
7
|
Cut-off voltage
|
2.75V
|
||
|
8
|
Standard charge current
|
< 0.2A / customized
|
||
|
9
|
Max continuous discharge current
|
< 0.5A / customized
|
||
|
10
|
Peak discharge current
|
<1.0A / customized
|
||
|
11
|
Battery dimension
|
8*30*32mm with PCB
|
||
|
12
|
(Approx.)Total weight(Approx.)
|
about 16g
|
||
|
13
|
Standard charging temperature
|
0℃~45℃
|
||
|
14
|
Discharge temperature
|
-20℃~60℃
|
||
|
15
|
Storage temperature
|
-20℃~45℃
|
||
|
16
|
Cycle life
|
>500 times
|
||
|
17
|
Warranty
|
12 month
|
||
|
18
|
Option
|
Connectors/other Capacity
|
||
Connectors as your requirement :
Main Applications:
1.Energy Storage:Solar-Wind Power System / City Grid (On/Off) / Community and Family / RV Motor/Golf Carts Battery / Boat Marine
Yachts / Electric Skateboard
2.Back-up System and UPS:Telcom Base / CATV system / Computer Server Center / Medical Instrument
3.Security and Electronics / Mobile POS, Mining Light / Torch / LED Light / Emergency Light / LED Backup /Engine Starting Battery.
4.Other applications
Yachts / Electric Skateboard
2.Back-up System and UPS:Telcom Base / CATV system / Computer Server Center / Medical Instrument
3.Security and Electronics / Mobile POS, Mining Light / Torch / LED Light / Emergency Light / LED Backup /Engine Starting Battery.
4.Other applications
Optional: Built in PCB overall protection:
1.Over charged protection
2.Over discharged protection
3.Thermal protection
4.Over load protection
5.Over current protection
2.Over discharged protection
3.Thermal protection
4.Over load protection
5.Over current protection
Models in stock:
