Quick Details
-
Voltage:
-
220/380V
-
Dimension(L*W*H):
-
4166*2037*1584 mm
-
Weight (KG):
-
6000
-
Power (kW):
-
9.82 kw
-
Name:
-
Crankshaft Grinder
-
Model:
-
MQ8260Ax16
-
Function:
-
Grinding Flywheel
-
Max. work weight:
-
120 kg
-
Center height:
-
300 mm
-
Max. cross movement:
-
185 mm
-
Max. work swing dia./ Max. length:
-
580*1600 mm
-
Grinding wheel size:
-
900*32*305 mm
-
Machine dimensions (L*W*H):
-
4166*2037*1584 mm
-
Machine weight:
-
6000 kg
Quick Details
-
Wheel Size(mm):
-
900x32x305 mm
-
Place of Origin:
-
China
-
Brand Name:
-
TIMAC
-
Voltage:
-
220/380V
-
Dimension(L*W*H):
-
4166*2037*1584 mm
-
Weight (KG):
-
6000
-
Power (kW):
-
9.82 kw
-
Name:
-
Crankshaft Grinder
-
Model:
-
MQ8260Ax16
-
Function:
-
Grinding Flywheel
-
Max. work weight:
-
120 kg
-
Center height:
-
300 mm
-
Max. cross movement:
-
185 mm
-
Max. work swing dia./ Max. length:
-
580*1600 mm
-
Grinding wheel size:
-
900*32*305 mm
-
Machine dimensions (L*W*H):
-
4166*2037*1584 mm
-
Machine weight:
-
6000 kg
Products Description
|
Specification
|
Unit
|
MQ8260Ax16
|
MQ8260Ax18
|
MQ8260Ax20
|
|
Max. work swing dia. x Max. length
|
mm
|
580x1600
|
580x1800
|
580x2000
|
|
Max. swing diameter over table
|
mm
|
580
|
580
|
580
|
|
Work dia. ground with steady rest
|
mm
|
30-100
|
30-100
|
50-120
|
|
Throw of crankshaft
|
mm
|
110
|
110
|
120
|
|
Max. work length ground: in 3-jaw chuck
|
mm
|
1400
|
1600
|
1800
|
|
Max. work length ground: between centers
|
mm
|
1600
|
1800
|
2000
|
|
Max. work weight
|
mm
|
120
|
120
|
150
|
|
Center height
|
m/s
|
300
|
300
|
300
|
|
Work speed
|
mm
|
25, 45, 95
|
25, 45, 95
|
30, 45, 65, 100
|
|
Max. cross movement
|
mm/r
|
185
|
185
|
185
|
|
Wheel-head rapid approach & withdrawal
|
mm/r
|
100
|
100
|
100
|
|
Wheel feed per turn of cross feed handwheel
|
mm
|
1
|
1
|
1
|
|
Per grad of cross feed handwheel
|
mm
|
0.005
|
0.005
|
0.005
|
|
Wheel spindle speed
|
rpm
|
740, 890
|
740, 890
|
740, 890
|
|
Wheel peripheral speed
|
m/s
|
25.6-35
|
25.6-35
|
25.6-35
|
|
Grinding wheel size
|
mm
|
900x32x305
|
900x32x305
|
900x32x305
|
|
Table travel per turn of handwheel coarse
|
mm/r
|
5.88
|
5.88
|
5.88
|
|
Table travel per turn of handwheel fine
|
mm/r
|
1.68
|
1.68
|
1.68
|
|
Table swivel (taper 18/100)
|
°
|
5°, taper 9/100
|
5°, taper 9/100
|
5°, taper 9/100
|
|
Table swivel per grad of scale(taper 1:50)
|
°
|
1°, taper 1/100
|
1°, taper 1/100
|
1°, taper 1/100
|
|
Overall capacity of motors
|
kw
|
9.82
|
9.82
|
11.12
|
|
Machine dimensions (LxWxH)
|
mm
|
4166x2037x1584
|
4166x2037x1584
|
4900x2037x1584
|
|
Machine weight
|
kg
|
6000
|
6200
|
7000
|
|
Ovality (new standard)
|
mm
|
0.005
|
0.005
|
0.005
|
|
Cylindricity
|
mm
|
0.008
|
0.01
|
0.01
|
|
Roughness (external)
|
um
|
Ra0.32
|
Ra0.32
|
Ra0.32
|
|
Roughness (end)
|
um
|
Ra0.63
|
Ra0.63
|
Ra0.63
|
* 3-jaw chuck
* Wheel adapter
* Grinding wheels & wheel extractor
* Steady rest
* Driving dog
* Wheel dresser
* Wheel balancing arbor
* Vertical aligning stand
* Horizontal aligning stand
