- Product Details
- {{item.text}}
Quick Details
-
Horse Power:
-
10.5kw(7500r/min) 14.5HP
-
Top speed:
-
60km/h
-
Transmission:
-
CVT
-
Brake:
-
220MM Rear Dual Hydraulic Disk
-
Color:
-
green,red,blue,orange
-
Final Drive:
-
shaft-drive
-
Drive Line Type:
-
4x2
-
Ignition System:
-
C.D.I
-
Suspension:
-
Front: double A-Arm, Rear:Fang power 4-Link bar Rear Suspension
Quick Details
-
Brand Name:
-
FANGPOWER
-
Certificate:
-
EPA EEC CE
-
Place of Origin:
-
Shandong, China
-
Horse Power:
-
10.5kw(7500r/min) 14.5HP
-
Top speed:
-
60km/h
-
Transmission:
-
CVT
-
Brake:
-
220MM Rear Dual Hydraulic Disk
-
Color:
-
green,red,blue,orange
-
Final Drive:
-
shaft-drive
-
Drive Line Type:
-
4x2
-
Ignition System:
-
C.D.I
-
Suspension:
-
Front: double A-Arm, Rear:Fang power 4-Link bar Rear Suspension
|
ENGINE
|
FX250 Spider
|
SUSPENSION/BRAKES
|
|||
|
Engine type
|
4-stroke,Single-Cylinder, Air/Oil cooled
|
Suspension Front
|
Adjustable Double A-arm optional
|
||
|
Displacement
|
232cc
|
Suspension Rear
|
Fangpower 4-link®bar Rear Suspension
|
||
|
Horse Power
|
10.5kw(7500/r/min) 14.5HP
|
Brakes Front
|
220MM Front Dual Hydraulic Disk
|
||
|
Value Configuration
|
OHV
|
Brakes Rear
|
220MM Rear Dual Hydraulic Disk
|
||
|
Compression ratio
|
10.3:1
|
Steering
|
Rock and pinion steering
|
||
|
FUEL SYSTEM
|
TIRES
|
||||
|
Fuel Delivery System
|
Fuel Pump Carburetor
|
Front Tread
|
1150mm(45.3 in)
|
||
|
Choke System
|
Automatic
|
Rear Tread
|
1040mm(41.0in)
|
||
|
Fuel Capacity
|
9.5L(2.1 Gallon)
|
Front & Rear tire size
|
25x8-12 / 25x10-12
|
||
|
DRIVETRAIN
|
MISC
|
||||
|
Drivenline Type
|
2x4
|
Loading information
|
8 units/20″; 26units/40HQ
|
||
|
Final Drive
|
Shaft-drive
|
Top speed
|
65km/h
|
||
|
Transmission
|
Constantly Variable Transmission
|
Dry weight
|
400kgs
|
||
|
Gear Selection
|
F-N-R
|
Gross weight
|
470kgs
|
||
|
ELECTRICAL SYSTEM
|
Wheel Base
|
1980mm (78in)
|
|||
|
Speed/Fuel meter
|
LED meter
|
Vehicle dimension(L×W×H)
|
2590x1350x1750mm(102x53x69in)
|
||
|
Battery
|
12 AH 12V
|
Packing size
|
2290x1300x815mm
|
||
|
Forward Lights
|
Headlights-High&Low Beam LED LIGHT
|
Ground clearance
|
260mm (10.2in)
|
||
|
Rear Lights
|
Brake Lights& Left/Right Signal Lights
|
Safety
|
Driver & Passenger Seat belts/ Driver and Passenger safety steel door.
|
||
|
Starting system
|
Electric start
|
||||
|
Ignition system
|
C.D.I
|
||||
