Quick Details
-
Brand Name:
-
OEM, ZHONGHE, DBN
-
Model Number:
-
MTA-2.3
-
Dimension (L x W x H):
-
56.5*46.5*36mm
-
Use:
-
Stage audio equipment
-
THD:
-
<1%
-
SNR:
-
>80dB
-
Output mode:
-
4-16ohm
-
Color:
-
Black or Silver or Golden or Customized
-
Type:
-
Constant impedance amplifier
-
Name:
-
Professional stereo amplifier
-
Inputs/Outputs:
-
2 MIC IN; 3 AUX IN; USB IN; SD IN; 1 AUX OUT
-
Class:
-
AB
Quick Details
-
Power:
-
500W-1400W
-
Frequency Range (Hz):
-
80Hz - 18KHz
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
OEM, ZHONGHE, DBN
-
Model Number:
-
MTA-2.3
-
Dimension (L x W x H):
-
56.5*46.5*36mm
-
Use:
-
Stage audio equipment
-
THD:
-
<1%
-
SNR:
-
>80dB
-
Output mode:
-
4-16ohm
-
Color:
-
Black or Silver or Golden or Customized
-
Type:
-
Constant impedance amplifier
-
Name:
-
Professional stereo amplifier
-
Inputs/Outputs:
-
2 MIC IN; 3 AUX IN; USB IN; SD IN; 1 AUX OUT
-
Class:
-
AB
Product description
:
Output power, 1 kHz, 0.1 % clipping
8 Ω dual channel drive 260 W
8 Ω single channel drive 300 W
4 Ω dual channel drive 400 W
Signal to noise (20 hz-20 kHz) 100 Db
Input sensitivity 1.2Vrms
Voltage gain (8 Ω) 32.2 dB
Output circuit B
Power requirements (1/8 power, 6.3 A, 6 A 11.5 A pink noise when 4 Ω 220 V AC)
Distortion (1 dB below the rated power, 1 kHz) 8 Ω, less than 0.02%
4 Ω, less than 0.05%
The frequency response is 20 minus 20 KHZ, plus 0, minus 1dB
Dynamic headroom, 4 Ω 2 db
Input impedance over 20K ohms (balanced or non-balanced)
Maximum input level +6 dB
Input connector, each channel 3 pin XLR, balanced, parallel
Output connector, each channel Speakon, terminal
Amplifier and load protection short circuit, circuit, thermal and RF protection
Load protection against dc faults
This series power rating matches the most commonly used speakers in the entertainment industry.
Load is 4 Ω and 8 Ω speaker system one of the biggest real net optimization.
Input: XLR, 1/4, TRS socket, compatible with any audio source.
Output: Speakon combo Speakon 2 column and 4 column plug (connect only 2 columns).The terminal supports all other speaker wiring systems.
Intelligent protectors automatically protect amplifiers and speakers from damage caused by temperature rise or overvoltage without shutting down playback.
The front panel LED monitors power, signal and clipping.
Subwoofer/satellite divider built in.
|
IP network broadcast professional amplifier
|
|
|
|
|
|
|
|
|
||||||||
|
Product Model
|
MTA-2.3
|
MTA-3.3
|
MTA-5.3
|
MTA-7.3
|
MTA-8.3
|
MTA-10.0
|
MTA-12.0
|
MTA-14.0
|
||||||||
|
8ohm Stereo Power
|
2*260W
|
2*330W
|
2*530W
|
2*850W
|
2*950W
|
2*1500W
|
2*1700W
|
2*1800W
|
||||||||
|
Case
|
Iron Case;Aluminum Panel;Aluminum Handle;Aluminum Knob
|
|
|
|
|
|
|
|
||||||||
|
DC power supply
|
4-16ohm
|
|
|
|
|
|
|
|
||||||||
|
Frequency Response
|
Line 60Hz to (20 kHz + 1 / -3 dB, 10 dB at rated output) Microphone line 70 Hz to 20 kHz (+ 1 / -3 dB, 10 dB at rated output)
|
|
|
|
|
|
|
|
||||||||
|
Color
|
Black/Silver
|
|
|
|
|
|
|
|
||||||||
|
Addition
|
MP3/AUX1/Switch/Echo Function
|
|
|
|
|
|
|
|
||||||||
